Introduction
The
TAPR
T-238
is
MC68HC908GP32 microcontroller-based board intended
for use with the Dallas Semiconductor 1-Wire™ bus and
any device that needs a serial connection.
button switches and a Liquid Crystal Display (LCD) provide
the user interface. The initial application for the T-238 is a
controller that accepts data from a Dallas Semiconductor
weather sensor unit, processes it, and formats it for
sending either directly to a Terminal Node Controller (TNC)
for broadcasting in APRS™ format or to a computer for
further processing and/or logging. There is nothing about
this board that makes it solely a weather station. This is
just the first application.
Dallas Semiconductor announced on July 7, 2000 that they
will no long supply the 1-Wire™ Weather Sensor unit.
Tecnologia Aplicada http://www.aag.com.mx now supplies
the 1-Wire(tm) Weather Instrument Kit V2.0. See
http://www.aag.com.mx/weather.html
information.
The TAPR T-238 is a ready-made kit with the weather
application pre-programmed into the microcontroller. All
the necessary hardware is provided for the more
adventurous people to develop their own applications. A
T-238 Assembly Manual
T-238 Assembly Manual
a
general-purpose
Four push-
for
to reproduce any portion of this document provided that: the
reproduction is not sold for profit, the intent of the reproduction is
to further disseminate information on Amateur Packet Radio, the
reproduction is not used for advertising or otherwise promoting
any specific commercial product, full credit is given to Tucson
Amateur Packet Radio Corporation (including address) as the
original source of information, and Tucson Amateur Packet
Radio Corporation is notified in writing of the reproduction.
list of available development tools for the MC68HC908 is
available at http://mcu.motsps.com/dev_tools/index.html.
Development tools are available from P&E Microsystems
at http://www.pemicro.com/ics08/.
"ICS08GP Software for 68HC908GP20/GP32" which
contains the following programs:
WINIDE08 - Integrated Development Environment w/
Assembler
PROG08SZ - MON08 Flash/EEPROM Programmer
ICS08Z - In-Circuit Simulator
ICD08SZ - Real Time In-Circuit Debugger
Motorola
More information on how to use the T238 debugging
functions is available in the T238 Operations Manual at
http://www.beals5.com/wx
http://www.tapr.org/taprf/html/Ft238.html
The T238 kit does not come with an enclosure or power
supply. It is left up to the builder to find an enclosure that
is suitable. For power, the user can use an ordinary wall
transformer ("wall wart") that provides 8-12 Volts DC at 300
milliamps. The T238 is fitted with a 2.1mm power coaxial
connector arranged so that the center conductor is
positive.
As T-238 programs are developed they will be displayed or
linked from the TAPR Weather web site located at
http://www.tapr.org/taprf/html/Ft238.html. If you've created
a project and would like to display or link to it, contact
ordering
TAPR at tapr@tapr.org.
Updated
http://www.beals5.com/wx
http://www.tapr.org/taprf/html/Ft238.html.
Rev. 1 February 2001
T- 238
documentation
can
Download the file
or
be
found
at
or
Page 1 of 11
