DSP85 Series Digital Repeater
User's Guide
W
ESTELL.COM
©Westell Technologies. 960-1666-MNL rJ1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DSP85 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Westell DSP85 Series

  • Page 1 DSP85 Series Digital Repeater User’s Guide ESTELL.COM ©Westell Technologies. 960-1666-MNL rJ1...
  • Page 2 Use or application of such information or statements is at the users’ sole risk, without any liability on the part of Westell Technologies.
  • Page 3: Table Of Contents

    Donor Antenna .................................... 20 2.4.2 Antennas ......................................21 Optional Accessories ..................................21 2.5.1 Outside Donor Antenna ................................21 2.5.2 Inside Omnidirectional Antenna ............................21 WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ1 1.877.844.4274 Page 3 of 77...
  • Page 4 Band Plans and Filter File Naming Conventions ................. 51 Frequency Band Plans ..................................51 B.1.1 700 MHz Lower A, B and C Band Plan ..........................51 WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ1 1.877.844.4274 Page 4 of 77...
  • Page 5 Digital Repeater Port Configurations ............................69 E.2.1 Dual-band D2:D1 Port Configuration ..........................69 E.2.2 Dual-band D1:D2 Port Configuration ..........................69 E.2.3 Dual-band D2:D2 Port Configuration ..........................70 WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ1 1.877.844.4274 Page 5 of 77...
  • Page 6 Figure 3-13: Email Configuration ..................................34 Figure 3-14: Log Configuration ..................................35 Figure 3-15: Account Credentials ..................................36 Figure 4-1: Null Modem Cable ..................................37 WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ1 1.877.844.4274 Page 6 of 77...
  • Page 7 Table D-1: Mechanical Specifications ................................62 Table D-2: Electrical Specifications ................................. 63 Table D-3: Power Requirements ..................................63 Table D-4: Environmental Requirements ..............................63 WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ1 1.877.844.4274 Page 7 of 77...
  • Page 8 Digital Repeater Line DSP85 Series Table D-5: Operating Power Parameters ..............................64 Table G-1: Acronyms and Abbreviations ..............................76 WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ1 1.877.844.4274 Page 8 of 77...
  • Page 9: Preface

    The purpose of this document is to provide a procedure to help experienced technicians/engineers install and commission an in-building wireless enhancement repeater system using Westell Technologies digital repeaters. This document was written to address the practical concerns of the installer. Following the procedures in this manual will minimize risks associated with modifying a live system and will prevent service interruptions.
  • Page 10: Table P-1: Document Conventions

    A plus sign between key names indicates simultaneous keyboard commands. Press and hold down the first key while pressing the second key. For example, Ctrl+X. WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ1 1.877.844.4274 Page 10 of 77...
  • Page 11: Figure P-1: Product Registration Information

    Failure to comply with these precautions or specific warnings elsewhere in the manual violates safety standards of design, manufacture, and intended use of equipment. Westell Technologies assumes no liability for the customer’s failure to comply with these requirements: Grounding: This digital repeater system is designed to operate from 100 - 240 VAC and must always be operated with the ground wire properly connected.
  • Page 12: Canadian Compliance Information

    Unauthorized use may result in significant forfeiture penalties, including penalties in excess of $100,000 for each continuing violation.” WARNING! Changes and Modifications not expressly approved by Westell can void your authority to operate this equipment under Federal Communications Commission’s rules.
  • Page 13: Technical Support

    Appendix B describes the band plans and the convention Westell uses to identify and store the files that make up the filter set. All Westell repeaters are shipped with an active filter set that is programmed according to customer specifications.
  • Page 14: Led Indicator

    1.3 LED Indicator Westell Technologies automatic safety precautions are built into the amplifier system. In the case of a catastrophic system event, a shutdown circuit will disable all emissions if the uplink input or downlink input is overdriven or if an oscillation or output overpower event occurs.
  • Page 15: Local Communication Interface Ports

