Star micowave SM Cirius SHC User Manual

Digital microwave radio hybrid ip digital microwave indoor unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SM Cirius SHC
Digital Microwave Radio
Hybrid IP Digital Microwave Indoor Unit
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SM Cirius SHC and is the answer not in the manual?

Questions and answers

Summary of Contents for Star micowave SM Cirius SHC

  • Page 1 SM Cirius SHC Digital Microwave Radio Hybrid IP Digital Microwave Indoor Unit User’s Manual...
  • Page 2 This is an unpublished work the copyright in which vests in Star Microwave Service Corporation ("Star Microwave Service Corporation"). All rights are reserved. The information contained herein is confidential and the property of Star Microwave Service Corporation and is supplied without liability for errors or omissions.

  • Page 3: Table Of Contents

    0.1 CONTENTS Section Page ......................... 3 CONTENTS ........................6 HISTORY ............... 7 SAFETY NOTICES AND ADMONISHMENTS ....................8 GLOSSARY OF TERMS ....................9 SYSTEM SPECIFICATION IDU ........................... 9 1.1.1 ..................9 INTERFACE DESCRIPTION 1.1.2 ....................... 10 DC POWER 1.1.3 ........................... 10 1.1.4 .........................
  • Page 4 3.4.1.5.1 ....................30 ADD NEW VLAN ENTRY 3.4.1.5.2 ....................30 DELETE VLAN ENTRY 3.4.2 ......................... 31 3.4.2.1 ..................... 31 SYSTEM INFORMATION 3.4.2.1.1 ..................... 31 CHANGE SYSTEM MODE 3.4.2.1.2 ....................31 CHANGE SYSTEM TIME 3.4.2.2 ......................32 SYSTEM 3.4.2.3 ........................32 MODEM 3.4.2.3.1 ...............
  • Page 5 3.6.1 ........................49 SWITCH 3.6.1.1 ....................... 49 PASSWORD 3.6.1.2 ..................49 AUTHENTICATION METHOD 3.6.1.3 ......................... 50 3.6.1.4 ........................50 HTTPS 3.6.1.5 ....................51 ACCESS MANAGEMENT 3.6.2 ........................ 51 NETWORK 3.6.2.1 ......................51 PORTS 3.6.2.2 ....................52 RATE LIMITERS 3.6.2.3 ................53 ACCESS MANAGEMENT STATISTICS ......................

  • Page 6: History

    0.2 HISTORY Change No. Details Of Change 1-0-0 Initial document released in Sep 2012. 1-0-1 Revised the description format, and update the Web GUI screen capture in September 2013. Star Microwave Cirius SHC , 2016...

  • Page 7: Safety Notices And Admonishments

    0.3 SAFETY NOTICES AND ADMONISHMENTS This document contains safety notices in accordance with appropriate standards. In the interests of conformity with the territory standards for the country concerned, the equivalent territorial admonishments are also shown. Any installation, adjustment, maintenance and repair of the equipment must only be carried out by trained, authorized personnel.

  • Page 8: Glossary Of Terms

    GLOSSARY OF TERMS Alarm ATPC Automatic Transmit Power Control Bit Error Rate Bayonet Neill-Concelman Craft Interface Terminal Direct Current Framing specification for synchronous digital streams at 2.048Mbit/s Ethernet ETSI European Telecommunications Standards Institute Federal Communications Commission FPGA Field Programmable Gate Array Ground Indoor Unit Intermediate Frequency...

  • Page 9: System Specification

    1 SYSTEM SPECIFICATION 1.1 IDU 1.1.1 IDU INTERFACE DESCRIPTION Figure 1-1 1U IDU Unit Front Penal Interface STM-1 IF Interface External Clock GT1-GE4 GE5-GE7 AUX/Alarm Sys ON / IDU ON / OFF Table 1-1 Interface Description Interface Connector Quantity Remark Polarized plug -48V DC and lower than 5A PWR Switch...

  • Page 10: Dc Power

    Table 1-2 IDU LED Indicator Instruction Indicator Status Description flash (Green) System on boot On (Green) System operates normal No power in or system boot failure On (Red) The system detect a IDU alarm IDU ALM IDU normal operation On (Red) The system detect a ODU alarm ODU ALM ODU normal operation...

