Summary of Contents for Air Vent Inc. HCV-BS-AVIR
- Page 1 Apr 2016 Air Ventilation HCV Rev. 4.0En Installation & Owner’s Manual English This Manual Covers the Following Models HCV-BS-AVIR HCV-CS-AVIR Manufactured by: ClairiTech Innovations Inc. 1095 Ohio Rd. Boudreau-Ouest, NB Canada E4P 6N4...
-
Page 2: Table Of Contents
Air Ventilation Table of Contents Table of Contents ........................1 Service and Warranty ......................... 3 ........................3 USTOMER SSISTANCE ........................ 4 ONSUMER IMITED ARRANTY ............................5 NSTALLATION ..........................5 NCLUDED OMPONENTS ....................... 5 OOLS EQUIRED FOR NSTALLATION ........................... 5 NSTALLATION ACTS IMPORTANT –... - Page 3 Air Ventilation LCD M ........................16 AVIGATING THE ......................17 HANGING AXIMUM PEEDS ..........................17 HANGING PEEDS ....................18 HANGING ESIRED UMIDITY EVEL ..............18 ETTING VERRIDE IMER FOR MAXIMUM VENTILATION ....................... 19 UMIDITY REND AND ONDITIONS ..........................19 UMIDITY ONDITIONS ............................
-
Page 4: Service And Warranty
Air Ventilation Service and Warranty For Customer Assistance To aid in answering questions if you call for service or warranty purposes, please record below the model and serial number located on the side of the unit. Product Name: Model #: Date of Manufacturing: Date of Purchase: Serial #:... -
Page 5: Consumer Limited Warranty
Air Ventilation Consumer Limited Warranty ClairiTech Innovations Inc. warrants to the first consumer that this product, when shipped in its original container, will be free from defective workmanship and materials, and agrees that it will, at its discretion, either repair the defect or replace the defective Product or part thereof with a new or remanufactured equivalent at no charge to the purchaser for the period(s) set forth below. -
Page 6: Pre-Installation
Air Ventilation Pre-Installation Included Components Before installing your Avir system, make sure that you have the right model and accessories. The following items should be included in the accessory box. If parts are missing, contact our customer service at 1-888-533-1348. 1x Owner’s Manual 2x Cable Ties 1x Pipe 6”... -
Page 7: Combustion Appliance Present In Dwelling
Air Ventilation Warning!!! Combustion Appliance Present in Dwelling Read this Section Carefully With the presence of appliances evacuating air outside the building envelope (such as range hood, bathroom fan, dryer, Avir system, etc.) a negative pressure could be created inside the building. As the pressure inside the building gets lower than the barometric pressure outside, the smoke and gases from any combustion appliance (oil furnace, gas/wood stove, fireplace, etc.) may be drawn into the building rather than go out the chimney. -
Page 8: Replenishment Air To Basement From Upstairs
Air Ventilation Replenishment air to Basement from Upstairs The damp air exhausted by the Avir unit must be replaced by the warmer/drier air from the upper levels. If there is no open stairwell, the airflow is restricted from coming down; then install a passive return grille with 100 sq. -
Page 9: Installation
Air Ventilation When ducting the unit outside, no more than 3 feet of Vinyl Flex should be used. When circumstances are that a longer span is required, rigid ducting can be used from the inside of the unit to the wall. The rigid duct will improve the airflow to compensate for the additional distance the air has to flow to reach the outside. -
Page 10: Preparing The Airv Ventilation System For Installation
Air Ventilation Preparing the Air Ventilation system for Installation Measure the required Unit height. Remember that the units cannot be higher than 3” to 6” off the ground. From the inside, drill a pilot hole of approximately ¼” at the center of the proposed 6¼”... -
Page 11: Putting The Unit Together
Air Ventilation Putting the unit together For HCV-BS Only Join the two halves (Bottom section must fit inside Top section) of the HCV-BS casing together, overlapping the two pieces such as the desired height is obtained. Remove screws if necessary. NOTE: If the unit has to be shorter than 86.5”... -
Page 12: Fasten The Unit To The Wall
Air Ventilation Fasten the unit to the wall With the help of a tie wrap attach the flex pipe to the collar on the back of the unit before attaching the unit to the wall. Insert the other end of the flex pipe inside the hole in the wall. -
