Infrared Thermometer SP
Instruction Manual
To Avoid Personal Injury, Follow These Guidelines:
•
Do not point laser directly at the eye or indirectly
off reflective surfaces.
•
Do not use the thermometer if it operates abnor-
mally. When in doubt, have the thermometer
serviced by a certified NorCross
•
Do not operate the thermometer around explo-
sive liquids, gases, or vapors.
•
Reflective objects will often result in lower than
actual temperature measurements. Do not
touch any surface suspected of being hot.
•
Do not use in a manner not specified by this manual.
To Avoid Damage to the Thermometer, Follow These Guidelines:
•
Do not expose to EMF (electro-magnetic fields) from arc welders, induction
heaters, etc.
•
Do not expose to static electricity.
•
Do not expose to thermal shock caused by large or abrupt ambient tempera-
ture changes. Allow 30 minutes for the thermometer to stabilize to a new
environment before use.
•
Periodically wipe the case with a dry cloth. Do not use abrasives, cleaning
chemical or solvents on this device. If necessary use a damp cloth to remove
debris buildup.
•
Do not store in a high temperature environment (automobile, vehicle or boat
dashboard, direct sunlight, etc).
•
Remove the batteries during storage to prevent damage from leaking batteries.
The Infrared Thermometer SP has an accuracy of
plus or minus 4° F (2.5° C) and is not intended to be
a scientific instrument. Do not use this device if you
require accuracy greater than this tolerance.
®
repair facility.
- 1 -
P/N: IR101SP
Advertisement
Table of Contents
Summary of Contents for Norcross IR101SP
- Page 1 Do not point laser directly at the eye or indirectly off reflective surfaces. • Do not use the thermometer if it operates abnor- mally. When in doubt, have the thermometer serviced by a certified NorCross ® repair facility. • Do not operate the thermometer around explo- sive liquids, gases, or vapors.
- Page 2 How the Thermometer Works This thermometer is a non-contact infrared thermometer. It measures the sur- face temperature of a non-translucent object by detecting the infrared energy emitted by the object. The laser is used for aiming purposes only. Warning: This thermometer is not recommended for use in measuring the tem- perature of shiny or polished metals.
- Page 3 Measurement Spot Size Readings are projected in what is known as a Distance/Spot Ratio (D:S). The D:S is a measurement of the diameter of the temperature measurement area as it 1” relates to the distance between the device and the surface being read. The D:S for this thermometer is 5:1 5”...
- Page 4 Warning: © 2007 NorCross Marine Products Inc., All Rights Reserved. ALL unauthorized copying of the content of this manual without the expressed written consent of NorCross Marine Products, Inc will be prosecuted to the fullest extent of the law.