  • Page 11: Eth

    1.1.4 ETH Each IDU Unit supports four 10/100/1000Mbps electrical Ethernet ports and three 100M/1000Mbps optical Ethernet ports. Optical Ethernet port used SFP module. Electrical port supports MDI and MDI-X auto-negotiation mode. RJ-45 connector front view and pin definitions in Figure 1-4 and Tables 1-6 shown. Figure 1-4 Ethernet Port Table 1-6 RJ-45 MDI/MDI-X Pin Definition 10/100/1000 BASE-T MDI...
  • Page 12 1.1.5 T1 Uses MDR68 connector connects from IDU to Interface Adapter. Connector view and pin definitions in Figure 1-5, Tables 1-8 and Tables 1-9 shown. Figure 1-5 TMD RJ-45/BNC Port IN — 10 — OUT Table 1-8 T1 RJ-45 Pin Definition Signal Function Signal...

  • Page 13: System Software

    2 SYSTEM SOFTWARE Cirius HM system software is divided into three parts: NMS software, IDU software and ODU software. The software architecture is shown in Figure 2-1, the NMS software used the IP communicate with IDU. Figure 2-1 Software Architecture NMS Software IDU Software ODU Software...

  • Page 14: Configuration In Web Graphic User Interface

    3 CONFIGURATION IN WEB GRAPHIC USER INTERFACE 3.1 LOGIN The supported browsers include ‘Internet Explore’, ‘Mozilla Firefox’ and ‘Google Chrome’. Follow steps below to achieve the connection with web interface: Step 1: First the user needs to set the PC IP address as the one sharing the same network segment with the IDU IP address.

  • Page 15: Brief Description

    3.2 BRIEF DESCRIPTION 3.2.1 SYSTEM COMPOSITION After logging in, the following window will show up. The main window in Web GUI is the System Composition, which shows the system including the Local site and Remote site status. Figure 3-2 System Composition Window Table 3-1 Device Information Parameter Description...
  • Page 16 Table 3-3 SRU Information Parameter Description Modulation Mode System current modulation mode ACM Switch System adaptive coding & modulation function status Channel Bandwidth System current used of channel bandwidth ODU Tx Power ODU current transmit power ODU RSL ODU current receive signal level ODU ATPC ODU ATPC function status NOTE:...

  • Page 17: Information

    3.2.2 INFORMATION In the main system information window, user is able to check the system information, include software and hardware version. Figure 3-3 System Information Window NOTE: Some item will display N/A according the different system mode because of useless. •...
  • Page 18 Table 3-5 Modem Information Parameter Description Firmware Version System current modem firmware version Bandwidth System current used of channel bandwidth Modulation Mode System current modulation mode Demodulation State Shown whether the modem demodulation normal Used to measure the Modulation Error Ratio Table 3-6 ODU Information Parameter Description...

  • Page 19: Alarm

    3.2.3 ALARM In the alarm window, user is able to check the system current important alarm. When the alarms are inactive, corresponding icon will display green. Once the alarms had be active, icon will display red and IDU front panel alarm LED indicator will turn on. Figure 3-4 Alarm Window Table 3-7 System Alarm Information Parameter...

  • Page 20: Guide

    3.3 GUIDE 3.3.1 QUICK CONFIGURATION User can use the system quick configuration window to achieve a quick start of the microwave link. The quick configuration can set the radio parameters and a few system settings. The system can provide basic services such as simple Ethernet service after the quick configuration is completed. Figure 3-5 Quick Configuration - Step 1 Parameter Range...
  • Page 21 MRU MASTER Mode Master | Slaver Master SRU ACM Switch On | Off License dependent SRU Modulation M. QPSK ~ 256QAM License dependent SRU Bandwidth ETSI | FCC SRU MASTER Mode Master | Slaver Slaver NOTE: ACM function and modulation selection range are License dependent. Please contact Star •...
  • Page 22 Figure 3-8 Quick Configuration - Last Step <Save Configuration>: Save all parameter settings and apply immediately. Star Microwave Cirius SHC , 2016...

  • Page 23: Configuration Window

    3.4 CONFIGURATION WINDOW 3.4.1 SWITCH 3.4.1.1 PORT In the ports window user can read/configure the parameters of Ethernet ports. Port 1~4 corresponds to front panel electrical Ethernet ports 1~4, and Port 5~7 corresponds front panel optical Ethernet ports 5~7. Port 8~11 are system internal ports only… please keep these ports at their default setting.

