Summary of Contents for Nyle Systems L200 Series
- Page 1 User Manual L200 Series © Nyle Systems LLC L200 Manual Version 3.1 Nyle Systems www.nyle.com 12 Stevens Rd info@nyle.com Brewer, ME 04412 800-777-6953...
- Page 3 Nyle Systems makes no warranty as to the fitness of the equipment for a particular use and shall not be liable for any direct, indirect or consequential damages in conjunction with this contract and/or the use of its equipment.
-
Page 4: Table Of Contents
Table of Contents Safety Guidelines ........................................1 Precautions ..........................................1 Electrical Grounding......................................... 1 Your Kiln ............................................2 How your Dehumidification Kiln Works ................................2 Floors ............................................. 2 Ceilings ............................................2 Doors.............................................. 2 Construction Guidelines ......................................3 Equipment Installation ......................................4 Figure 1-1 Chamber Plan ...................................... - Page 5 Figure 4-2 Power Vent ......................................44 Figure 4-3 Fan Kit ........................................45 Figure 4-4 L200M Serial Interface ..................................46 Figure 4-5 Spray System Kit ....................................47 The Nyle Systems Kiln Store ....................................48 Maintenance, Reference Diagrams and Warranty ............................49 General Maintenance for L200 ...................................49 Air Inlet Filters ...........................................49 Refrigerant Charging Procedure L200 ................................49...
- Page 6 Service Log Issue Description Date Servicer...
-
Page 7: Safety Guidelines
Read through entire manual before installing, operating, or servicing this unit. Failure to follow any steps or guidelines could result in personal injury, death, destruction of property or may cause the unit to become inoperable. This manual must be kept with the unit at all times. Safety Guidelines Refrigerant! Precautions... -
Page 8: Your Kiln
The dehumidification systems are installed in Your Kiln insulated chambers, usually built from standard construction materials. Details on construction can How your Dehumidification Kiln Works be found elsewhere in this manual or on drawings Please read through carefully as some options provided by Nyle. -
Page 9: Construction Guidelines
If you want to use spray foam insulation, urethane All installed doors must: based only applied at 2.2lb/cu ft. Fiberglass is never • Be built to construction guidelines. However they recommended. may be lightened by increasing the stud spacing and using 3/8”... -
Page 10: Equipment Installation
Step 10: Seal holes after wires are installed to keep Equipment Installation moisture from the control box. Seal the holes in the kiln wall. Please reference figures 1-1,2,3,4 and 5 for more information on installation. Step 11: Install the fans in locations over the lumber see figures 1-1,2,3,4 and 5 as a reference. -
Page 11: Figure 1-1 Chamber Plan
Figure 1-1 Chamber Plan... -
Page 12: Figure 1-2 Kiln Chamber Section C
Figure 1-2 Kiln Chamber Section C... -
Page 13: Figure 1-3 Kiln Chamber Section D
Figure 1-3 Kiln Chamber Section D... -
Page 14: Figure 1-4 Kiln Chamber Recommended Dimensions
Figure 1-4 Kiln Chamber Recommended Dimensions... -
Page 15: Figure 1-5 Kiln Chamber Wall Details
Figure 1-5 Kiln Chamber Wall Details... -
Page 16: Figure 1-6 Kiln Chamber Front Elevation
Figure 1-6 Kiln Chamber Front Elevation... -
Page 17: Figure 1-7 Kiln Chamber Door Framing
Figure 1-7 Kiln Chamber Door Framing... -
Page 18: Figure 1-8 Kiln Chamber Door Section E
Figure 1-8 Kiln Chamber Door Section E... -
Page 19: Figure 1-9 Kiln Chamber Door Section F
Figure 1-9 Kiln Chamber Door Section F... -
Page 20: Figure 1-10 Deflectors And Baffles
