Page 1 Operation Manual Thank you for purchasing the ARF200 Paperless Recorder. This manual contains information for ensuring the correct use of the ARF200 Paperless Recorder. It also provides neces- sary information for installation, mainte- nance, and troubleshooting. This manual should be read by those who design and maintain equipment that uses the ARF200 Paperless Recorder.
Page 2 If you should find an error or omission, please contact the azbil Group. In no event is Azbil Corporation liable to anyone for any indirect, special or consequential damages as a result of using this product. © 2011-2017 Azbil Corporation All Rights Reserved.
Page 3: Conventions Used In This Manual
Conventions Used in This Manual ■ About Icons The safety precautions described in this manual are indicated by various icons. Please be sure you read and under- stand the icons and their meanings described below before reading the rest of the manual. Safety precautions are intended to ensure the safe and correct use of this product, to prevent injury to the operator and others, and to prevent damage to property.
Page 4: Safety Precautions
Safety Precautions WARNING Be sure to turn OFF the power supply before connecting wires to the power or input/output termi- nals to prevent an electric shock. To prevent electric shock, connect the protective ground terminal to a ground of less than 100 Ω. To prevent electric shock, attach the terminal cover after wiring.
Page 5 3. Check the contents of the package against the packing list to make sure that all items are included. Handle the ARF200 and its accessories with care to prevent damage or loss of parts. If there is some problem with your order, please contact your dealer immediately.
Page 6: Table Of Contents
Contents Safety Rrecautions Unpacking Chapter 1. OVERVIEW 1.1. Introduction ..............1 ■...
Page 7 Chapter 6. SWITCHING SCREENS ........... . . 29 Chapter 7.
Page 8 Chapter 12. WEB SCREEN 12.1. Remote Monitoring and Configuration ......... 108 Chapter 13.
Page 9: Chapter 1. Overview
Chapter 1. OVERVIEW 1.1. Introduction The ARF200 Paperless Recorder is able to measure temperature and various other industrial process quantities from 12 through to 24, 36 and 48 channels, and display various data in real time on a 12.1-inch TFT color LCD. This recorder can also store measured data in its internal memory or on a memory card (CF card or USB memory).
Page 10: Model Selection Guide
1.2. Model Selection Guide  Model number configuration VIII Input Option 1 Option 2 Option 3 Addition 1 Addition 2 Notes Basic Power model No. supply 12 inputs ARF212 ARF224 24 inputs ARF236 36 inputs ARF248 48 inputs 100-240Vac, 50/60Hz Standard multi-input (100 ms Ｓ...
Page 11: Optional Parts
Optional parts Name Model number Notes CompactFlash card ARF910CF0128 128 MB CompactFlash card ARF910CF0256 256 MB CompactFlash card ARF910CF0512 512 MB CompactFlash card ARF910CF1000 1 GB CompactFlash card ARF910CF2000 2 GB PC card adapter ARF910ADP000 250 Ω ± 0.02 % (qty.: 1) Resistor 81401325 250 Ω...
Page 12: Chapter 2. Part Names And Functions
Chapter 2. PART NAMES AND FUNCTIONS  Main unit Display Mounting bracket (2, left + right) (With options attached) (With options attached) Key cover (for the functions of keys, see chapter. 5 )  Rear terminals Power and protective ground terminals Ethernet connector Non-voltage contact input terminals Measurement input terminals...
Page 13: Chapter 3. Mounting And Wiring
Chapter 3. MOUNTING AND WIRING 3.1. Installation Site The ARF200 recorder is designed for indoor use. Install it in a location with the following characteristics: ・ Steady ambient temperature and humidity of about 23 °C, 50 % RH ・ Free from dust, smoke, steam, etc.
Page 14: Mounting Methods
• (1) Insert the ARF200 into the panel cutout on the instrument panel. (2) There are two screw holes, one on the left side and one on the right side of the ARF200. Lightly screw in the 2 screws provided.
Page 15: Wiring Precautions
3.3. Wiring Precautions Warning ・ Be sure to turn OFF the power supply before connecting wires to the power or input/output terminals to prevent an electric shock. ・ Attach crimp terminals to the ends of wires to prevent looseness or disconnection of terminals and short-circuit between terminals.