  • Page 24: Ethernet Port Speed Rate Configuration

    3.4.1.1.1 ETHERNET PORT SPEED RATE CONFIGURATION Step 1 Click in Functional Navigation Tree; Configuration > Switch > Ports Step 2 Click corresponding port drop-down menu, and select the Speed - Configured appropriate value; Step 3 Click <Save> and wait for the page refresh; Step 4 Check whether Speed - Current...

  • Page 25: Aggregation

    3.4.1.2 AGGREGATION In aggregation window, user can configure the aggregation group and algorithm. Figure 3-10 Aggregation Window Hash Code Contributors: allows selecting hash code contributors for making a key, including Source four type. MAC Address Destination MAC Address IP address TCP/UDP port number Base on the network demand, user can use of combinations of different algorithms to build up the aggregation network.

  • Page 26: Aggregation Group Menber Configuration

    <IP Address>: allows Ethernet data with different IP address to be arranged to transmit in different links evenly. <TCP/UDP Port Number>: allows Ethernet data with different TCP/UDP port number to be arranged to transmit in different links evenly. 3.4.1.2.1 AGGREGATION GROUP MENBER CONFIGURATION Step 1 Click in Functional Navigation Tree;...

  • Page 27: Aggregation Group Algorithm Configuration

    3.4.1.2.2 AGGREGATION GROUP ALGORITHM CONFIGURATION Step 1 Click in Functional Navigation Tree; Configuration > Switch > Aggregation > Static Step 2 Tick appropriate algorithms according to the network plan; Step 3 Click <Save> and wait for the page refresh; - - - End NOTE: The algorithms will take effect to the entire aggregation group, and do not support •...

  • Page 28: Mac Table

    3.4.1.4 MAC TABLE In the MAC address table window, user can configure the parameters of MAC address table. Figure 3-13 MAC Table Window Parameter Range Default Remark Disable Auto Aging Enable | Disable Disable Automatic aging function Aging time Auto learn MAC aging time MAC table - Auto 1~11 1~11...

  • Page 29: Mac Table Aging Time Configuration

    3.4.1.4.1 MAC TABLE AGING TIME CONFIGURATION Step 1 Click in Functional Navigation Tree; Configuration > Switch > MAC Table Step 2 Key in appropriate value in Aging Time column Step 3 Click <Save> and wait for the page refresh; - - - End 3.4.1.4.2 DISABLE MAC TABLE AGING TIME Step 1 Click...

  • Page 30: Vlans - Vlans Membership

    3.4.1.5 VLANS - VLANS MEMBERSHIP In VLAN membership configuration window, user can configure VLAN parameters. Figure 3-14 VLAN Window Parameter Range Default Remark Delete Delete current VLAN entry VLAN ID 1~4096 VLAN ID is unique VLAN Name Max 31 characters Port Members 1~11 Port default VLAN ID = 1...

  • Page 31: Mru

    3.4.2 MRU 3.4.2.1 SYSTEM - INFORMATION Figure 3-15 System Information Window Parameter Range Default Remark System Time YYYY-MM-DD hh-mm-ss System Mode License dependent NOTE: Most of the system parameters are the same and relate with Quick Configuration. If the • Quick Configuration was completed, some system parameters setting can be skipped.

  • Page 32: System - Ip

    3.4.2.2 SYSTEM - IP Figure 3-16 System IP Window Parameter Range Default Remark IP Address Default: 192.168.168.1 IP Mask Default: 255.255.255.0 IP Router 0.0.0.0 Gateway Remote IP Address Used to inquiry remote info VLAN ID 1~4096 Web GUI VID 3.4.2.3 MODEM Figure 3-17 MRU Modem Window Parameter Range...

  • Page 33: Select Bandwidth And Modulation

    3.4.2.3.1 SELECT BANDWIDTH AND MODULATION Step 1 Click in Function Navigation Tree; Configuration > MRU > Modem Step 2 Click the drop-down menu and select the appropriate value in Bandwidth Modulation Mode Step 3 Click <Save> and wait for the page refresh; - - - End 3.4.2.3.2 ACM CONFIGURATION Step 1...

  • Page 34: Mute The Radio

    3.4.2.4.1 MUTE THE RADIO Step 1 Click in Function Navigation Tree; Configuration > MRU > ODU Step 2 Select Off in SSPA Step 3 Click <Save> and wait for the page refresh; - - - End 3.4.2.4.2 TX POWER CONFIGURATION Step 1 Click Configuration >...

