Page 1 Rhein Tech Laboratories Client: OSLINK Sp. z o.o. 360 Herndon Parkway Model: OSBRIDGE 5GXi Suite 1400 FCC ID: UEV-5GXI Herndon, VA 20170 Standard: FCC 15.247 http://www.rheintech.com Report #: 2007118 Appendix H: Manual Please see the following pages. Page 47 of 64...
Page 2: Configuration Manual
OSBRiDGE 5XLi/5GXi/5GXi-HP Configuration Manual Firmware 3.30R...
Page 3 Caution: Exposure to Radio Frequency Radiation To comply with the FCC radio frequency exposure requirements the separation between this device built in antenna and any person's body (including hands, wrists, feet and ankles) must be atleast 15 inch (38 centimeter). Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.
Page 4 1. Initial setup and configuration. OSBRiDGE 5XLi/5GXi devices are configurable via WWW interface. Each device uses following default settings: IP Address: 192.168.1.251 Subnet Mask: 255.255.255.0 Login: admin Password: public The initial login screen looks as follows: Please enter username and password, then press submit to log into the device.
Page 5 2. System Information System information tab shows information about system hardware and operational parameters:...
Page 6: Connection Information
Polling Client - Client for OSBRiDGE 5G device using OSBRiDGE proprietary polling protocol. – AP Client - Client for OSBRiDGE 5G device operating in Access Point mode. In this mode full – MAC address passthrough is achieved between bridged ethernet segments PtP Bridge Master - Master device when configured to operate as point to point wireless –...
Page 7 – Supported Frequencies – Supported Frequencies for currently configured Regulatory Domain. Distance to the Access Point – Configured distance between OSBRiDGE 5XLi/5GXi device and the Access Point (or other Wireless Bridge) it is connecting to. IP Address – Device IP address.
Page 8 Far East & Africa – 4920 – 6100 MHz, 802.11a and 802.11a Turbo modes (236 channels). Device Name - This is the system name for easy identification of the OSBRiDGE 5XLi/5GXi unit. ESSID - An ESSID is the unique name shared among all peers in your wireless network. The name must be identical for all devices and points attempting to connect to the same network.
Page 9 AP Client – This mode allows connection to OSBRiDGE 5G device and full MAC address passthrough in Bridge mode. PtP Bridge Master – This mode allows creation of a point to point connection with another OSBRiDGE 5XLi/5GXi or OSBRiDGE 5Gi device operating in Slave (or Client) mode.
Page 10 Currently supported PPPoE authorization types are CHAP, PAP, MSCHAP and MPPE. Watchdog – If enabled then OSBRiDGE 5XLi/5GXi device will send 3 ICMP Echo Requests to the configured IP address, each in 3 minutes interval. If there is no single ICMP Echo Reply to any of these requests, then the device will reboot itself.
Page 11 4. IP Settings Bridge Mode Device IP – Enter device IP address here. Subnet Mask – Enter network subnet mask here. Default Gateway – IP address of a router where traffic going outside of the local network will be forwarded.
Page 12 Router Mode / NAT Router Mode Wired Interface IP – Enter IP address of the wired interface here. Wired Interface Mask – Enter wired network subnet mask here. Wireless Interface IP – Enter IP address of the wireless interface here. Wireless Interface Mask –...
Page 13 Distance to the Access Point – Configure distance between OSBRiDGE 5XLi/5GXi device and the Access Point it is connecting to. Tx Power - By default, the OSBRiDGE 5XLi/5GXi transmits data at the maximum output power for the regulatory domain selected and frequency used. With Transmit Power Control (TPC), you can adjust the output power of the unit to a lower level in order to reduce interference from neighboring devices.
Page 14 6. QOS Settings When the device operates as Access Point the built-in traffic shaper allows you to set up different data flow speeds for it’s clients – In IP Bridge Mode - based on MAC Address, In IP Router Mode - based on IP Address or IP Subnetwork. Downlink –...
