Model No. TBSC79020
Model No. TBSC79920
Table of Contents
Important Precautions . . . . . . . . . .2
Before You Begin . . . . . . . . . . . . .3
How to Set Up the Scooter . . . . . . .4
How to Operate the Scooter . . . . . .6
Troubleshooting . . . . . . . . . . . . . . .8
Part List . . . . . . . . . . . . . . . . . . . .11
Replacement Parts . . . . . . . . . . . .11
Limited Warranty . . . . . .Back Cover
CAUTION
Read all warnings and instructions
in this manual before using the
scooter. Keep this manual for future
reference.
User's Manual
Advertisement
Summary of Contents for Skoot-Eze TBSC79020
-
Page 1: Table Of Contents
Model No. TBSC79020 Model No. TBSC79920 Table of Contents Important Precautions ..2 User’s Manual Before You Begin ... . .3 How to Set Up the Scooter ..4 How to Operate the Scooter . -
Page 2: Important Precautions
Important Precautions WARNING: To reduce the risk of serious injury, read these warnings before using the scooter. 1. Read, understand, and follow all warnings and darkened conditions. instructions on the scooter and in this manual. 11. Do not allow more than one person to ride the Save this manual for future reference. -
Page 3: Before You Begin
Before You Begin Thank you for selecting the new SCOOT-EZE ™ motorized scooter. The SCOOT-EZE motorized scooter combines quiet electric power with a sturdy, compact design to provide you with comfortable motorized transportation. For your safety and benefit, carefully read all of the warnings and instructions in this manual before using the scooter. -
Page 4: How To Set Up The Scooter
How to Set Up the Scooter Follow the steps below to set up the scooter for use. Assembly requires the included tool kit. 1. See the inset photograph. Press and hold down the Upright Latch (19). While holding down the Upright Latch, fully raise the Upright (41). - Page 5 5. Make sure that the on/off key is removed from the Fuse on/off switch (see USING THE ON/OFF KEY on page 6). Unlock and open the battery cover (not shown). Locate the plastic fuse holder. See the inset photograph. Press the long tab in the center of the fuse holder, and Red Wires open the fuse holder.
-
Page 6: How To Operate The Scooter
How to Operate the Scooter Important: Read all instructions in this section before For maximum battery life, avoid leaving the on/off key using the scooter. in the ON position when the scooter is not in use. Avoid draining the batteries. It is recommended that the batter- CHARGING THE BATTERIES ies be charged after each use. - Page 7 OPERATING THE SCOOTER Using the direction switch on the right handlebar (see the photograph at the left), the scooter can be made to drive To use the scooter, first hold the handlebars securely, backward as well as forward. Press the top of the switch, step onto the deck, and sit down onto the seat.
-
Page 8: Maintenance And Troubleshooting
Maintenance and Troubleshooting Regularly check the scooter and make sure that all parts the brake Locknut are properly tightened. If the scooter does not function cable. Using Adjustment Barrel properly, follow the steps below. IMPORTANT: Always a small turn the on/off key to the “OFF” position and remove open-end Cable it before performing any of the steps below. - Page 9 Notes...
- Page 10 Notes...
-
Page 11: Part List
To order replacement parts, call toll-free 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). When ordering parts, please mention the model number of the scooter (TBSC79020 or TBSC79920) and the key number and description of the needed parts. -
Page 12: Limited Warranty
Limited Warranty ICON Health & Fitness, Inc. (ICON) warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of purchase. This warran- ty extends only to the original purchaser.