Figure 1-10 Deflectors and Baffles FAN WALL TOP BAFFLE SIDE BAFFLE SIDE BAFFLE BLOCK AIR GAP STACKING & BAFFLING CLOSE ALL LARGE AIR GAPS SO THAT AIR CAN ONLY PASS THROUGH THE STICKER SPACE CAREFULLY ALIGN STICKERS VERTICALLY HANGED BAFFLE FROM FANWALL TO FRONT EDGE OF LUMBER STACK TITLE DEFLECTORS AND BAFFLES CUSTOMER... -
Page 21: Figure 1-11 Equipment Front
Figure 1-11 Equipment Front... -
Page 22: Figure 1-12 Equipment Back
Figure 1-12 Equipment Back... -
Page 23: Figure 1-13 Fan Diagram
Figure 1-13 Fan Diagram CARRIAGE BOLT FAN HOUSING 1/3 HP MOTOR PROPELLOR SPACER NOTE: HUB FACES AWAY FROM MOTOR 1. MOUNT MOTOR ON BASE USING SPACERS, BOLTS AND NUTS PROVIDED 2.PLACE FAN ON MOTOR SHAFT SO THAT ONE SCREW SET MEETS THE FLAT OF THE SHAFT. -
Page 24: Wet And Dry Bulb, Controller Installation And Use
kiln controller as well. This setting controls the Wet and Dry Bulb, Controller Installation and Use kiln compressor and spray system which will be automatically adjusted to accommodate the desired Sensor Technology WBT. Every Nyle Dehumidification Dry Kiln System Example: If the WBT falls below the set parameter measures and regulates internal kiln conditions the system will turn on the spray system. -
Page 25: L200S Kiln Controller
Wet Bulb Installation L200S Kiln Controller The wet bulb is mounted in a bracket. Mount the The L-Series kiln controller is set up like a modern, bracket on the wall at a convenient height, roughly 4 microprocessor based, electronic circuit which feet (1.2m) off the floor is ideal so that it is receiving assures an exact measurement of wood moisture air flow from the circulating fans. -
Page 26: Using L200S
To set the next parameters press the same key again, Using L200S for changing the values use the up and down arrow keys. To turn on the controller turn the system switch to the on position. The controller will exit from the set-up mode after the setting of the last parameter or after 10 seconds At power-on time, the instrument model and without any activity on the keyboard. -
Page 27: Alarm Conditions / Messages
Alarm Conditions / Messages L-SERIES can signal some faults that may occur to the temperature probes. When a fault is detected, an error message is displayed instead of the temperature value of the faulted probe. When this occurs the controller cannot work properly, after about a minute, all the output relays will turn off (safety condition) and a signaling buzzer starts. -
Page 28: Figure 2-4 Wiring
Figure 2-4 Wiring Function NEUT RA L PHASE Wet Bulb N.C. Temperature COM MON Probe SPRAYE RS Dry Bulb HEATER ON Temperature HEATER OFF Probe VENT ON VENT OFF RS485 (Optional) COM PRESS. Rx/Tx+ N.C. Rx/Tx- Rx/Tx - Power Supply and Rx/Tx + Output Compressor... -
Page 29: Technical Specifications
Technical Specifications 230Vac 50/60Hz ± 20% Power supply 120Vac 50/60Hz ± 20% Absorption Working Temperature 0/+40˚C (32/104˚F) Temperature Measuring 0-99˚C (32/210˚F) Range Temperature Measuring 0.1˚ Resolution Temperature Probe NTC Thermistor 4 (Heating, Spray, Vent, Relay Outputs Compressor) Relay Contact Ratings 250Vc -5A (Resistive Load) Internal Fuse Ratings 5 x 20mm5A Fast... -
Page 30: L200M Kiln Controller
Figure 2-6 Wet Bulb L200M Kiln Controller The L200M kiln controller is based on a modern, microprocessor based, electronic circuit which assures an exact measurement of wood moisture content, with automatic adjustment of kiln temperature, without need of any regulation by the user and without using any correction table for wood temperature, because all corrections are automatically made by the microprocessor. -
Page 31: Timber Probes
Timber Probes Figure 2-8 Incorrect Probe Placement L200M controller measures the wood moisture content by referring to its electrical resistance. Therefore, it is necessary to deeply fix timber probes into sample boards. The probes are connected by cables to the panel jacks on the controller, allowing them to provide accurate information directly to the system. -
Page 32: Power On
To access the configuration mode, press “Select” key: Power On the first parameter setting screen will appear. To turn on the controller turn the system switch to To set the next parameters press the same key again, the on position. for changing the values using the up and down arrow keys. -