  • Page 35: Sru

    3.4.3 SRU 3.4.3.1 MODEM Figure 3-19 SRU Modem Window Parameter Range Default Remark ACM Switch On | Off License dependent Modulation Mode QPSK ~ 256QAM License dependent Bandwidth ETSI | FCC Modulation Error Ratio Current Tx Mod. QPSK ~ 256QAM Current Rx Mod.
  • Page 36 RSL Alarm Thresh. -90~-20dBm NOTE: The SRU page displays items and parameters that change based on the system mode (as • 1+1 HSB / SD / FD or 2+0). Star Microwave Cirius SHC , 2016...

  • Page 37: Msu

    3.4.4 MSU 3.4.4.1 CHANNEL SWITCH Figure 3-21 MSU Protection Window Parameter Range Remark T1 Enable Enable | Disable STM-1 Enable Enable | Disable 3.4.4.1.1 T1 CONFIGURATION Step 1 Click in Function Navigation Tree; Configuration > MSU > T1 Step 2 Select to enable the 16 ways T1, or to disable the T1;...

  • Page 38: Monitor

    3.5 MONITOR 3.5.1 SWITCH 3.5.1.1 PORT - STATUS In ports status, shown are the seven Ethernet ports which correspond to the IDU front panel. When the Ethernet is connected, the port icon will turn green. If port is black this means this port is disconnected.

  • Page 39: Qos Statistics

    Filter - Rx Count the filtering packets number on received <Clear>: Clear the page statistics and restart the counting. 3.5.1.3 QOS STATISTICS Figure 3-24 QoS Statistics Window Parameter Description Q1~Q7 - Rx Count the received packet number on each queue of port Q1~Q7 - Tx Count the transmitted packet number on each queue of port Star Microwave Cirius SHC , 2016...

  • Page 40: Detailed Statistics

    3.5.1.4 DETAILED STATISTICS Figure 3-25 Port Statistics Window Parameter Description Receive Total Count the total received packets of port Transmit Total Count the total transmitted packets of port Rx Size Counters Count the total received numbers of different frame sizes Tx Size Counters Count the total transmitted numbers of different frame sizes Rx Queue Counters...

  • Page 41: Mac Table

    3.5.1.5 MAC TABLE Figure 3-26 MAC Table Window Parameter Description Type Indicate type of MAC address (include static and dynamic) VLAN VLAN ID of MAC address MAC Address The details of MAC address Port Members Indicate which ports had learned this MAC entry 3.5.1.6 VLAN MEMBERSHIP Figure 3-27 VLAN Window Parameter...

  • Page 42: Mru

    3.5.2 MRU 3.5.2.1 SYSTEM - INFORMATION Figure 3-28 MRU Information Window 3.5.2.2 SYSTEM - SYSTEM LOG Figure 3-29 System Log Window Parameter Description The ID of system event Level System defined event level as Info, Warning, Error Time The date event happened Message The details of system event <Clear>: Clear the all the system events.

  • Page 43: System -Rsl Log

    3.5.2.3 SYSTEM -RSL LOG Figure 3-30 RSL Log Window Parameter Description RSL Log Interval The time period to record the RSL The ID of RSL record Time The record date of RSL event RSL (dBm) The recorded received signal level 3.5.2.4 TEMPERATURE Figure 3-31 System Temperature Window Parameter...

  • Page 44: Modem

    3.5.2.5 MODEM Figure 3-32 MRU Modem Status Window Parameter Description Demodulation Status Indicate whether the modem demodulation is working normally Tx Channel Status Indicate the Transmit channel status 3.5.2.6 IF Figure 3-33 MRU IF Window 3.5.2.7 ODU Figure 3-34 MRU ODU Status Window Star Microwave Cirius SHC , 2016...

  • Page 45: Alarm

    3.5.2.8 ALARM Figure 3-35 MRU Alarm Window Star Microwave Cirius SHC , 2016...

  • Page 46: Sru

    3.5.3 SRU 3.5.3.1 SYSTEM - RSL LOG Figure 3-36 SRU RSL Log Window 3.5.3.2 MODEM Figure 3-37 SRU Modem Status Window 3.5.3.3 IF Figure 3-38 SRU IF Window Star Microwave Cirius SHC , 2016...

  • Page 47: Odu

    3.5.3.4 ODU Figure 3-39 SRU ODU Status Window 3.5.3.5 ALARM Figure 3-40 SRU Alarm Window Star Microwave Cirius SHC , 2016...