Page 13: Attaching The Flex, Pipe And Outside Vent
Air Ventilation Attaching the Flex, Pipe and Outside Vent Attach the vent to the 6” pipe with the ½ in screws provided. From the outside, pull the flex pipe through the 6 ¼” hole. Attach the flex to the 6” pipe with 24” tie wrap. Make sure the vent is not twisted by inserting the screws too tight and that the flaps are working properly. -
Page 14: Unit Operations
Air Ventilation Unit Operations The first time the unit runs… Anytime the Avir HCV unit is powered on (plugged into a power outlet), it will run at the last recorded speed setting (in memory) for 2 hours to allow air to circulate in house. The factory default setting when the unit is brand new is “High Speed”. -
Page 15: What Is The Dew Point
Air Ventilation What is the dew point? The dew point is one of the three environmental variables that are important when discussing the conditions in your home. Understanding the dew point will help you understand how the Avir HCV unit operates and how it will help to reduce the relative humidity (RH%) level infiltrating your home and eliminate excess humidity, while providing energy efficient ventilation for your home. -
Page 16: Lcd Display And Control Layout
Air Ventilation LCD Display and Control Layout The following sections of this operating manual refer to the user interface presented below: The user interface consists of: 1- Humidity Button 2- Override Timer Button 3- Fan Speed Button 4- Up Arrow Button 5- Down Arrow Button 6- Ok Button 7- LCD Display... -
Page 17: The Lcd Display
Air Ventilation The LCD Display The LCD Display consists of: 1- Humidity Conditions and Trending Icons 2- User Set Humidity Level 3- Override Timer 4- User Set & Operating Fan Speed 5- Low1/Low2 Fan Speed Indicator 6- Desired Max Fan Speed Indicator Navigating the LCD Menu The Avir unit has an LCD display that allows the unit to display information about its operation. -
Page 18: Changing Maximum Fan Speeds
Air Ventilation Changing Maximum Fan Speeds To change the maximum fan speeds, simply press the Fan Speed Button (The Desired Max Fan Speed Indicator will blink) and use the Up/Down Arrow Buttons to cycle through all of the different fan speeds and to select this speed simply press the Ok Button when you have the desired fan speed. -
Page 19: Changing Desired Humidity Level
Air Ventilation Changing Desired Humidity Level To change the desired humidity, simply press the Humidity Button (the humidity setting will blink) and use the Up/Down Arrow Buttons to cycle to your desired humidity level. Press the Ok Button to enter your desired humidity level. If wrong level is entered, repeat this procedure. ** Recommended humidity level for summer season is 55% and 45% for the winter season. -
Page 20: Humidity Trend And Conditions
Air Ventilation Humidity Trend and Conditions Humidity Conditions At the top of the LCD display the house with or without the 3 water drops are used to show the current humidity conditions. The image below demonstrates the different humidity conditions shown on the LCD display. -
Page 21: Positive Humidity Trend
Air Ventilation Positive Humidity Trend The water drops will blink from right to left when a decreasing humidity trend is detected, with either outline or solid drops used to indicate the condition, as above. High Humidity Conditions If the water drops are solid, this means that the unit has detected high humidity conditions. Notes on LCD display features 1) The LCD display on this unit has a built in backlight to allow for better readability in darker locations. -
Page 22: Most Common Issues
Air Ventilation Most Common Issues Mold, Mildew and Musty Smell If mold or mildew is present prior to installing an Avir unit, please have the contaminated area cleaned. Not doing so could cause Avir system to spread that mold to other locations in the basement or crawlspace. -
Page 23: Specifications
Air Ventilation Specifications Technical Data Model Amps Watts Airflow Capacity (CFM) (Sq.Ft.) HCV-BS-HDEX 0.30 2,400 HCV-CS-HDEX 0.30 3,000 All Units require a 115 VAC electrical outlet Dimensions Model Height (In.) Width (In.) Depth (In.) HCV-BS-HDEX *86.5 - 96” 11.5” 7.5” HCV-CS-HDEX *32”... -
Page 24: Schematic Of Wiring
Air Ventilation Schematic of Wiring Follow the wiring schematic below when the fan and/or controls need to be serviced or replaced.