Page 16: Terminal Block
3.4. Terminal Block The following figure shows the terminal block as configured for options (alarm relay outputs [12 Form A contacts, 6 Form C contacts] and 8 contact inputs). The Ethernet connector is the standard type. Power terminals Ethernet connector Protective ground terminals TC, mV(+), RTD (A) terminals TC, mV(-), RTD (B) terminals...
Page 17: Wiring Of Power And Protective Ground Terminals
Note: The input, alarm, and contact input terminal blocks can be removed to facilitate wiring. Because the terminal block is connected by connectors, it can be removed easily by loosening two screws. Terminal block Mounting screws Handling Precautions ・ The thermocouple input terminal block cannot be repositioned or replaced with a terminal block for another instrument.
Page 18: Wiring Of Measurement Input Terminals
•Set the burnout to disabled. •Ground the device that you wish to connect in parallel at one point. In addition, install the device near the ARF200 and if possible use the same power supply. •Do not shut off the power of either device during operation.
Page 19 &12 in each input terminal block, and on the ARF _ _ _ AL (1 s input cycle models) the C terminals are short-circuited between all channels in each input terminal block.
Page 20: Alarm Output Wiring (For Applicable Models)
3.7. Alarm Output Wiring (for applicable models) (1) Alarm output terminal layout The terminal arrangement depends upon the type of alarm output. Alarm relay output (1a) N.O. terminals (M3.5) Alarm relay outputs (12) COM terminals (M3.5) MOS alarm relay output (1a) Digital inputs (8) Digital input (DI) COM (4 common inputs)
Page 21 After wiring, be sure to attach the terminal cover to prevent electric shock. Example of mechanical relay Form A contact output Example of mechanical relay Form C contact output Buffer relay Buffer relay ARF200 ARF200 Power Power : Contact point protective surge absorber Contact point protective surge absorber (placement on the “a”...
Page 22 Reference values for C and R C: 0.01 F (rating about 1 kV) R: 100 to 150 (rating about 1 W) Azbil Corporation’s surge absorber is No. 81446365-001 (qty. 10). Handling Precautions The common terminal of each alarm output is separate from the others.
Page 23: Digital Input Terminals (For Applicable Models)
・ 3.8. Digital Input Terminals (for applicable models) ( 1) Digital input terminals ■ Connection example Contact input terminals 1 2 3 4 5 6 7 8 (2) Wiring Turn off the power before wiring to prevent an electric shock. Use a non-voltage contact signal for digital input terminals.
Page 24 Handling Precautions ・ Relays and switches connected to the contact input terminals should be designed for low voltage/current load use. ■ DI terminal functions (1) Digital input Detects ON/OFF (closed/open) state. Set the range type to DI. (See 11.2, “Input Settings.”) (2) Pulse input For pulse input, set the range type to either Pulse (+) or Pulse (-).
Page 25: Ethernet Connections
3.9. Ethernet Connections 1-to-1 connection with a PC To connect the PC and the ARF200 in a 1-to-1 connection, use a crossover cable or a hub. Crossover cable ARF200 （With LAN function） N-to-N connections with PCs When connecting to multiple PCs or to an existing LAN, use a hub and straight cables between the hub and ARF or PC units.
Page 26: Chapter 4. Setup
Chapter 4. SETUP The ARF200 is shipped with default factory settings. For actual operation, however, be sure to do the following setup procedures. Start Preparations for operation Mount the ARF200 in a panel and wire it properly. Power ON Setting The ARF200 is shipped with default settings, but be sure to change the following settings as appropriate for the actual application environment and measurement objective.
Page 27: Chapter 5. Front Panel
Chapter 5. FRONT PANEL 5.1. Parts and Functions Display 12.1-inch TFT color LCD. For operation screens, see Chapter 7. Touch panel View with key cover open. Key cover Keyboard Power switch CF card drive USB connector Handling Precautions ・ The front panel is made of glass. To avoid injuries due to broken glass, protect it from impact.
Page 28: Functions Of Keys
5.2. Functions of Keys The usage and functions of the keys is different depending on whether an operation screen or a settings screen is displayed. All key operations can also be done on the touch panel, so all operations are possible with the key cover closed. Main Functions Operation screen Settings screen...
Page 29: Character Input
5.3. Character Input The character input screen seen below is used for setting or entering tags (labels for the channels), annotations using the marker function, and passwords. Pressing ENTER from a relevant screen displays the character input screen. Character input space On the character input screen, after moving the focus (indicated in blue) to uppercase letters or lowercase letters, pushing the down arrow key moves the focus to the row of letters below.
