- Page 1 Series 5 soulution nature of sound 550 Phono-preamplifier User manual...
- Page 3 We understand your eagerness to get started but even though please study this manual step by step before you integrate the phono-preamplifier 550 in your High Fidelity system. This manual contains also useful tips for the optimisation of your overall HiFi-system.
- Page 4 soulution nature of sound CE-Declaration of Conformity Spemot AG declares that this product is in conformance with the following direc- tives and standards: Low Voltage Directive 2006/95/EG (EN/IEC 60065:2002) Electromagnetic Compatibility 2004/108/EG (EN 55013:2001, EN 55020:2002, EN 61000-3-2:2006, EN61000-3-3:1995) FCC-Notice Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
-
Page 5: Table Of Contents
Keep the packing for future transportations Unpacking Treat the top class surface with care Position the phono-preamplifier 550 on a stable base. Positioning Cooling air must be able to escape unrestricted. Disconnect all appliances of your system from the mains ... -
Page 6: Technical Highlights
Technical Highlights Layout The 550 phono-preamplifier is built in dual-mono layout. Both audio channels have their dedicated power supply. The audio section is physically separated from the digital circuits. Power supply The phono-preamplifier 550 has separate power supply units for the audio section as well as for its digital section. -
Page 7: Safety Advice
foreign substances or liquidity have entered the 550 the 550 has seen rain the 550 seems to malfunction the 550 has fallen to the floor or the housing is damaged Page... -
Page 8: Scope Of Delivery
Mains (A) Connect the phono-preamplifier 550 with the mains supply. Depending on the set- tings in the function PWR-MODE the 550 will change to operating condition OFF (consumption< 0.5W), wait for the LINK signal or switch-on automatically. Before disconnecting the 550 phono preamplifier from the mains you should bring it in operating condition OFF. - Page 9 A potential a hum-loop may be suppressed by the GND-LIFT function (page 12). LINK (D) The switch-on of the 550 phono preamplifier can be remote controlled through the LINK-connection. The function PWR-MODE (page 12) defines the behaviour of the 550 after switch-on.
-
Page 10: Front Side
The Power button defines the operating condition ON or OFF (red LEDs). In operat- ing condition OFF the audio circuits are completely disconnected from the outputs. Unplug your 550 from the mains before you manipulate with cables, before clean- ing, during thunder storms or before you leave for longer periods. -
Page 11: Remote Control
Phono-preamplifier User manual Remote control Button Pre-Mode CD-Mode IR-transmitter Operation until 5m distance and angel of ±45°. (2,3) Volume +/- DIM / Volume-Dim Play/Pause (5/6) Select +/- Next / Previous track Enter Function for Program-Mode (De)activates Program-Mode Mute (10) -
Page 12: Program-Mode
Program-Mode General The phono-preamplifier 550 can be adjusted to your individual setup. It is already programmed with default settings. Further programming is not mandatory. Function Push on the Prog button switches the phono- preamplifier 550 between operating-mode and pro- gramming-mode. - Page 13 Adjusts the brightness of the display 2 = medium 3 = high Pre 1, Pre 2, Defines the IR- identification of the 550. Phono, DAC The identification of the remote control has to be defined accordingly Activates the default values (bold) for all functions.
-
Page 14: Trouble Shooting
Check the cabling to preamplifier the preamplifier If you cannot identify the error please disconnect the phono-preamplifier 550 from the mains supply and contact your soulution dealer. Service If your soulution product needs service please contact your soulution dealer. For fur- ther information see www.soulution-audio.com... -
Page 15: Safety Functions
For currents > 0.2 Ampere at the output the phono- preamplifier 550 shuts down automatically. Power supply The power supply is monitored for correct operation. In case of an error the 550 gets shut down automatically. Fuse Model 220-240 V 2A/T 250V micro fuse 5x20mm... -
Page 16: Specification
soulution nature of sound Specification Specification Data General Nominal Voltage 220-240 V Power consumption 50 W Standby <0.5 W Input (IN 1...IN 2) Impedance 20 – 1’260 1 - 47 k 0 -200 pF Output Gain MM @ 1kHz 48 dB MC @ 1kHz 60 dB... - Page 17 Phono-preamplifier User manual Dimensions Page...
- Page 20 Spemot AG Industriestrasse 70 CH-4657 Dulliken www.soulution-audio.com info@soulution-audio.com soulution nature of sound part.no. 92210...
