Summary of Contents for Winmate DD-M101
- Page 1 Desk Docking DD-M101 User Guide V1.0 For more information on this and other Winmate products, please visit our website at: www.winmate.com Document Part Number: 91521110101G Please read these instructions carefully before using this product, and save this manual for future use.
-
Page 2: Table Of Contents
Contents 1 Introduction - 3 - About DD-M101 Desk Docking - 3 - Package Contents - 3 - Product Overview - 4 - 2 Software Installation - 5 - 3 Hardware Installation - 6 - Setting up the Desk Docking... -
Page 3: Introduction
Congratulations on purchasing Winmate® DD-M101 Desk Docking. The Winmate® DD-M101 Desk Docking device supports the Winmate M101 series tablet computer. The DD-M101 enables you to connect your tablet computer to external devices and expand the functionality of the tablet. Package Contents Carefully remove the box and unpack your device. -
Page 4: Product Overview
Product Overview Unit: mm № Components Description Connects the docking station to ① 12-19V DC IN (Default) the AC adapter. Connects the docking station to ② 9-36V DC IN (Optional) the DC power source. ③ USB 2.0 x 2 (with 5V / 1A) Connect USB devices. -
Page 5: Software Installation
DD-M101 2 Software Installation This section describes how to install the DD-M101 Desk Docking software on M101-series tablet computer. 1. Before connecting tablet to DD-M101 Desk Docking, install drivers using provided CD. NOTE: The desk docking driver is not pre-installed on the tablet. -
Page 6: Hardware Installation
Before you begin any of the procedures in this section, follow the safety instructions that shipped with your tablet. Before You Dock the First Time Before connecting your tablet to the DD-M101 Desk Dock, please ensure the following: 1. Ensure that the tablet computer is docked to the DD-M101. -
Page 7: Docking Your Tablet
DD-M101 Docking Your Tablet 1. First, use screwdriver to loosen three screws on the docking. 2. Place the tablet holding plate on the desk docking, and then fasten the screws. 3. Put the tablet on the docking, and make sure the device is secure mounted on the holding plate. -
Page 8: Connecting To Ac Power
Connecting to AC Power WARNING! To reduce the risk of electric shock or damage to your equipment: Plug the power cord into a grounded (earthed) outlet that is easily accessible at all times. Disconnect power from the equipment by unplugging the power cord from the electrical outlet. -
Page 9: Connecting To Dc Power (Optional)
DD-M101 Connecting to DC Power (Optional) Notice that terminal block connector is an optional feature and may not be present in your DD-M101. Connect open wire cable (not supplied by Winmate) to 9-36V DC. - 9 -... -
Page 10: Using The Desk Dock With External Monitors
Using the Desk Dock with External Monitors Display Description Mode In mirror mode, you can easily operate touch screen. Note: Due to Intel® Graphic driver limitation, M101B series Mirror tablet with Windows 10® CBB OS does not support mirror Mode mode option. -
Page 11: Undocking Your Tablet
DD-M101 Undocking Your Tablet Disconnect all peripherals and AC power from the docking. 1. Pull the tablet from the tablet holding plate. 2. Lift the tablet up from the desk docking. ❶ ❷ - 11 -... - Page 12 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
