Summary of Contents for SHERMAN+REILLY SRK15X
- Page 1 OPERATION MANUAL Serial Number SRK15X Battery-powered Crimping Tool Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. 52080067 REV 1 © 2017 Sherman + Reilly, Inc. 3/17...
-
Page 2: Table Of Contents
6,276,186, 6,401,515, and 6,718,870. Die Selection ..............11 Connector Selection ............. 11 Model X-SRK15X—FCC ID: 2AGL2X; IC ID: 20646X LCD Screen ..............12 This device complies with Part 15 of the FCC Rules and with Industry Canada licence-exempt RSS standard(s). -
Page 3: Important Safety Information
SRK15X Battery-powered Crimping Tool IMPORTANT SAFETY INFORMATION SAFETY Wear eye protection when operating ALERT or servicing this tool. SYMBOL Failure to wear eye protection could result in serious eye injury from flying debris or hydraulic oil. This symbol is used to call your attention to hazards or unsafe practices which could result in an injury or property damage. -
Page 4: Important Safety Information
SRK15X Battery-powered Crimping Tool IMPORTANT SAFETY INFORMATION Do not dispose of batteries in a fire. They will vent Do not allow anything to contact the battery fumes and may explode. terminals. Failure to observe this warning could result in severe •... -
Page 5: Identification
SRK15X Battery-powered Crimping Tool Identification 1. LED Work Light (white) 2. Die Release Button 3. Crimping Head 4. Lanyard Ring 5. Housing 6. Retract Button 7. LED Indictor (red) 8. LCD Screen 9. Battery 10. Trigger Specifications Crimping Capacities Crimping Tool Maximum Crimping Capacity Length ............19.8"... -
Page 6: Adapter Kits
SRK15X Battery-powered Crimping Tool Adapter Kits Procedure for Using Kearney PH14 Dies Procedure for Using Kearney PH2 Dies; 48824 Die Holder Kit 1. No die holder assemblies are needed. Dies fit directly into tool. 1. Install 48823 PH2 die spacer assembly into hole in top of “C”... - Page 7 SRK15X Battery-powered Crimping Tool Adapter Kits (cont’d) Procedure for Using Thomas & Betts TBM15 Dies; Procedure for Using Burndy Y46 Dies; 48788 Die Holder Kit 48820 Die Holder Kit 1. Install the upper 48789 die holder assembly in hole 1. Install the upper 48822 die holder assembly in hole in top of “C”...
-
Page 8: Setup
SRK15X Battery-powered Crimping Tool Adapter Kits (cont’d) Setup Procedure for Using 12-Ton “U” Dies; 1. Select the die set that corresponds to the size, type, 48802 Die Holder Kit and manufacturer of connector to be crimped. 1. Install the upper 48803 die holder assembly in hole 2. -
Page 9: Operation
SRK15X Battery-powered Crimping Tool Operation • Inspect tool and dies before use. Replace any • Do not use this tool for continuous use. After 30 to worn or damaged parts. A damaged or improp- 40 cycles, allow the tool to cool for 15 minutes. - Page 10 SRK15X Battery-powered Crimping Tool Operation (cont’d) Pressure Sensor 4. For a single crimp, position the connector so the crimp will be located at the center of the barrel. This tool is equipped with a pressure sensor that alerts the user of an incomplete crimp.
-
Page 11: Die Selection
SRK15X Battery-powered Crimping Tool Die Selection Refer to “Connector Selection” for brand names and model numbers of appropriate lugs as well as crimping instructions. Crimps made with this tool and KC12-type or KA12-type dies are cUL and UL classified when used with the appropriate conductor and connectors listed below. -
Page 12: Lcd Screen
SRK15X Battery-powered Crimping Tool LCD Screen This tool has an LCD screen, which displays informa- If there is no error code, cycle through the various tion about the tool. Turn on the screen by inserting the displays using the left and right buttons on either side of battery and jogging the tool. -
Page 13: Maintenance
SRK15X Battery-powered Crimping Tool Maintenance Daily Before use: 1. Inspect the tool for wear or damage, such as cracks, Wear eye protection when operating gouges, or chips. or servicing this tool. 2. Inspect the tool for damage or leaks. Failure to wear eye protection could result in serious eye injury from flying 3. -
Page 14: Troubleshooting
SRK15X Battery-powered Crimping Tool Troubleshooting Before You Begin 2. Use a nonflammable contact cleaner or pencil 1. Make sure that the battery is charged. Recheck eraser to clean the electrical contacts on the battery the battery after several minutes to make sure the and tool. - Page 15 SRK15X Battery-powered Crimping Tool Sherman + Reilly, Inc. / A Textron Company 400 West 33rd Street • Chattanooga, TN 37410 USA...
- Page 16 400 West 33rd Street • Chattanooga, TN 37410 USA Phone 800-251-7780 • 423-756-5300 423-756-2948 www.sherman-reilly.com...