    1.4 Local Communication Interface Ports To allow monitoring and control, Westell repeaters are equipped with four ports that provide external communication access: one ethernet, one DB-9 serial, and two USB ports. The ethernet port is a primary communications port to the PC.
  • Page 16: Ethernet

    This port is used to provide local or remote access to the GUI. 1.8 Monitoring and Alarms The DSP85 Series can be monitored via an ethernet connection using SNMP, SSH and/or HTTP protocols. Public safety DSP models have dry contacts for traditional alarm panel monitoring as well.
  • Page 17: Figure 1-2: Dual Band Functional Block Diagram

    Digital Repeater Line DSP85 Series Figure 1-2: Dual Band Functional Block Diagram WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 17 of 77...
  • Page 18: Figure 1-3: Single Band Functional Block Diagram

    Digital Repeater Line DSP85 Series Figure 1-3: Single Band Functional Block Diagram WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 18 of 77...
  • Page 19: Optimizing The System During Installation

    If you cannot see an adjacent out-of-band signal when using the 1 MHz RBW filter, decrease the RBW to see the close-in-frequency signals. Set the RBW back when you want to measure the power level. WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274...
  • Page 20: Important Installation Notes

    Ground system components in accordance with NEC 810-15, 21 as required.  WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 20 of 77...
  • Page 21: Antennas

    2.5 Optional Accessories A complete line of accessories is available from Westell. Check with your Westell distributor for any additional items needed. Below are just a few examples suitable for most in-building needs: 2.5.1...
  • Page 22: Directional Couplers

    Tri-band Rack Mount - model number CSI-CM250-L7/C/P (700 Lower A/B/C LTE, Cellular and PCS)  Tri-band Wall Mount - model number CSI-CBC21/696-1990/N (700 Lower A/B/C LTE, Cellular and  PCS) WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 22 of 77...
  • Page 23: Web-Based Gui

    The GUI screens shown throughout this manual show a dual-band Cell/PCS configuration. They are for illustration purposes only. The actual screen you see will depend on the individual configuration. WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 23 of 77...
  • Page 24: System Status

    After login, the System Status page displays, Figure 3-2. The Navigation Menu on the left side of the page (highlighted in Figure 3-2) shows available operations. Clicking a menu item displays the page for that operation. Figure 3-2: System Status WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 24 of 77...
  • Page 25: Local Network

    After you have made the necessary changes, refresh the page to review the fields and ensure the information is correct. NOTE Changing network settings causes the current TCP/IP connection to fail because changes take effect immediately. WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 25 of 77...
  • Page 26: Rf Configuration

    53.5 dB and 85 dB. The repeater will not allow values outside this range. Implement change in gain by clicking the Change Settings button at the bottom of the page. Figure 3-4: RF Configuration WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 26 of 77...
  • Page 27: Program A Filter

    This process may take several minutes. If the desired filter is not currently in the repeater, additional filters, along with instructions on how to load them, are available by contacting Westell Technologies. Figure 3-5: Program a Filter WESTELL.COM...
  • Page 28: Remote Network

    If the repeater is connected to an ethernet device for remote access and/or monitoring, this feature must be disabled. Figure 3-6: Remote Network WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 28 of 77...
  • Page 29: Snmp Configuration

    Click Time Configuration in the left page menu to display the Time Configuration page, Figure 3-8. This page allows you to set the current system time and time zone. Figure 3-8: Time Configuration WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 29 of 77...
  • Page 30: System Health

    Be sure to click Clear All Logs before logging out of the Web interface. Figure 3-9: System Health WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 30 of 77...
  • Page 31: Install And Upload

    Click Install & Upload in the left page menu to display the Install & Upload page, Figure 3-10. Use this page to perform a software installation or upgrade. Contact Westell Technologies for new software versions. Figure 3-10: Install & Upload...
  • Page 32: Reboot