Page 30: How To Operate The Touch Panel
5.4 How to Operate the Touch Panel All ARF200 operations can be done on the touch panel. If the touch panel is not operating normally or if the same operation method as on the ARF100 series is preferred, the keyboard can be used.
Page 31 <[Operation] menu> Menu Item Description Start recording Starts recording. Same as the START key Stop recording Stops recording. Same as the STOP key HOME setting Opens the HOME settings. Same as the HOME key MENU setting Opens the MENU settings. Same as the MENU key <[DISP] menu>...
Page 32 5.4.2 Touch Operations in Setting Screens On the MENU and HOME settings screens, settings can be changed most easily by touch. To enter a value for any item, touch the button with the ▼ mark. To return to the previous screen, click the [Back] button. On screens with a scroll bar, information can be scrolled by touching and moving the scroll bar.
Page 33 5.4.3 Handwritten Input on Trend Screens On the real trend screen and historical trend screen, handwritten notations can be freely made by touching the display and drawing your finger along it. To write with your finger, touch once to enable the function. When handwritten input is enabled, is displayed in yellow as shown below.
Page 34 (Setting operation) The thickness and color of handwritten input can be be changed by touching 10 line thicknesses are available. 16 line colors are available. ← Fine Thick → Example of use Supplementary Explanation Number of Handwritten Points The number of handwritten points is obtained by periodically sensing and sampling coordinate data when the touch panel is touched.
Page 35 5.4.4 Automatic Scrolling on the Historical Trend Screen Section 5.4.2 dealt with touch operations on screens with a scroll bar. On the historical trend screen (see 7.6, “Historical Trend Screen”) and the dual trend screen (7.7, “Dual Trend Screen”), on which recorded data can be played back, the scroll bar can be made to move automatically by swiping the screen as if to move it to see the latest part of the graph.
Page 36: Operations In 4-Frame Split Screen Display
5.5 Operations in 4-Frame Split Screen Display The screen of the recorder can be split into four sections for displaying information simultaneously on four separate screens. However, on a split screen display, the selectable display type is limited. Only trend time charts, numeric displays and bar graphs can be selected. <How to switch from 1-screen display to 4-frame split display>...
Page 37: Chapter 6. Switching Screens
Chapter 6. SWITCHING SCREENS When the power is turned on, initialization takes about 10 to 30 seconds, and then an operation screen is displayed. With the factory settings, the operation screen that is displayed is the real-time trend (Initialization screen. However, generally when the power is turned on, the operation screens) screen that was being viewed when the power was turned off is displayed.
Page 38: Home Screen
Home screen On the Home screen it is easy to configure the same settings on all channels. The settings available on the Home screen are restricted, however, and settings cannot be changed on the Home screen while recording is in progress. Also, changing the recording cycle is possible for group 1 only.
Page 39: Chapter 7. Operation Screens
Chapter 7. OPERATION SCREENS 7.1. Common Key Functions 7.1.1. Use of the keys With touch operation, [Operation] → [Start recording]. Or, touch the disk icon. START Starts data recording. The data for any group which has been set to be recorded is stored in the internal memory.
Page 40 With touch operation, [Operation] → [HOME setting]. HOME Displays the HOME screen. With touch operation, [Operation] → [MENU]. MENU Displays the MENU screen. With touch operation, differs according the screen. ENTER On many screens, displays a menu. Menu contents differ depending on the screen. With touch operation, [Back] button (in the settings screen) Returns to the previous screen (except when the present screen is the real-time trend, bar graph, or numerical display screen).
Page 41 When trends are displayed vertically, the up and down keys switch the displayed group and the left and right keys switch the displayed channels. When trends are displayed horizontally, the left and right keys switch the displayed group and the up and down keys switch the displayed channels. With touch operation, N/A...
Page 42 7.1.2. Displayed data Readings and messages displayed on screens Data or message Description (Numeric value) Numeric values are displayed based on the scale settings for each channel. The number of digits after the decimal point is determined by the maximum and minimum values of the scale.
Page 43: Status Bar Information
7.2. Status Bar Information The status bar is always at the top of the screen. It shows information such as the status of the recorder. If a schedule is set (see 11.7), the background color of the status bar is gray for periods other than the scheduled period.
Page 44 The Disk Icon • The recording state of the currently displayed group is indicated by an arrow state. Arrow State Flowing up Recording is in progress. Flashing The START key was clicked, but the recorder is in a recording standby state since recording conditions have not been met.
