Summary of Contents for Caramia DARREN BUNK BED
- Page 1 DARREN BUNK BED DARREN LIT SUPERPOSÉ ASSEMBLY INSTRUCTIONS INSTRUCTIONS D’ASSEMBLAGE 839 Central Parkway West,Mississauga,Ontario,Canada L5C 2V9,Phone:905 361-1970 Fax:905 361-1969 Toll Free: 1-877-728-0342 www.caramiafurniture.com...
- Page 2 DARREN BUNK BED Assembly Instructions Step 1 4 pcs Wood dowel (10x40) 8 pcs 8 pcs 28 pcs 1 pc Allen head bolt M6x80mm Barrel nut (M6x13) Wood screw #8x1" Allen key Allen head boulon DeCanon2 Visa bois Clés Allen...
- Page 3 Step 2 4 pcs 12 pcs 8 pcs Allen head bolt M6x60mm Allen head bolt M6x40mm Allen head boulon Wood dowel (10x40) Allen head boulon 8 pcs 8 pcs 28 pcs 1 pc Allen head bolt M6x80mm Barrel nut (M6x13) Wood screw #8x1"...
- Page 4 Step 3 4 pcs Metal pin D12x100mm Brocheme'taux...
-
Page 5: Hardware List
Hardware List Liste de matérial 16 pcs 8 pcs Allen head bolt M6x80mm Allen head bolt M6x60mm Allen head boulon Allen head boulon 4 pcs 16 pcs Barrel nut (M6x13) Metal pin D12x100mm DeCanon2 Brocheme'taux 56 pcs 1 pc 8 pcs 12 pcs Wood screw #8x1"... -
Page 6: Component List
Liste due pièces Component List 2 pcs 1 pc 1 pc INSIDE LEFT INSIDE RIGHT Upper foot board Upper head board Lower bed end Pied de lit (Haut) Tete de lit (Haut) Base du lit 4 pcs 4 pcs 2 pcs Upper front guardrail Garde de sécurité...
