AP700 APP

Android Tablet User Manual

Connection

Download App

Step

Android operating system version 4.0 or above is required.

Below resolutions are supported: 1024 x 600, 1024 x 768, 1280 x 720, 1280 x 800,

1920 x 1200, 2048 x 1536

Open "App Store", Search for and Download "Kessil WiFi Controller".

Connect Lamp (Follow the instructions on Android Tablet App)

Step

Make sure the AP700 is connected to a

wall outlet through power adapter.

Touch the

button to turn on the AP700.

Press

and

simultaneously to turn on

WiFi. WiFi Indicator will flash.

Open " Kessil WiFi Controller " and click "

Add New Lamp ".

Connect Direct to AP700

1 Make sure the AP700 WiFi indicator is flashing and press "Next".

2 Exit App and open "Settings"> "Wi-Fi", then connect to AP700 (WiFi

SSID:Kessil_KDxxxxxxxx) (WiFi SSID Label can be found on AP700).

* Make sure it is connected and the WiFi fan signal at top right corner appear.

Go back to the app and press "Next"

3 Create own password for the AP700, then press "Next".

4 Exit app and open "Settings" > "WiFi". Connect to AP700 (WiFi SSID:Kessil_KDxxxxxxx)

and enter the password. Return to app and press "Next".

* Make sure it is connected and the WiFi fan signal at top right corner appear.

5 If only connecting one AP700, press "Done". If connecting more than one AP700, press

"Set Next Lamp"

Repeat 1. and 2.

ii Make sure the first AP700's WiFi SSID is shown and password matches.

iii Press "Next".

iv Exit app and open "Settings" > "Wi-Fi". Connect to first AP700.

* Make sure it is connected and the WiFi fan signal at top right corner appear.

v Press "Next" and press "Done" if you have connected all AP700(s). Press "Add

Another AP700" and repeat steps if you have more to connect.

6 Wait for around 30 seconds to load data (Additional lamps may require longer loading times).

7 When lamp interface appear(s), the AP700(s) can be controlled via app. If no new lamp interface appears, press

at the top right corner).

POWER

WiFi

WiFi SSID : Kessil_KDxxxxxxxx

(WiFi SSID Label can be found on AP700)

Table of Contents

Need help?

Do you have a question about the AP700 APP and is the answer not in the manual?

Questions and answers

Summary of Contents for Kessil AP700 APP

Page 1 Below resolutions are supported: 1024 x 600, 1024 x 768, 1280 x 720, 1280 x 800, 1920 x 1200, 2048 x 1536 Open “App Store”, Search for and Download “Kessil WiFi Controller”. Connect Lamp (Follow the instructions on Android Tablet App)
Page 2 Use Wireless Router 1 Make sure the AP700 WiFi indicator is flashing and press “Next”. 2 Exit App and open “Settings”> “Wi-Fi”, then connect to AP700 (WiFi SSID:Kessil_KDxxxxxxxx) (WiFi SSID Label can be found on AP700). * Make sure it is connected and the WiFi fan signal at top right corner appear. Go back to the app and press “Next”...
Page 3 This can be used when adding new corals or when using Kessil LED lights for the first time. “Starting Intensity” means a proportion of the point’s intensity, e.g. if you have a point at 80% intensity, under Acclimation &...
Page 4 2 Press “Cancel” to keep data. Press kessil@kessil.com to send an email to Customer Service Team for help. Press to connect to Kessil's Facebook / Twitter / Youtube pages, to interact with other reefers, and to keep up to date on our latest news!
Page 5 Issue Remedy 1 Make sure AP700 WiFi Indicator is flashing (Press simultaneously Tablet cannot connect to AP700 to turn on WiFi). WiFi SSID/Cannot find AP700 WiFi 2 If AP700 WiFi SSID is still not found, unplug and replug power supply and SSID under WiFi network selection turn on WiFi.
