Summary of Contents for Discteq 352U
- Page 1 Dual HDD Clone Docking Station Discteq - 352U - User Manual...
-
Page 2: Table Of Contents
Contents Introduction Packaging Contents System Requirements Docking Function Clone Functions Important Notes Specifications Technical Support Warranty Information Compliance... -
Page 3: Introduction
If and when any relative content is changed it will be published on our website, http://www.discteq.com. Discteq strongly advise that you to make a copy your data before commencing the cloning process incase of a power failure during the cloning process. -
Page 4: Packaging Contents
Packaging Contents 1 x Discteq hard drive dock 1 x Power Adapter with UK, EU power cords 1 x e-Sata Cable 1 x A-B USB Cable 1 x Instruction Manual System Requirements Available USB 2.0 Port Available e-Sata Port Available AC Power Outlet... -
Page 5: Docking Function
Docking Function To use the dock to access external hard disks you will be required to use either the USB/ESATA lead, which will need to be plug into the laptop/computer system as illustrated below, the operating system will 3/4 seconds to recognize the device at which point it will automatically configure for use as required, this apply to All Microsoft, Macintosh and Linux operating systems. - Page 6 It is possible to dock 2 hard disk in any configuration e.g.. 2.5/3.5 2.5/2.5 3.5/3.5 externally both drives will be allocated a drive letter by the operating system, it is also possible move data between all drives listed within your operating system Once you have located the drives in the dock, power the device on, the LED’s will light up and the operating system will begin the configuration process, once this is complete you will be able to view and access the...
-
Page 7: Clone Functions
Clone Functions One Key Clone (From HDD1 to HDD2) without connecting computer. - Insert the Master hard disk to be cloned into bay 1 - Insert the new Secondary hard disk into bay 2 - Plug the power unit into the device and power up with the power switch - Press the COPY button then LED’s will light up (100%) - Press the COPY button again within 3 seconds of the first press the 100% will go out then the 25% will light flash, and... -
Page 8: Important Notes
The LED lights will flash to indicate the cloning process (25% / 50% /75% /100%) once the cloning process has reached the 100% it will change from a flashing blue light to a static blue light which will indicate that the cloning process is complete. -
Page 9: Specifications
Specifications Item 2.5”/3.5”Dual bay Docking Station Model CA-07 - 352U Dimension 180mm x 135mm x 96mm Weight: 300g External Interface USB2.0 Max Transfer Rate 480Mb/s Capacity 2TB (Max) Power Supply DC 12V/3.0A... - Page 10 Clone Function One Key Clone (from HDD1 to HDD2) without PC Compatible Type Desktops, Notebook LED Light Power LED from red to green Signal LED Blue Flashing Storage Temperature -40~70C Operating temperature 5~55C Operating Relative Humidity 5~90% Operating System Windows 98 / ME / 2000 / XP / Vista / 7 / Mac OS.9.0 or above...
-
Page 11: Technical Support
Warranty Information Discteq is covered by a one year RTB (Return To Base) warranty, Discteq warrants the materials and workmanship for the period of one calendar year from the date of purchase, during this period the product... -
Page 12: Compliance
America, compliancy certificates are available up on request. Limitation of Liability In no event shall the liability of PC Doctors Limited t/a Discteq or their officers, directors, employees or agents for any damages whether direct or indirect, special, punitive, incidental, consequential or otherwise loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of this product exceed the actual price paid for the product. - Page 14 Discteq is the trading name of PC Doctors limited based in Coventry West Midlands, we are the providers of Hard Disk Drive duplication and docking products to the UK market, The Discteq brand is solely owned by PC Doctors Limited, Our Hard Drive duplicator and docking products are developed specifically for Discteq and undergo rigorous testing to ascertain their practicality and suitability for the UK I.T Market place.