Page 33: Alarm Conditions / Messages
7. Final moisture (0% to 30%) check carefully the connection cable and, if required, replace it with a new one with the same Screen Appearance: Configuration 7 Final Moist xx characteristics. This is the final timber moisture to be reached at the end of the cycle. -
Page 34: Figure 2-10 Table Of Wood Groups By Species
Figure 2-10 Table of Wood Groups by Species... -
Page 35: Figure 2-11 Wiring For L200M
Figure 2-11 Wiring for L200M Function Probe 1 NEUT RA L Probe 2 PHASE Probe 3 Probe 4 N.C. Wet Bulb COM MON Temperature SPRAYE RS Probe HEATER ON Dry Bulb HEATER OFF Temperature Probe VENT ON Earth VENT OFF COM PRESS. -
Page 36: Figure 2-12 Technical Specifications
Figure 2-12 Technical Specifications 230Vac 50/60Hz ± 20% Power supply 120Vac 50/60Hz ± 20% Absorption Working Temperature 0/+40˚C (32/104˚F) Temperature Measuring 0-99˚C (32/210˚F) Range Temperature Measuring 0.1˚ Resolution Temperature Probe NTC Thermistor Timber Moisture 8% - 90% at 25˚C Measuring Range Number of Probes 4 (Heating, Spray, Vent, Relay Outputs... -
Page 37: Drying Lumber
• If the load supports are thicker than normal Drying Lumber stickers, the extra space should be blocked with a narrow board or lath. Loading the Drying Chamber • Close off any large openings that will let air go The USDA Dry Kiln Operators Manual describes, around the lumber. -
Page 38: Moisture Removal Rates
The drying rates in Table 1 are the rates to follow Moisture Removal Rates when first using the machine. These rates can be safely exceeded by an additional 50% (i.e., 1.0% can Moisture Removal Rate Per Day (Maximum) be raised to 1.5% and 3.3% can be increased to almost These removal rates are estimates only. -
Page 39: Figure 3-4 Drying Schedules
Figure 3-4 Drying Schedules Normal Schedule Alternate Schedule Moisture Content Dry Bulb Wet Bulb Dry Bulb Wet Bulb Group 2 Above 45% 90˚F 85˚F 100˚F 97˚F 45% - 35% 100˚F 87˚F 105˚F 93˚F 35% - 25% 110˚F 96˚F 110˚F 96˚F 25% - Final 120˚F 90˚F... -
Page 40: Figure 3-5 Drying Rates (Metric)
Figure 3-5 Drying Rates (Metric) Oven Dry Avg. Green Kg Water Max MC% Species Weight Kg Green MC Weight Kg Per % MC Loss/day / M3 / M3 Cedar, Eastern White 315.6 609.2 7.27 Fir, Balsam 347.8 7.73 Hemlock, Eastern 432.2 911.6 Larch, Eastern... -
Page 41: Figure 3-6 Drying Rates (North American Measure)
Figure 3-6 Drying Rates (North American Measure) Oven Dry Avg. Green # Water Max MC% Species Weight Green MC Weight Loss/ day #/MBF #/MBF % MC Cedar, Eastern White 1578 3046 Fir, Balsam 1739 3790 Hemlock, Eastern 2161 4558 Larch, Eastern 2532 3849 Pine, Red (Norway) -
Page 42: Kiln Sample Boards
Step 4: Cut two 1” sections off each end of the Kiln Sample Boards samples, and mark them with the number of the board they came from. To measure moisture content on a daily basis, it is best to use sample boards. Moisture meters Example: the two sections that came from sample are not accurate enough for most hardwood dry board 3 would be labeled 3A and 3B. - Page 43 constant weight is achieved. Example: Two 1” sections are cut from 30” sample board 1, and labeled 1A and 1B. They are weighed Oven: Place the 1” section in an oven at 215ºF on a balance, and the weights are: A=2.5g and (101ºC) until the section stops losing weight, usually B=2.3g.
-
Page 44: Drying Rate Index (Dri)
The Drying Rate Index is a relative number. For Drying Rate Index (DRI) example: The dry kiln industry has never had a method of A kiln is operating at 120º F. dry bulb and 110º F. wet predicting drying rates. This is remarkable as one bulb, that means the depression is: main reason for having a kiln is to bring about 10º... - Page 45 cases, were this pressed to an extreme, it may make the surface shrink too much so that factor should be considered. The best way to use the drying chart is to check the kiln each day. Calculate the moisture loss and then adjust the kiln temperature and humidity each day to achieve the drying rate desired.