Page 45: Real-Time Trend Screen
7.3. Real-time Trend Screen The data trends can be viewed as on an analog recorder. Up to 4 scale bars can be displayed. A “pen” for each channel is positioned on the scale bars according to the display position setting for the channel.
Page 46: Bar Graph Screen
7.4. Bar Graph Screen On this screen, bar graphs display the readings for each channel in real time, for easy visual evaluation. The scales and length of the bars are determined by the display scale of the channel with the lowest channel number in the group. Display options this...
Page 47: Historical Trend Screen
7.6. Historical Trend Screen Previously recorded data can be played back in trend format. If “Historical trend” is selected from the DISP menu (or if [SCROLL] key is pressed while the real-time trend screen is displayed), internal memory is displayed. Data for When a file has been selected the cursor...
Page 48 With touch operation, touch the H, L icons on status HOME If the data format set for the displayed file is maximum/minimum, the numeric value display (or bar graphs) show maximum and minimum values. The status bar will indicate either H (= high or max.) or L (= low or min.).
Page 49: Dual Trend Screen
7.7. Dual Trend Screen The screen is split into upper and lower Upper row: current data parts to display both real-time trends readings and historical trends, allowing them to Lower row: data be easily compared. The numerical data for the cursor position in the section is also split, and shows both historical trends...
Page 50 Special functions of keys (see 7.1 above for other functions) Up and down arrows move the yellow highlighting up and down. Left and right arrows are not used. SCROLL With touch operation, operate the scroll bar. Operation is the same as on the historical trends screen. See 7.6 above.
Page 51: Internal Memory Screen
7.9. Internal Memory Screen This screen lists the files contained in the recorder’s internal memory. The start date and time, the end date and time (the last moment of recording) and the number of records (data count) are displayed. Files are displayed in chronological order (latest on top).
Page 52 About internal memory The ARF200 writes all data to internal memory as a file. The recorded data is copied to the CF card at a preset interval and when recording in a file is complete. Limitations on internal memory File size. When data reaches the maximum file size in internal memory, the file is completed.
Page 53: Cf Card/Usb Memory Screen
7.10. CF Card/USB Memory Screen This screen shows a list of files stored on the CF card or the USB memory for the group identified in the status bar. The screen displays the start date and time, the end date and time (or the time of the latest recording, if recording is in progress), and the number of records (data count).
Page 54: Marker Screen
7.11. Marker Screen Shows a list of annotations recorded on the trends with the marker function. The date and time and the annotation are displayed in chronological order (latest on top). Only annotations in the selected group are displayed. A maximum of 200 annotations can be recorded.
Page 55: Chapter 8. Initial Settings
Chapter 8. INITIAL SETTINGS When the power is turned on with the default factory settings or when the settings are initialized, the initial settings screen will appear. Set parameters for the following, at a minimum: ・Language ・Power frequency (50/60 Hz) ・Usage group count ・Clock ・Input...
Page 56 2) Power frequency The sub-screen is displayed by touching the ▼ button for the 50Hz/60Hz item. The selected item is displayed by touching the item to set from 50Hz or 60Hz in the sub-screen. Before setting this, check the frequency of the power supply you are using. 3) Usage group count The sub-screen is displayed by touching the ▼...
Page 57 4) Clock settings The clock setting screen below is displayed by touching the [Set] button at the Clock settings item. For detailed setting instructions, refer to “11.11.1. Clock”. (Page 101) 5) Input settings The input setting screen below is displayed by touching the [Set] button at Input settings item. For detailed settings instructions, refer to “11.2 Input settings”.
Page 58 6) Display settings The display setting screen below is displayed by touching the [Set] button at Display settings item. For detailed setting instructions, refer to “11.3.1. Channel parameters”. (Page 68) 7) File settings The file setting screen below is displayed by touching the [Set] button at File settings item. For detailed setting instructions, refer to “11.5.
Page 59: Chapter 9. Menu Structure
Chapter 9. MENU STRUCTURE HOME setting Input parameter settings (page 37) screen (page 37) Recording interval settings (page 37) Operation Instrument specifications display Specification confirmation (page 39) screen List Detail settings Input operation settings (page 44) MENU setting screen (page 40) Channel parameters Setting of display Display settings (page 52)
Page 60: Chapter 10. Home Screen
Chapter 10. HOME SCREEN 10.1. Quick recorder setup For convenient setup and checking, input and recording settings for all channels at the same time can be set on the HOME screen. □ Operation screen Press [HOME] key or touch [Operation] → [HOME setting] □...
