R C E 1 0 E R A N G E TEMPERATURE CONTROLLER FOR FAN COIL UNIT 1.0.0 USER GUIDE INDEX 1.1.0 GENERAL RECOMMENDATION 1.0.0 USER GUIDE 1.1.0 GENERAL RECOMMENDATION 1. Keep this booklet in a readily accessible place for future reference. 1.2.0 Description of the unit 2.
R C E 1 0 E 1.2.0 DESCRIPTION OF UNIT CONTROLS 1.3.3 Night Function (Economy). Put the selector switch C to the Moon position. The following controls are be found on the unit (Fig. 1): The Comfort temperature is reduced by 4°C in the heating mode and increased by 3°C in the cooling mode.
R C E 1 0 E R A N G E TEMPERATURE CONTROLLER FOR FAN COIL UNIT 2.0 INSTALLER GUIDE Auxiliary output: TRIAC 0.6A max Temperature adjustment range:+15...+30°C selectable with software 2.1.0 GENERAL DESCRIPTION parameters and knob (A) +/- 5°K ...
R C E 1 0 E 2.4.0 DESCRIPTION OF INPUTS AND OUTPUTS 2.4.1 Analog inputs (External measurement sensors) Temperature sensors with the characteristics described under Technical Data may be connected to the analog inputs M13 and M14. Sensors with other characteristics may not be connected. The air and water sensors are optional.
R C E 1 0 E R A N G E TEMPERATURE CONTROLLER FOR FAN COIL UNIT No sensor, set: 2.5.0 METHODS OF CONTROL Parameter 2= 2 pipes + 1 sol.v 2.5.1 Fan Parameter 9= manual Fan operation is regulated to ensure a correct flow of heated (or chilled) Parameter 10= absent air during the various operating phases.
R C E 1 0 E The control automatically controls the heat valve to start heating and Upon completion of the sequence, the controller returns to normal the cool valve to start cooling. operation. If a selector switch is activated during the sequence, the Set Parameter 9= T ambient (room temp).
Page 8
POSITION "D" SELET. FACTORY PARAMETER TO BE SET DESCRIPTION OF PARAMETERS SET POINT POSITION A POSITION SPEED 1 POSITION SPEED 2 POSITION SPEED 3 Wint. / Sum. setpoint W/S Setpoint value setting 20/25 (d.z.= 5) 20/24 (d.z. =4) 21/23 (d.z.= 2) 20/25 (d.z.= 5) Type of system Defines the type of system...
R C E 1 0 E 2.8.0 ELECTRIC WIRING DIAGRAM Window cont. Window cont. ECONOMY Cont. ECONOMY Cont. S/W switching cont S/W switching cont Neutral common Neutral common Water sensor Water sensor Air sensor Air sensor Power supply 230 Vac Power supply 230 Vac Motor Motor...
Page 10
R C E 1 0 E R A N G E TEMPERATURE CONTROLLER FOR FAN COIL UNIT I N S T A L L A T I O N A N D U S E G U I D E...
Page 11
R C E 1 0 E I N S T A L L A T I O N A N D U S E G U I D E...
Page 12
All data in this technical manual are no binding for Eden S.r.l. company who takes the right, without advance notice obbligation, to provide to any modification for product improvements. EDEN s.r.l. Via dell'Artigianato, 11 - 31010 Fonte (TV) - ITALY Tel.
