Summary of Contents for Sunstream Wireless M5800SB-AP-60
- Page 1 MODEL M5800SB-AP-60 5.8 GHz Digital Spread Spectrum Wireless Internet Access Point Installation and Operating Instructions SUNSTREAM WIRELESS, A DIVISION OF TRANGO SYSTEMS, INC. COPYRIGHT 2001...
- Page 2 • Tighten all nuts and bolts down after the alignment is completed. 10• To help protect against potential lightning damage, use an ethernet lightning surge arrestor in line with the STP cable at the entry point to the building. Copyright © 1999 Sunstream Wireless, LLC All rights reserved.
-
Page 3: Fcc Information
1 power adapter (optional) 1 warranty card Service: If the unit ever needs repair service, contact your service provider or Sunstream Wireless distributor as appropriate for return authorization and shipping instructions. FCC Information: This device complies with Part 15 of the FCC Rules. Operation is subject to the... - Page 4 – The unit must be fixed-mounted on outdoor permanent structures with a separation distance of at least 2 meters from all persons and must not be co-located or operating in conjuction with any other antenna or transmitter. Copyright © 1999 Sunstream Wireless, LLC All rights reserved.
-
Page 5: System Description
System Description: The M5800SB-AP-60 is a broadband wireless internet access system designed for sending and receiving Ethernet based data traffic where conventional wiring is impractical or when higher connection speeds are required. The system utilizes robust spread spectrum technology to reduce susceptibility to interference. The typical access point installation consists of one or more M5800SB-AP-60 transceiver mounted outdoors and a junction box mounted indoors. - Page 6 • FIGURE 1 • Figure 1 shows installation of the transceiver on the pole. • FIGURE 2 • Figure 1 shows installation of the junction box and power adapter. Copyright © 1999 Sunstream Wireless, LLC All rights reserved.
- Page 7 Copyright © 1999 Sunstream Wireless, LLC All rights reserved.
-
Page 8: Installation
8 AWG or larger wire. For best performance, the antenna must be 15 to 20 feet above all obstacles in the line of sight to the any one subscriber unit. Copyright © 1999 Sunstream Wireless, LLC All rights reserved. - Page 9 UTP for the indoor connection to the switch or PC. 4. LED INDICATORS These LEDs indicate when a data packet is transmitted(red) or received (green). The yellow LED indicates the strength of the signal received from the base station. Copyright © 1999 Sunstream Wireless, LLC All rights reserved.
-
Page 10: Receiver Section
Grey steel pole/wall mount Connectors/Indicators RF Output: MCX for integral dual pol antenna SMA per Part 15C, 15.203. FCC Compliance: The transmitter shall comply with the following: FCC Part 15.405, 15.407 Copyright © 1999 Sunstream Wireless, LLC All rights reserved. -
Page 11: Standard Antenna
5.7 to 5.9 GHz Gain: +18 dBiL Az Beamwidth: >60 degrees El Beamwidth: >8 degrees Cross Pol: >15 dB Front/Back Ratio:>30 DB as mounted in M5800SB-AP-60 VSWR: < 2.0:1 over Bandwidth Copyright © 1999 Sunstream Wireless, LLC All rights reserved.
