servibell SB-HCM-3000N Operating Manual

Wristwatch-type receiver
Hide thumbs
1
2
3
4
5
Table of Contents

Advertisement

Quick Links

Download this manual
Wristwatch-type Receiver
<Button Descriptions>
FUN
(FUNCTION): To start function, To enter chosen function.
PWR
(POWER): Power ON/OFF, To move on to next function, To move on to next number/menu
ESC
(ESC): To delete the calling numbers one by one, To complete/exit function
<Basic Descriptions>
POWER ON:
Press "PWR" button for 3 seconds to turn on the Wristwatch-type Receiver. When power is turned on, the
screen will show "333 222 111 000" with a short beeping sound and vibration. The backlight is shortly turned on and off.
Now the screen is on the stand-by status.
POWER OFF:
Press "PWR" button for 3 seconds to turn it off.
CHARGING:
GREEN: Plug in the adapter and the LED light on the adapter will turn on green.
RED: As the USB cable is connected to the Wristwatch-type Receiver, the LED light turns into red which
means the receiver is in the charging status.
GREEN: When the receiver is fully charged, the LED light turns into green.
* After fully charged, the battery will maintain approximately 40 hours on a stand-by status till the next charging.
BACKLIGHT:
Backlight is on for 2 seconds and then goes off at the moment the Wristwatch-type Receiver gets the
signal or the Function buttons are performed.
BATTERY CHECK & BELL TEST:
###: Voltage indication
Push the buttons on Wireless Service Bell. It's normal if rF blinks on display making a beeping sound. press "ESC" to
exit the function.

* Using this Bell Test Mode, you can test the Wireless Service Bells without registering them on receivers.
BATTERY ALARM:
When the battery is low, melody will be played and the battery icon will blink.
RESET:
The first thing you have to do is resetting SB-HCM-3000N before performing any function.
(Go to Function F6 (bdE))
* After the reset ("dEL"), everything turns into the basic settings. So you have to change them according to your needs.
Basic Settings
F2 (bEL): 4
F3 (dSP): 5
F4 (bno): 1
Beep Sound: melody and vibration
Display Time: 5 SEC
Beep Number: 1 TIME
<Main Features>
1. Dimensions: 42mm X 57mm X 15 mm
2. Frequency: 433.92MHz
3. Power: DC3.7V/180mA
4. Battery: Lithium Polymer (Internal)
5. Receive Sensitivity: -105dBm
6. Expected Battery Life: 40 hours standby
7. Internal Battery
8. Internal Antenna
9. Backlight LED Blue
10. 3 signals, 3-digit display
11. Multiple Bell registration with same number is possible.
12. The standard type of cable (Micro USB) is offered.
13. Priority Numbers: U00~U06
14. Cancel Numbers: U07, U08, U09
Press "ESC" button for 3 seconds on Stand by Mode, then "rF###" will appear.
Operating Manual
model: SB-HCM-3000N
(Model names may vary by country)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SB-HCM-3000N and is the answer not in the manual?

Questions and answers

Summary of Contents for servibell SB-HCM-3000N

  • Page 1 When the battery is low, melody will be played and the battery icon will blink. RESET: The first thing you have to do is resetting SB-HCM-3000N before performing any function. (Go to Function F6 (bdE)) * After the reset (“dEL”), everything turns into the basic settings. So you have to change them according to your needs.
  • Page 2 Step 6. If you want to select the other function, use “PWR”. Or if you want to go back to the stand-by status, press “ESC”. * Up to 2,399 Wireless Service Bells can be registered with SB-HCM-3000N. 001~999, A00~A99, b00~b99, C00~C99, d00~d99, E00~E99, F00~F99, H00~H99, L00~L99, n00~n99, o00~o99, P00~P99, r00~r99, t00~t99, U00~U99 (U00~U06 have priority.
  • Page 3 6: mute
 7: voice and vibration 8: voice and melody 9: voice Voice require earphones to be sold separately. Volume function when setting voice(7~9) with button “FUN=UP” or “PWR=DOWN” uol 1~uol 10 Step 5. If you want to select the other function, use “PWR”. Or if you want to go back to the stand-by status, press “ESC”.
...
  • Page 4 7. F9 (rSP) Recall Time Setting (When using repeater) Step 1. Press and hold “FUN” button for 3 seconds. F1 (rEC) displayed.


 Step 2. Press “PWR” button until “F9 (rSP)” is displayed. Step 3. Press “ENT” button and the screen will show the current number. Change the status by using “PWR” button(0~4).
  • Page 5 4. E4 (bit) Product type: Select Transmitter Step 1. Press and hold “FUN” button for 3 seconds. F1 (rEC) displayed.
 Step 2. Press and hold “FUN” button for 3 seconds. E1 (Pdt) displayed.
 Step 3. Press “PWR” button until “E4 (bit)” is displayed. Step 3.