    Click Reboot in the left menu to display the Reboot page, Figure 3-11, which allows you to reboot the repeater. A reboot takes approximately three to five minutes to complete. Figure 3-11: Reboot WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 32 of 77...
  • Page 33: Alarm Configuration

    Apply Settings button. Letters, numbers and hyphens are the only acceptable nomenclature for the location field. Hyphens may not be used as the first or last character. Figure 3-12: Alarm Configuration WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 33 of 77...
  • Page 34: Email Configuration

    The software will not allow you to enter invalid characters in any field. Figure 3-13: Email Configuration WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 34 of 77...
  • Page 35: Log Configuration

    Log Rotate File Count. Enter the desired settings for each and click the Configure Logs button to save the settings. Figure 3-14: Log Configuration WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 35 of 77...
  • Page 36: Account Credentials

    The old account is removed when the new account is created. If you need to recover a password you have set, contact Westell Technologies technical support line at 1.877.844.4274, Option 2, then Option 1 for assistance.
  • Page 37: Console Interface

    Many terminal emulation programs will work if properly configured. In this section, Tera Term is used to establish the TMI session. Figure 4-3 displays when the application opens. Figure 4-3: Tera Term Pro Web Start Up WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 37 of 77...
  • Page 38: Figure 4-4: Serial Radio Button

    3. Click Setup to expand the drop-down menu, Figure 4-5 and select Serial port. The Serial Port Setup window, Figure 4-6, displays. In this window, you can make changes to the serial port setup. Figure 4-5: Setup WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 38 of 77...
  • Page 39: Figure 4-6: Serial Port Setup

    7. The set parameters option is disabled by default. To enable it, press 1. A dialog displays, prompting you to enter a user name and password. 8. Enter the default user name csi and the password csi1234. WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 39 of 77...
  • Page 40: Figure 4-7: Tmi Menus

    Digital Repeater Line DSP85 Series Figure 4-7: TMI Menus WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 40 of 77...
  • Page 41: Figure 4-8: Adjust Gain

    Change the gain value by entering the desired gain value at the prompt. You may return to the previous menu by selecting r. Figure 4-9: User Gain WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 41 of 77...
  • Page 42: Telnet Session (Remote Access)

    If you require assistance, contact your IT department or you may review the 4.4 Additional Tips section. WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274...
  • Page 43: Figure 4-11: Default Ip Address

    In the field after the prompt, enter the user name for the band to be changed. The default password is csi1234 for both bands. WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274...
  • Page 44: Modem Interface (Remote Access With Login)

    Network congestion (throughput)  When a connection has been established, the login screen shown in both the GUI Serial and Telnet examples displays. WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 44 of 77...
  • Page 45: Additional Tips

    2. Click on View network status and tasks, under Network and Internet as shown in Figure 4-15. Figure 4-15: View Network Status and Tasks 3. On the left side, click Change adapter settings as shown in Figure 4-16. WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 45 of 77...
  • Page 46: Figure 4-16: Change Adapter Settings

    Figure 4-17: Local Area Network 5. Double click Internet Protocol Version 4 (TCP/IPv4), or highlight Internet Protocol Version 4 (TCP/IPv4) and select Properties, Figure 4-18. WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 46 of 77...
  • Page 47: Figure 4-18: Internet Protocol Version 4 (Tcp/Ipv4)

    IP address and Subnet mask fields. In the IP address enter 192.168.1.2, and click OK, Figure 4-19. NOTE The Subnet mask will automatically populate to 255.255.255.0. Figure 4-19: Enter IP Address WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 47 of 77...
  • Page 48: Westell.com

    In some cases, DNS Server setup is required. To do this, log in as bandone through a SSH or serial connection. After you have logged in, follow the setup instructions. The DNS Address is the IP address of the modem (enter it in twice). WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274...
  • Page 49: Appendix A Attenuation And Dynamic Range Guidelines

