Summary of Contents for Reso QDOS Q-PUK
- Page 1 Company Confidential Reso Ltd T/A QDOS USER MANUAL QDOS Q‐PUK Bluetooth Waterproof Speaker Issue N° 1 June 2014 ...
- Page 2 Congratulations on your purchase. Your QDOS Q‐PUK Bluetooth Waterproof Speaker for all Bluetooth compatible iProducts, smartphones, tablets, PCs and other devices capable of streaming Bluetooth audio is designed to deliver a superior audio experience as an ultra light‐weight mini portable speaker system. This compact, rugged speaker built for outdoor use easily connects wirelessly to your music device, in seconds…no cables, no hassles! Robust and durable with its unique protective, waterproof silicone skin, it will provide hours of crystal clear audio on the go. We hope you will take few moments to read this manual and follow all user instructions to get to know your product. System Specifications of the QDOS Q-PUK Bluetooth Waterproof Speaker Product Specifications Dimensions: 85mm x 87mm x 34mm DC power: Rated Power: DC power Weight : 130gms Interface :...
- Page 3 Company Confidential Reso Ltd T/A QDOS Features & Functions ① Carabiner • Convenient carry solution for fixing to backpack, belt etc.. ② + Volume Up / Next song • short press for next song • long press for volume up ③ NFC: approach any NFC‐enabled mobile phone to this position and the speaker and mobile will pair automatically ④ ‐ Volume Down / Previous song • short press for previous song • long press for volume down ⑤ LED indicator – built‐in battery status • Blue LED flashing ‐ pairing. After pairing successfully, it will remain blue • Blue LED on ‐ playing • Red LED on ‐ charging, when charging is finished, it will turn off ⑥ Power switch On/Off •...
- Page 4 Company Confidential Reso Ltd T/A QDOS Operation First, turn on the QDOS Q‐PUK Bluetooth Waterproof speaker using the On/Off button on the side of the device ⑥. Press the button for 3 seconds to power on or power off. When powered on, the blue LED light will flash and you will hear a sound. Your QDOS Q‐ PUK Bluetooth speaker is ready for use. When you are ready to turn off the Q‐PUK speaker, simply hold the power button down for 3 seconds. You will hear a sound and the blue LED light will turn off. NB ‐ to preserve battery power and ensure uninterrupted fun when out and about, the QDOS Q‐PUK is designed to turn off after 5 minutes when not in use, or when no device is paired! Connecting your QDOS Q‐PUK waterproof speaker for playback via Bluetooth Activate the Bluetooth function of your device (smartphone, PC or tablet) Make sure the QDOS Q‐PUK is turned on Search for QDOS Find QDOS Pairing Select QDOS to connect and play When finished playing do remember to turn off the QDOS Q‐PUK using the power button Connecting your QDOS Q‐PUK waterproof speaker for playback via NFC* Search your mobile device and, if applicable, turn on/select the option ‘allow data exchange when close to other devices’ ...
- Page 5 Company Confidential Reso Ltd T/A QDOS Using your QDOS Q‐PUK device Now that you are connected and ready for play, you can control the volume either directly on the QDOS Q‐PUK using the volume buttons ② ④, or via the volume control on your paired device When making or receiving a call, the audio will pause during the call and restart when the call has ended NB ‐ sound performance can be affected by transmitting distance, poor signal and other factors. See TROUBLESHOOTING for more information. Waterproof details for your QDOS Q‐PUK Bluetooth speaker Your QDOS Q‐PUK is tested and certified submersible up to 1 metre Please note that playback may be momentarily affected due to water pressure and interference It is recommended to shake off any excess surface water and dry your QDOS Q‐PUK before re‐use to get back to optimal performance NB ‐ the QDOS Q‐PUK is a waterproof speaker and is protected against accidental water ingress for a rugged outdoor or indoor use. It is not designed for use as an underwater speaker. Charging your QDOS Q‐PUK device When the battery is low, the QDOS Q‐PUK will emit warning beeps to remind you to re‐charge it Turn off your QDOS Q‐PUK Connect the micro‐USB end of the USB charging cable with the unit ⑧ and connect the other end to your PC, power bank or other charger device whose output is DC5V, 0.5A‐2A ...
- Page 6 Company Confidential Reso Ltd T/A QDOS Low battery capacity may also affect playback performance. Re‐charge the device using the cable provided to restore performance. It is recommended always to turn off your device when charging and to unplug before use. WHATS IN THE BOX QDOS Q‐PUK Bluetooth speaker Carabiner and silicone band USB to Micro‐USB charging cable User manual CARE AND MAINTENANCE Always turn off the unit and unplug the power cable first before performing any general cleaning ...
- Page 7 Company Confidential Reso Ltd T/A QDOS a harmful quantity shall not be possible when the enclosure is immersed in water (immersion up to 1m) Do not submerge or use the QDOS Q‐PUK Bluetooth speaker in water deeper than 1 metre. The QDOS Q‐PUK will likely be damaged by water pressure below that depth. If your QDOS Q‐PUK Bluetooth speaker does fall into deeper water, do not resume use without the advice of a qualified technician To prevent short circuit or other potential hazards, keep small electrically conductive parts away from the QDOS Q‐PUK Bluetooth speaker and its connecting sockets Do not allow small children to play with the QDOS Q‐PUK Bluetooth speaker ...
- Page 8 LIMITATION OF LIABILITY REPAIR OR REPLACEMENT OF THIS PRODUCT, AS PROVIDED HEREIN, IS YOUR EXCLUSIVE REMEDY. RESO LTD SHALL NOT BE LIABLE FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING, BUT NOT LIMITED TO, LOST REVENUES, LOST PROFITS, LOSS OF USE OF SOFTWARE, LOSS OF...