Page 61 ■ Scale • Set the scale. (The scale depends on the range type and sensor type.) Correctly input the position of the decimal point here since it becomes the position of the decimal point for measurement values. ■ Reference junction compensation (RJ) •...
Page 62: Specifications Display
10.2. Specifications display The basic specifications of this recorder can be checked from the HOME screen. • If you have a question about the recorder, contact your distributor after checking the • specifications. □ Operation screen Press [HOME] or [Operation] → [MENU settings]. □...
Page 63: Chapter 11. Menu Screen
Chapter 11. MENU SCREEN 11.1. Overview □ Operation screen Press [MENU] key from the operation screen, and the MENU screen is displayed. Select the desired item with the arrow keys and press [ENTER] key to switch to the desired parameter setting screen.
Page 64 □ Display settings screen Select “Display settings” and press [ENTER] key. See 11.3, “Display settings.” (Page 68) □ Alarm settings screen Select “Alarm settings” and press [ENTER] key. See 11.4, “Alarm settings.” (Page 78) □ File settings screen Select “File settings” and press [ENTER] key. See 11.5, “File settings.”...
Page 65 □ Totalizer settings screen Select “Totalizer reset settings” and press [ENTER] key. See 11.6, “Totalizer settings.” (Page 85) □ Schedule settings screen Select “Schedule settings” and press [ENTER] key. See 11.7, “Schedule settings.” (Page 87) □ Marker settings screen Select “Marker settings” and press [ENTER] key. See 11.8, “Marker settings.”...
Page 66 □ Memory operation screen Select “Memory operations” and press [ENTER] key. See 11.9, “Memory operations.” (Page 89) □ Network settings screen Select “Network settings” and press [ENTER] key. See 11.10, “Network settings.” (Page 91) □ System settings screen Select “System settings” and press [ENTER] key. See 11.11, “System settings.
Page 67: Input Settings
Press the ▼ button for the item to be set and then move to the input screen. The ARF200 can be set for up to 128 channels. Depending on the model, functions are allocated among the channels as shown in the table below.
Page 68 ARF212 ARF224 ARF236 ARF248 Without With Without With Without With Without With contact contact contact contact contact contact contact contact input input input input input input input input Analog input CH1~12 CH1~12 CH1~24 CH1~24 CH1~36 CH1~36 CH1~48 CH1~48 channels Channels set for CH13~128 CH13~120...
Page 69 Digital input type (Digital input type (for models with digital input): CH121 to 128) Digital input Pulse input Pulse (+)*, Pulse (-)** Pulse (+)*: pulse counter increases at a rising edge (OFF to ON) of input signal. Pulse (-)**: pulse counter increases at a falling edge (ON to OFF) of input signal. Digital input: DI Records ON/OFF status of digital input.
Page 70 “System settings” is selected for “Filter level,” the filter level will be determined by the settings in System settings > Other. Note: Setting the filter level is possible only in version 2.00 and later. ■ Tag (label) • A tag can be displayed instead of the channel number. (Up to 15 one-byte characters) This is valid when data display of [Display settings] →...
Page 71 11.2.2. Formula definition 1) Types of calculation Arithmetic operations The basic f our arithmetic operations are available. Operation Symbol Example Remarks Addition Subtraction X–Y Multiplication Division Remainder Exponential Note: X and Y in the table indicate a formula or number. Comparison Comparison is done and the result is given as 1 (satisfied) or 0 (unsatisfied).
Page 72 Channel data operation functions The following calculations can also be done: Symbol Example Remarks See the value before the CH(X) operation of the specified Input data channel. *1 Calculation result PCH(X) data Previous calculated OCH(X) Data at the previous scanning result data ITG(X) Totalization...
Page 73 Example: Inputting the instantaneous value (L/min) from the flowmeter and calculating the cumulative count Since the unit used by the formula for integration (ITG) on the ARF200 is the second, it is necessary to convert the PV from L/min to L/s. Therefore, the ITG is divided by 60: ITG (d)/60 (or ITG (d)/3600 if the PV unit is L/hour).
