Pavone Sistemi

pesatura elettronica industriale

TESTER 1008

for checking simultaneously a weighing system with up to 4 load cells

Pavone Sistemi

pesatura elettronica industriale

USER MANUAL

Calibrator and mV/V signal simulator

Software version P28901

Table of Contents

Need help?

Do you have a question about the 1008 and is the answer not in the manual?

Questions and answers

Summary of Contents for Pavone Sistemi 1008

Page 1 Pavone Sistemi pesatura elettronica industriale USER MANUAL TESTER 1008 for checking simultaneously a weighing system with up to 4 load cells Calibrator and mV/V signal simulator Software version P28901 Pavone Sistemi pesatura elettronica industriale...
Page 2 Page II...
Page 3: Table Of Contents
INDEX Technical Specifications ................Page Connection Sub-D 25 poles ................Page Tester: Switch ON ..................Page Signal Detection ..................Page Tester Functions ................... Page Display ...................... Page Tester Functions ................... Page Tester Functions: Autotare ................Page Tester: Calibrator Functions ................Page 11-12 Main Menu ....................
Page 4: Technical Specifications
TECHNICAL SPECIFICATIONS Power Supply: 4 x 1,5V Alkaline Batteries or NiMh 1.2V rechargeables Consuption: Max. 170 mA (Max. Light, 4 load cells of 350 Ohm) Operating Temperature: -10°C ÷ +50°C Storage Temperature: -20°C ÷ +70°C Display: LCD graphic monochrom. 4” (240 x 128 pixels) Keyboard: Touch panel + Swtich On button Dimensions:...
Page 5 SUB-D 25 POLES CONNECTION Page 3...
Page 6: Tester Switch On
TESTER SWITCH ON The LC Tester1008 shows the following display for about 2 seconds where Firmware and Software Rev. are displayed. Then, select the number of load cells connected to the junction box mod. CGS4C -CEM4C (or other) and confirm with “V” key. Page 4...
Page 7: Signal Detection
SIGNALS DETECTION The LC Tester 1008 automatically detects the input impedance values of the load cells connected, choosing among the 4 available values “ 350Ω, 700Ω, 1000Ω e 2000Ω”. The detected values can all be changed if the load cell impedance is different from the 4 available values.
Page 8: Tester Functions
TESTER FUNCTIONS The LC Tester 1008 allows the simultaneous display of the “mV / V” signal of each load cell, of the weight “Kg ..gr..t..lb..N..KN”, of the percentage of the single load “ % FS “ and their distribution”% “.
Page 9: Display
Change of Display Key CALIBRATOR. Access Menu Key The displayed “squared boxes” depend on the number of load cells selected when powering on the LC Tester 1008. The change of the displayed values determines the display of the following alternative screens: Page 7...
Page 10: Tester Functions
“Net and setting the new value. When Weight”, resetting the weight rebooting, the values calculated values, the load percentage and by the LC Tester 1008 tester are the distribution percentage. restored. Pressing again it restores the gross weight function.
Page 11 TESTER FUNCTIONS In order to enable peak and hold functions, press impulsively on the squared box of the “Gross Weight and Signal (mV / V)” display. Note: Peak function only activates from the “Gross Weight and Signal” display. The value on the left correspon- The pressure, for about 2 secon- ds to the actual weight of the ds, of one of the four squared...
Page 12: Tester Functions: Autotare
TESTER FUNCTIONS: AUTOTARE The Autotare function activates by pressing the display in the highlighted area By pressing the highlighted area again the gross weight function is restored and the autotare per- formed is cancelled. Page 10...
Page 13: Tester: Calibrator Functions
TESTER: CALIBRATOR FUNCTIONS Suitable for weighing instruments with load cells excitation from +/-3V to +/-15V Reading and Display of Indicator power supply. The display allows a complete and clear visualization the signals and their simulated gross or net weight. Clock and Batteries CALIBRATOR Function active Status Increment Signal Key...
Page 14 Key the performed Autotare is cancelled and in the box “weight” it is displayed “Gross Weight”. The LC Tester 1008 simulates signals espressed in mV/V and generates the weight. Note: The correct display of the weight generated, assumes that the parameters WEIGHING DATA: ...
Page 15: Main Menu
LC Tester 1008. SET UP MENU: here the LC Tester 1008 operation parameters must be set. * LCD CONTRAST and LCD BRIGHTNESS: Manual adjustment of the LCD contrast and LCD brightness (to reduce the batteries consumption).
Page 16 * AUTO – SWITCH OFF: Selection of the auto-switch off after a non-operative while (OFF, 3 MIN, 5 MIN, 10 MIN) * DATE/TIME ADJUSTMENT: Manual adjustment of the clock and calendar. By selection of is possible to set date and time. * BAUD RATE RS232: Selection of the default values from 1200 to 115200 bit/sec.
Page 17: Instrument Files Menu
Activate the download / upload function of the connected indicator. The confirmation key starts the receiving phase from the LC Tester 1008. The message “File Received “ confirms the correct execution of the transfer. The “Error” message is displayed if there are errors in the transfer.
Page 18: Configuration Files Menu
CONFIGURATION FILES MENU CONFIGURATION FILES: Management of the transmission and storage of the configuration files set into the LC Tester 1008. The files are stored in the folder (: \ CONFIG). The file extension is .csv. Stored parameters are: Number of the Load Cells, Measurement Unit, Division Value, Load Cell Capa- city, Load Cell Sensitivity, Capacity of the System, Zero Signals, FS Signals, Sample Weight.
Page 19 Data exchange mode with DAT1400 with NFC option. When receiving or transferring the file using NFC, place the LC Tester 1008 aerial, located in the back of the container above the batteries compartment, close to that of the instrument. When the LC Tester 1008 has established the communication with the instrument, the word “Reading in progress”...
Page 20: Management From Pc
FILE MANAGEMENT FROM PC File management functions (erasing, renaming, etc.) can only be performed from a PC via USB con- nection (ABC cable). The PC will recognize the LC Tester 1008 as a USB remote disk. There are two folders inside of it: “CONFIG”...
Page 21 Pavone Sistemi pesatura elettronica industriale Certifications: Via Tiberio Bianchi, 11/13/15 - 20863 Concorezzo (MB) ITALIA - Telephone: 039 9162656 (6 lines) - Fax: 039 9162675 E-mail: pavone@pavonesistemi.it...