Page 15 Default Priority Traffic - Size that will be reserved for default priority queue from which data is sent after the High Priority queue is empty. Default Priority traffic is defined as traffic originating from well known services (http, smp, pop3, ssh etc.) which should be prioritized but is not as latency dependent as high priority traffic.
Page 16 There are two tables shown on the configuration screen. "Ethernet" table shows currently defined firewall rules for the wired interface of the OSBRiDGE 5XLi/5GXi device. "Wireless" table shows currently defined rules for the wireless interface. You can delete existing firewall rule by selecting "Delete"...
Page 17 Destination Port - Destination port of the packet to be matched. Use "*" to match any destination port. Define New Rule (IP Router Mode): Interface – Select the incoming interface the rule should apply to. Choose either Ethernet or Wireless interface. Action –...
Page 18 8. DHCP Settings...
Page 19 Depending on which DHCP opton is enabled (or disabled) on the General Settings page, this page will show appropriate information. If DHCP server is enabled then you can configure it’s operational parameters on this page. Server Enabled on Interface – Choose the interface the DHCP server should listen for requests on.
Page 20 9. Port Forwarding When the device is operating in Access Point Client and IP Router/NAT Router mode this menu will let you configure port forwarding from external (WLAN) interface to the host available on the internal (ethernet) interface. Each forwarding rule consists of: Application - Description of the application the rule applies to.
Page 21 10. Device Settings Use this screen to change password which is used to access and configure the device.
Page 22 11. Syslog Settings This option allows device events logging to remote Syslog server. Syslog Server IP - IP Address of the computer where Syslog server is running. Syslog Server Port - Port the Syslog server is listening on. Log Messages - Enable or disable logging for specific events: Device Startup - save an event when the device has started.
Page 23 12. Interface Status This page shows statistical information about packets that traversed the bridge/router. In IP Bridge mode there is also Bridge Learn Table shown, in IP Router mode there is device ARP table shown, containing it’s neighbours MAC addresses. Currently active DHCP leases are also displayed here.
Page 24 13. Services Site Survey – Allows to see other Access Points in range. Reset Default – Allows to reset device to factory default settings. Traceroute – This command is used to determine the route taken by packets across an IP network.
Page 25 14. Firmware Upgrade This page allows you to upgrade the device firmware. It is recommended to upgrade firmware only to newer version than the one currently installed in the device. Please always remember to reboot the device first before you proceed with firmware upgrade.
Page 26 15. Load Configuration You can use this option to save current device configuration to file.
Page 27 16. Save Configuration You can use this option to load device configuration from file.
Page 28 17. SNMP Support OSBRiDGE 5XL(i) devices support SNMP monitoring feature and appropriate .mib file is provided with each firmware release. SNMP community string required for monitoring is always configured to be the same as admin user password used for device configuration.
Page 29 18. TFTP Firmware upgrade Each OSBRiDGE device allows firmware upgrade via TFTP. From the Windows DOS box you need to enter following command: X:\>tftp -i -s 192.168.1.251 PUT OSBRiDGE_5XLi_3.30R2.bin admin_public WinAgents TFTP Client version 1.3 Copyright (c)2004-2005 by Tandem Systems,Ltd.
Page 30 CLI allows to perform device mainteance using telnet session: [root@gw root]# telnet 192.168.1.7 Trying 192.168.1.7... Connected to 192.168.1.7 (192.168.1.7). Escape character is '^]'. Login: admin Password: ******** Osbridge 5Xli - CLI Use "help" for list of available commands > help Available commands: traceroute system survey...
Page 31 20. Resetting device to default settings. In order to reset OSBRiDGE device to factory default settings you need to use OSReset software available for download at http://www.osbridge.com/software.php. OSReset will locate any compatible OSBRiDGE device regardless of its IP address located on the same physical subnetwork with the computer it is running on.
Page 32 20. Resetting device to default settings. In order to reset OSBRiDGE device to factory default settings you need to use OSReset software available for download at http://www.osbridge.com/software.php. OSReset will locate any compatible OSBRiDGE device regardless of its IP address located on the same physical subnetwork with the computer it is running on.