-
Page 46: Figure 3-7 Nyle Drying Chart
Figure 3-7 Nyle Drying Chart... -
Page 47: Figure 3-8 Nyle Drying Chart
Figure 3-8 Nyle Drying Chart... -
Page 48: Drying Tips
• Every detail is important when drying lumber. Make Drying Tips sure that you are following operation and safety guidelines. Cutting corners can ruin your product, • Fresh cut lumber drys better and is less likely to be damage your unit, or even cause injury. damaged during the drying process. -
Page 49: Accessories
Powered Vent Accessory Kit gaining access to the compressor and terminal strip. Securely connect the control cable to the If desired Nyle Systems offers optional Powered Vent dehumidifier. Note that each wire is marked with Accessory Kits. These would replace standard vents the terminal number to which it is to be connected. -
Page 50: Figure 4-2 Power Vent
Figure 4-1 Power Vent Figure 4-2 Power Vent Wiring Diagram MAIN TERMINAL EXHAUST FAN MOTOR STRIP IN L200 (220V) CONTROL BOX WIRING DIAGRAM FOR POWER VENT KIT 240V L200H / L200M / DH4000... -
Page 51: Figure 4-3 Fan Kit
Figure 4-3 Fan Kit CARRIAGE BOLT FAN HOUSING 1/3 HP MOTOR PROPELLOR SPACER NOTE: HUB FACES AWAY FROM MOTOR 1. MOUNT MOTOR ON BASE USING SPACERS, BOLTS AND NUTS PROVIDED 2.PLACE FAN ON MOTOR SHAFT SO THAT ONE SCREW SET MEETS THE FLAT OF THE SHAFT. -
Page 52: Figure 4-4 L200M Serial Interface
Figure 4-4 L200M Serial Interface L200M controller can be supplied complete with a serial interface for PC connection, in order to produce reports of the drying cycles. The PC must be equipped with an electrically insulated RS485 COM port adaptor. The supported operative systems are WindowsXP®, VISTA® or Windows7®; the PC must also have .NET 3.5 framework installed and the L200 software kit. -
Page 53: Figure 4-5 Spray System Kit
Figure 4-5 Spray System Kit Although not standard on Nyle DH Kilns you may choose to add on this optional Spray System Kit which will provide extra control when drying. The Sprayers are designed to be automatically activated by the system when needed and help with regulating the relative humidity within the kiln chamber. -
Page 54: The Nyle Systems Kiln Store
The Nyle Systems Kiln Store Nyle Systems likes to be there for our clients whether they have just bought a new kiln or if they have owned a Nyle kiln for years. It is because of this that we try to make replacement parts easily accessible right online in our Kiln Store. -
Page 55: Maintenance, Reference Diagrams And Warranty
Maintenance, Reference Diagrams and Warranty Refrigerant Charging Procedure L200 General Maintenance for L200 The refrigeration system is a closed loop system with its own lubrication oil supply. Nyle uses only The L200 is designed for continuous duty, with little the best trade practices when assembling these maintenance. -
Page 56: Controller Factory Setting
Overheating threshold (0 to 20° C/F) Controller Factory Setting Screen appearance: SETUP 4 These setting are programmed by Nyle before Hy VENT 2° F unit ships, and are provided for reference only. Please do not attempt to adjust these settings It defines a threshold above the DB temperature without consulting Nyle service first. -
Page 57: Figure 5-1 Kiln Cart Layout
Figure 5-1 Kiln Cart Layout Figure 5-2 Kiln Cart Assembly... -
Page 58: Figure 5-3 Door Gasket Installation
Figure 5-3 Door Gasket Installation GASKETS AND DOOR KITS AVAILABLE FROM NYLE... -
Page 59: Figure 5-4 L200S Control Wiring
Figure 5-4 L200S Control Wiring 240/1/60 BLOWER MOTOR SYSTEM SWITCH 1/3 HP CONTROL L-SERIES WET BULB TEMP. CTRL. DRY BULB TEMP. CTRL. HT. SWITCH H.C.C. A.O.T.C. COMP. SWITCH H.P. L.P. C.C.C. T.D.R. C.C.H. HEAT CONTACTOR HEAT CONTACTOR FUSIBLE LINK HEATER 4KW COMPRESSOR COMP. -
Page 60: Figure 5-5 L200M Power And Control Wiring
Figure 5-5 L200M Power and Control Wiring 240/1/60 BLOWER MOTOR SYSTEM SWITCH 1/3 HP CONTROL L200M D W 4 3 2 1 WOOD PROBE 1 WOOD PROBE 2 WOOD PROBE 3 WOOD PROBE 4 WET BULB TEMP. CTRL. DRY BULB TEMP. CTRL. HT. -
Page 61: Figure 5-6 L200 Wiring
Figure 5-6 L200 Wiring BLOWER MOTOR SYSTEM SWITCH TEMP. CONTROL 100.0 1 AMP TEMP SENSOR H.C.C. AOTC T.C.H C.C.C. H.P. L.P. T.C.ALM LT. BLU C.C.H. TITLE L200 Wiring Diagram CUSTOMER 12 Stevens Road Brewer, Maine 04412 Reference Manual Tel: 1-207-989-4335 Int'l: 1-800-777-6953 Fax: 1-207-989-1101 Email: info@nyle.com DRAWN BY DWG FILE NAME... -
Page 62: Appendix
EMC-EQUILIBRIUM MOISTURE CONTENT: This is Appendix the average moisture content all wood will reach eventually when exposed to these conditions. Terminology Example: At a dry bulb of 115º F. and a wet bulb DRY BULB: The temperature as measured by a of 101º... -
Page 63: Notes
Notes...