Page 74 (4) Relative humidity Format for entering the formula RH (D#W) D: Dry bulb temperature W: Wet bulb temperature The following formula is used for relative humidity calculation. ((B - 0.000662 × 1013.0 × (D - W)) ÷ A) × 100 A: Dry bulb saturated water vapor pressure B: Wet bulb saturated water vapor pressure D:Dry bulb temperature W:Wet bulb temperature...
Page 75 (7) Past data Calculate the data T seconds earlier. Format for entering the formula OLD (X#T) OLDH (X#T) X: Data channel No. T: Amount of time to go back (sec.) The table below shows the difference between OLD and OLDH. OLDH Sampling cycle 0.1 s...
Page 76: Display Settings
11.3. Display settings 11.3.1. Channel parameters • Start from the MENU screen. • Press [ENTER] key and the screen shown below will be displayed. Wave pattern type, maximum/minimum values of the display scale, color and the display position of each channel can be set.
Page 77 The significant of the minimum and maximum values is 1–9.99, and the exponent part can be set in a range of ±15. Minimum, maximum In the trend display, the coordinates are calculated such that the minimum value is positioned at the extreme bottom left and the maximum value is positioned at the extreme upper right.
Page 78 ■ Setting the display position • The display position (1, 2, 3, or 4) indicates the position of the scale on which the pen is placed. For vertical trend graphs For horizontal trend graphs ■ Copying parameters with the copy function The above shows the setup for copying Ch 01’s parameters to Channels 02 to 05.
Page 79 11.3.2. Group parameters • Start from the MENU screen. • Press the ▼ button for the item to be set and then move to the input screen. The group specified by the number next to "Group" in the upper left can be configured. ■...
Page 80 ■ Trip line • This is a fixed dotted line displayed on the trends. – Posi(tion) Set the display position of the trip line in the range 0–99 % of the display width. – Color Select the color of the trip line from a choice of 48 colors. –...
Page 81 ■ Time axis ruled line • Select “Auto” or “Specified.” If “Auto” is selected, the interval between ruled lines is determined automatically according to the recording interval. ■ Time axis ruled line interval • Specify the interval between ruled lines on the time axis in trend displays. Even numbers from 12 to 510 can be specified.
Page 82 11.3.4. Common parameters • Start from the MENU screen. • Press the ▼ button for the item to be set and then move to the input screen. ■ Data display • Set the upper side (or right side) display of the trend screen to indicate tags, bar graph, or nothing. No tag With tag Bar graph...
Page 83 ■ Bar graph base position • This sets the base position for bar graphs on the bar graph screen at a value from 0 to 100. At a setting of 0, bars start on the left side (or the bottom) of the screen. At a setting of 100, bars start on the right side (or the top).
Page 84 Zone The area in which measured/calculated data is displayed is called a zone. By assigning each channel to a zone, the data display can be more easily read. Select “ON” for Zone usage. From the MENU screen, when Display settings and then Channel parameters is selected, the following screen (with an added column for zone) is displayed.
Page 85 11.3.5. LCD settings • Start from the MENU screen. • Press the ▼ button for the item to be set and then move to the input screen. ■ Display off timer (minute) If there is no key operation during the time (in minutes) set for the display-off timer, the LCD display will turn off.
Page 86: Alarm Settings
11.4. Alarm settings • Start from the MENU screen. • Press the ▼ button for the item to be set and then move to the input screen. ■ Type • There are 6 settings for alarm type, as shown below. None The alarm is not set Diff.
Page 87 ■ Relay (for models with the optional alarm output terminal) • It is possible to set relays even without an alarm output terminal (but there is no effect). • The alarm output terminal number can be set from 0 to 12. However, there is no alarm output when 0 is set.
Page 88 Differential alarms Differential upper limit alarm Differential lower limit alarm Difference of measured values (absolute value) U の計警報値 Difference of measured values (absolute value) Alarm occurs Alarm occurs When difference in measured values ≥ alarm value: Differential upper limit alarm occurs When difference in measured values ≤...
Page 89: File Settings Screen
11.5. File settings screen • Start from the MENU screen. • Press the ▼ button for the item to be set and then move to the input screen. ■ No. The setting for number of groups that has been set in the recorder’s group count setting (in System settings →...
Page 90 Group file settings ■ Recording cycle Seconds 0.1, 0.2, 0.5, 1, 2, 3, 5, 10, 15, 20, 30 Minutes 1, 2, 3, 5, 10, 15, 20, 30, 60 ■ Data format If the recording cycle is set to 0.1 seconds, Sampling is the only selectable data format. In recording the data into the file, the average, maximum, minimum or maximum/minimum values in the period of the recording cycle can be recorded.
