Summary of Contents for MSI MS-9A91
- Page 1 MS-9A91 Touch Panel PC...
-
Page 2: Revision History
Alternatively, please try the following help resources for further guidance. Visit the MSI website for technical guide, BIOS updates, driver updates and other information, or contact our technical staff via http://www.msi.com/support/... -
Page 3: Safety Instructions
MS-9A91 Safety Instructions ￭ Always read the safety instructions carefully. ￭ Keep this User’s Manual for future reference. ￭ Keep this equipment away from humidity. ￭ Lay this equipment on a reliable flat surface before setting it up. ￭ The openings on the enclosure are for air convection hence protects the equipment from overheating. -
Page 4: Chemical Substances Information
Chemical Substances Information In compliance with chemical substances regulations, such as the EU REACH Regulation (Regulation EC No. 1907/2006 of the European Parliament and the Council), MSI provides the information of chemical substances in products at: http://www.msi.com/html/popup/csr/evmtprtt_pcm.html Battery Information European Union: Batteries, battery packs, and accumulators should not be disposed of as unsorted household waste. -
Page 5: Ce Conformity
MSI will comply with the product take back requirements at the end of life of MSI-branded products that are sold into the EU. -
Page 6: Japan Jis C 0950 Material Declaration
Japan JIS C 0950 Material Declaration A Japanese regulatory requirement, defined by specification JIS C 0950, mandates that manufacturers provide material declarations for certain categories of electronic products offered for sale after July 1, 2006. http://www.msi.com/html/popup/csr/cemm_jp.html http://tw.msi.com/html/popup/csr_tw/cemm_jp.html 日本JIS C 0950材質宣言 日本工業規格JIS C 0950により、2006年7月1日以降に販売される特定分野の 電気および電子機器について、製造者による含有物質の表示が義務付けられま... -
Page 7: Vietnam Rohs
Việt Nam RoHS Kể từ ngày 01/12/2012, tất cả các sản phẩm do công ty MSI sản xuất tuân thủ Thông tư số 30/2011/TT-BCT quy định tạm thời về giới hạn hàm lượng cho phép... -
Page 8: Table Of Contents
Preface CONTENTS Copyright Notice .................... ii Trademarks ....................ii Revision History .................... ii Technical Support ..................ii Safety Instructions ..................iii Chemical Substances Information ............... iv Battery Information ..................iv CE Conformity ....................v FCC-A Radio Frequency Interference Statement ......... v WEEE Statement .................. -
Page 9: Overview
Thank you for choosing the MS-9A91, a high-performance industrial touch panel PC from MSI. The MS-9A91 is designed for panel mounting and VESA mounting in machine and plant engineering. A highly integrated and easy-to-use platform, the MS-9A91 is perfect for factory automation, kiosk and more... -
Page 10: System Overview
Overview System Overview System I/O & Controls... -
Page 11: Touch Screen
MS-9A91 Touch Screen The user-friendly touch screen enables effective operation and control of the system on the user’s end. Antenna Connector (Optional) This connector allows you to connect an external antenna for wireless LAN. Users may find one antenna connector on the bottom I/O panel and two on the left and right sides of the system. - Page 12 Overview USB 2.0 Port The USB (Universal Serial Bus) port is for attaching USB devices such as keyboard, mouse, or other USB-compatible devices. It supports up to 480Mbit/s (Hi-Speed) data transfer rate. RS232 Serial Port: COM2 (RJ45 to RS232 adapter cable required) The serial port is a 16550A high speed communications port that sends/ receives 16 bytes FIFOs.
-
Page 13: System Specifications
MS-9A91 System Specifications Processor ■ Intel BayTrail-I E3845 processor Memory ■ 2 x DDR3L 1333MHz SO-DIMM slots ■ Up to 8 GB ■ Realtek RTL8111E Gigabit Fast Ethernet controller Audio ■ Realtek ALC887 High Definition Audio codec Storage ■ 1 x SATA 3Gb/s, 2.5” HDD/SSD ■... -
Page 14: Power Supply
Overview Dimension ■ 418mm x 271mm x 60mm Regulatory Compliance ■ EMC: CE, FCC, C-Tick, VCCI, BSMI ■ Safety: CB, BSMI Power Supply ■ 84 Watt AC/DC Adapter ■ Input: 100-240V~, 1.3A, 50-60Hz ■ Output: 12V 7A MAX ■ Each COM port outputs 0.5A/Maximum OS Support ■... -
Page 15: Me Overview
MS-9A91 ME Overview... -
Page 17: Getting Started
Getting Started This chapter provides you with the information on hardware setup procedures. While connecting peripheral devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity. 1-2-1... -
Page 18: Installing Components
Getting Started Installing Components h Installing Memory 1. Unscrew the SO-DIMM compartment. - Page 19 MS-9A91 2. Remove the cover and set it aside for later use. 3. Locate the SO-DIMM slots. 4. Align the notch on the DIMM with the key on the slot and insert the DIMM into the slot at a 45-degree...
- Page 20 Getting Started 5. Push the DIMM gently downwards until the slot levers click and lock the DIMM in place. 6. Install the second memory if necessary. Important • You can barely see the golden finger if the DIMM is properly inserted in the DIMM slot.
- Page 21 MS-9A91 h Installing mSATA Card 1. Locate the mSATA slot and remove the screw preinstalled on the motherboard. 2. Insert the mSATA card into the slot at a 45-degree angle. 3. Push the card gently downwards and fasten it with a screw.
- Page 22 Getting Started h Installing WiFi/Bluetooth Card 1. Locate the screws that secure the system rear cover. Unscrew them and keep them for later use. 2. Pull the rear cover carefully upwards and set it aside for later use. 3. Locate the Mini-PCIe slot.
- Page 23 MS-9A91 4. Remove the Mini-PCIe card screw preinstalled on the motherboard. 5. Insert the WiFi card into the slot at a 45-degree angle. 6. Push the card gently downwards and fasten it with a screw.
- Page 24 Getting Started 7. Connect one end of the antenna cable to the WiFi card and the other end to the system I/O panel. 8. Locate the antenna connector on the system I/O panel and fasten the antenna to the connector. Adjust the antenna’s angle and height for better signal reception.
- Page 25 MS-9A91 h Installing Hard Disk Drive 1. Unscrew the HDD compartment. 2. Remove the compartment cover. 3. Locate the levers and the retaining lip of the HDD tray.
- Page 26 Getting Started 4. Gently push the tray levers inwards and carefully pull the retaining lip to release the HDD tray out of the bay. 5. Fit the HDD into the tray. Be sure to put the HDD in the correct orientation and with screw holes aligned.
- Page 27 MS-9A91 7. Insert and hide the retaining lip into the gap. 8. Screw the HDD compartment to complete the installation. 2-11...
-
Page 28: Mounting The System
Getting Started Mounting the System h Panel Mounting 2-12... - Page 29 MS-9A91 h Recommended Opening Size on the Wall Important The recommended maximum wall thickness is 10mm. A wall thickness more than 10mm will not mount stably. 2-13...
-
Page 30: Vesa Mounting
Getting Started h VESA Mounting 2-14...