    Choose accurate attenuator values to ensure that the maximum total power (higher of composite or in-band input) applied to the donor and server port(s) does not exceed -25 dBm. WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274...
  • Page 50: Dynamic Range Thresholds

    If the (downlink) composite input exceeds the in-band input by more than 3 dB Cellular, or more than 5 dB PCS, the maximum output power will be reduced. WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274...
  • Page 51: Appendix B Band Plans And Filter File Naming Conventions

    B.1 Frequency Band Plans B.1.1 700 MHz Lower A, B and C Band Plan Figure B-1: 700 MHz Lower A, B and C Band Plan WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 51 of 77...
  • Page 52: 700 Mhz Upper C Band Plan

    UL 835-845 DL 880-890 DL 870-880 UL 846.5-849 UL 824-825 DL 891.5-894 DL 869-870 UL 845-846.5 DL 890-891.5 Figure B-3: Cellular Frequency Band Plan WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 52 of 77...
  • Page 53: Aws Frequency Band Plan

    DL 198 0-198 5 DL 198 5-199 0 DL 195 5-196 0 DL 197 5-198 0 Figure B-5: Canadian PCS Frequency Band Plan WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 53 of 77...
  • Page 54: Us Pcs Frequency Band Plan

    DL 1972.5-1975 in CSI repeaters. Figure B-6: US PCS Frequency Band Plan B.1.7 Public Safety Bands Figure B-7: Public Safety Bands WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 54 of 77...
  • Page 55: Filter File Naming Conventions

    B.2.1 700 MHz Filter Naming Convention Westell Technologies digital repeaters use an alphanumeric file naming convention for its filter files. The descriptions below will allow you to understand the methodology to determine the desired file for your application. Table B-1: 700 MHz Filter Naming Convention...
  • Page 56: Cellular Filter File Naming Convention

    Cellular blocks Uplink Downlink A0 825-835 870-880 B0 835-845 880-890 Cellular sub-blocks Uplink Downlink A’ 845-846.5 890-891.5 A” 824-825 869-870 B’ 846.5-849 891.5-894 WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 56 of 77...
  • Page 57: Canadian Pcs Filter File Naming Convention

    A2 1855-1860 1935-1940 A3 1860-1865 1940-1945 B1 1870-1875 1950-1955 B2 1875-1880 1955-1960 B3 1880-1885 1960-1965 C1 1895-1900 1975-1980 C2 1900-1905 1980-1985 C3 1905-1910 1985-1990 WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 57 of 77...
  • Page 58: Us Pcs Filter File Naming Convention

    US PCS blocks Uplink Downlink A0 1850-1865 1930-1945 D0 1865-1870 1945-1950 B0 1870-1885 1950-1965 E0 1885-1890 1965-1970 F0 1890-1895 1970-1975 C0 1895-1910 1975-1990 WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 58 of 77...
  • Page 59: Westell.com

    Up to four sub-blocks may be defined, resulting in a maximum filename length. All variant/guard band designators other than 0 (zero) and F are user-defined custom filters. WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274...
  • Page 60: Aws Filter Naming Convention

    Up to four sub-blocks may be defined, resulting in a maximum filename length of 12 characters. All variant/guard band designators other than 0 (zero) are user defined custom filters. WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274...
  • Page 61: Appendix Clte Attenuator And Installation Notes

    Antenna separation under 100 meters requires additional attenuation greater than 20 dB. NOTE Maximum gain assumes no loss or gain in donor seen, coax distribution, or active DAS. WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 61 of 77...
  • Page 62: Appendix D Mechanical And Electrical Specifications

    N-female or 4.3-10 N-female or 4.3-10 Thermal management Convection cooled Convection cooled Surface coating Powder coat Powder coat Color Satin black Satin black WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 62 of 77...
  • Page 63: Electrical Specifications