  • Page 48: Msu

    3.5.4 MSU 3.5.4.1 T1 Figure 3-41 T1 window Star Microwave Cirius SHC , 2016...

  • Page 49: Security Window

    3.6 SECURITY WINDOW 3.6.1 SWITCH 3.6.1.1 PASSWORD Figure 3-42 System Password Window Parameter Description Old password Key in the old password New password Key in the new password Confirm new PSW New password confirm, change fail when PSW mismatched NOTE: Password can be any number or letter and the length should be less than 31 characters.

  • Page 50: Ssh

    3.6.1.3 SSH Figure 3-44 System SSH Window Parameter Range Default Remark Mode Enable | Disable Enable Enable/disable SSH mode 3.6.1.4 HTTPS Figure 3-45 System HTTPS Window Parameter Range Default Remark Mode Enable | Disable Enable Enble/disable https mode Automatic Redirect Enable | Disable Disable Enable/disable auto redirect...

  • Page 51: Access Management

    3.6.1.5 ACCESS MANAGEMENT Figure 3-46 Access Management Window Parameter Range Default Remark Mode Enable | Disable Enable Access management Start IP Address IP address for access client End IP Address IP address for access client HTTP/HTTPS Enable | Disable Disable Enable/disable this function TELNET/SSH Enable | Disable...

  • Page 52: Acl - Rate Limiters

    Figure 3-48 Port Copy Data Flow Chart Cable Cable Port Copy Port Copy Connection Connection Port 1 Port 2 Port 3 Port 4 Cable Connection Port 6 Port 7 Port 5 Port Copy Port Copy Cable Connection 3.6.2.2 ACL - RATE LIMITERS Figure 3-49 Rate Limiter Window Parameter Range...

  • Page 53: Access Management Statistics

    3.6.2.3 ACCESS MANAGEMENT STATISTICS Figure 3-50 Access Statistics Window Parameter Description HTTP Packet statistics of HTTP mode HTTPS Packet statistics of HTTPS mode Telnet Packet statistics of Telnet mode Packet statistics of SSH mode Star Microwave Cirius SHC , 2016...

  • Page 54: Diagnostic

    3.7 DIAGNOSTIC 3.7.1 PING In this page the system provides the ICMP Ping function the same as Microsoft Window OS. Operator can use to inspect the Ethernet link status between the IDU and a target device. Figure 3-51 Ping Window 3.7.2 VERIPHY VeriPHY are used for verify the Ethernet PHY layer status and measure the length of cable which connects to port 1~4 electrical Ethernet port in the IDU front panel.

  • Page 55: Debug

    3.7.3 DEBUG 3.7.3.1 DEBUG - MRU Figure 3-53 MRU Debug Window Parameter Range Default Remark IF Loopback Normal | Loop Normal Used for maintenance only Modem Loopback Normal | Loop Normal Used for maintenance only Modem Onetone Enable | Disable Disable Used for maintenance only Onetone Frequency...

  • Page 56: Debug - Msu

    3.7.3.3 DEBUG - MSU Figure 3-56 MSU Debug Window Parameter Range Default Remark STM-1 Line Loop Normal | Loop Normal Used for maintenance only STM-1 System Loop Normal | Loop Normal Used for maintenance only T1 Line Loop Normal | Loop Normal Used for maintenance only T1 System Loop...

  • Page 57: Maitenance

    3.8 MAITENANCE 3.8.1 RESTART DEVICE Figure 3-57 System Restart Window NOTE: Restart will interrupt the microwave link and will recover after system start up. • 3.8.2 FACTORY DEFAULTS Figure 3-58 Factory Reset Window NOTE: Factory Default reset will clear all the parameters which had been configured, and will •...

  • Page 58: Appendix B: Rma (Return Material Authorization) Form

    3.9 APPENDIX B: RMA (RETURN MATERIAL AUTHORIZATION) FORM Star Microwave Service Corporation 41458 Christy St. Fremont, CA 94538-6547 Telephone: +1 510.498.7900 Fax +1 510.498.7901 RMA Request Form Date: From : Address : Fax : E-mail: ATTN: Product Information : Item Model Serial Number Return Category...

  • Page 59: Star Microwave Cirius Shc

    Star Microwave Service Corporation 41458 Christy St. Fremont, CA. 94538 Tel: +1 510.498.7900 Fax: +1 510.498.7901 Star Microwave Cirius SHC , 2016...