    Single Band Dual Band Operating Temperature 10°C to 50° C (50° F to 122° F) 10°C to 50° C (50° F to 122° F) WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 63 of 77...
  • Page 64: Operating Power Parameters

    Measured with two CW tones at 14 dBm/ tone RMS vector error (EVM) 3% max TDMA, EDGE, W-CDMA, CDMA2000 CDMA RHO 0.98 min CDMA2000, 1x-EVD0 WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 64 of 77...
  • Page 65: Appendix E Port Configurations

    Output: Two single-band duplex ports, one to the low-band server antennas and one to the high-band server antennas. Figure E-2: Dual-band D1:D2 Port Configuration WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 65 of 77...
  • Page 66: Dual-Band D2: D2 Port Configuration

    Input: One dual-band duplex port from dual-band donor antenna. Output: One dual-band duplex port to dual-band server antennas. Figure E-4: Dual-band D1:D1 Port Configuration WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 66 of 77...
  • Page 67: Single-Band D1:D1 Port Configuration

    Output: Four dingle-band simplex ports, two uplink, two downlink, one uplink and one downlink for each band. Figure E-6: Dual-band D2:S4 Port Configuration WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 67 of 77...
  • Page 68: Dual-Band D1:S4 Port Configuration

    Input: One single-band duplex port from donor antenna. Output: Two single-band simplex ports, one for uplink and one for downlink. Figure E-8: Single-band D1:S2 Port Configuration WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 68 of 77...
  • Page 69: Digital Repeater Port Configurations

    Output: Two single-band duplex ports, one to the low-band server antennas and one to the high-band server antennas. Figure E-10: Dual-band D1:D2 Port Configuration WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 69 of 77...
  • Page 70: Dual-Band D2:D2 Port Configuration

    Input: Two single-band duplex ports, one from the first band donor antenna and one from the second band donor antenna. Output: Two single-band simplex ports, one for uplink and one for downlink. Figure E-13: MIMO Port Configuration WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 70 of 77...
  • Page 71: Single-Band D1:D1 Port Configuration

    Output: Four dingle-band simplex ports, two uplink, two downlink, one uplink and one downlink for each band. Figure E-15: Dual-band D2:S4 Port Configuration WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 71 of 77...
  • Page 72: Dual-Band D1:S4 Port Configuration

    Input: One single-band duplex port from donor antenna. Output: Two single-band simplex ports, one for uplink and one for downlink. Figure E-17: Single-band D1:S2 Port Configuration WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 72 of 77...
  • Page 73: Appendix F Mechanical Configurations

    Digital Repeater Line DSP85 Series Appendix F Mechanical Configurations F.1 DSP85-250 and DSP85-251 Series Mechanical Drawing Figure F-1: DSP85-250 and DSP85-251 Series Mechanical Drawing WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 73 of 77...
  • Page 74: Dsp85-250 And Dsp85-251 Series Mounting

    Wall mounting uses four brackets, one at each corner. Figure F-3: Wall Mounting NOTE Westell digital repeaters must be supported in the rack system with a shelf or slide rail. Do not rely on the brackets exclusively to support all the weight of the modules.
  • Page 75: Westell.com

    Interconnection of the repeaters in the rack or wall mount configuration requires the short RF jumpers supplied with the CBC Module. The actual interconnections will depend on the bands and cross band coupler module being used. Contact Westell’s technical support line at 1.877.844.4274 should you have questions about your specific application.
  • Page 76: Appendix G Acronyms And Abbreviations

    Third-order Intercept Point Radio Frequency Single Board Computer SNMP Simple Network Management Protocol Text Menu Interface UHCI Universal Host Controller Interface Universal Serial Bus WESTELL.COM © 2016 Westell Technologies 14 June 2016 Doc. No. 960-1666-MNL rJ 1.877.844.4274 Page 76 of 77...
  • Page 77 Digital Repeater Line DSP85 Series ESTELL.COM ©Westell Technologies. 960-1666-MNL rJ1...