Page 91 ■ Recording triggers Recording is triggered in one of the following ways: Trigger type Description START key Recording starts when the [START] key is pressed. Alarm After the [START] key is pressed, recording begins when the alarm relay is activated. If this item is selected, the relay terminal number can be selected.
Page 92 ■ Auto save period This setting determines how often the file in internal memory is copied to the CF card. In addition to this cycle, each file is copied to the CF card when it is complete (see 7.9). Minutes No setting, 1 min, 2 min, 3 min, 5 min, 10 min, 20 min, 30 min, 60 min Note: Factory setting is 1 minute.
Page 93: Totalizer Settings
11.6. Totalizer settings Totalizer function (integration) is determined by the calculation settings for each channel. This screen is for selecting the procedure for resetting the cumulative count to 0. Totalizer F-value Pulse input calculation ITG24 Pulse (+) Pulse (-) Manual reset ●...
Page 94 ■ Reset by digital input (DI) (optional feature) • The cumulative count can be reset when the assigned digital input terminal is energized. Select “None” if this function is not needed. Note: This setting is not displayed if the ARF does not have a digital input option.
Page 95: Schedule Settings
11.7. Schedule settings • Start from the MENU screen. • Press the ▼ button for the item to be set and then move to the input screen. If a schedule is set on this screen, recording takes place only during the set period. Even if recording conditions specified by other settings are satisfied, the recorder does not record outside of the scheduled period.
Page 96: Marker Settings
11.8. Marker settings • Start from the MENU screen. • Press the ▼ button for the item to be set and then move to the input screen. Models without a digital input option Models with a digital input option On this screen, up to 50 annotations (30 one-byte characters max.) for use on the trends can be registered in advance.
Page 97: Memory Operations
Input a file name and press the “Done” key to write the settings. Files are saved in the “SETUP” folder in the CD card appended with the “.krs” extension. Setting files can also be read and used on other ARF200 series recorders.
Page 98 ■ Reading settings from external memory Reads setting files from CF card, and overwrites the current settings. The dialog box shown above is displayed. When reading of files in either CF card or USB memory is selected, a list of setting files in the “SETUP” folder in those files is displayed. Either touch the row of the file to read, or select it and press the ENTER key.
Page 99: Network Settings
11.10. Network settings 11.10.1. Ethernet • Start from the MENU screen. • Press the ▼ button for the item to be set and then move to the input screen. This screen sets up the address, etc. that this recorder needs for an Ethernet connection. ■...
Page 100 11.10.2. DNS settings The DNS server is for converting the address specified with a name into the IP address. When the addresses of the FTP server, POP3 server, SMTP server, etc. are entered with names, make sure to set the DNS server. •...
Page 101 11.10.3. Web server settings User name and password for logging on to the ARF200 web server function can be set on the screen shown below. • Start from the MENU screen. • Press the ▼ button for the item to be set and then move to the input screen.
Page 102 ARF200’s internal memory screen and transfer it by FTP. ■ Retry mode • When Retry mode is OFF, if FTP transfer fails three times, the ARF200 will stop attempting the transfer and display an error message. When Retry mode is ON, the ARF200 will continue to attempt the transfer until it is successful.
Page 103 11.10.5. FTP server • Start from the MENU screen. • Press the ▼ button for the item to be set and then move to the input screen. The settings below configure the recorder’s FTP server function. ■ FTP server ON/OFF •...
Page 104 Example: If the check base time is 0:00 and the check interval is 04:00, time synchronization by SNTP is executed at 0, 4, 8, 12, 16, and 20 hours. ■ Quick update • Whenever the “Update” button is pressed, the ARF200 and SNTP server times are synchronized.
Page 105 11.10.7. E-mail settings This recorder can send e-mail when an alarm event occurs, or at a specific time. Up to 8 recipients can be designated in advance. The recorder sends e-mail to the recipients when the event (defined by a maximum of 8 conditions) occurs. •...
Page 106 Select “Forwarding condition” and press [ENTER] key to get the following screen. ■ Condition number • Up to 8 sets of e-mailing conditions can be registered. This screen sets the conditions for the number selected here. ■ Forwarding condition • Determine the conditions for sending e-mail to the specified destinations. Condition Description None...
Page 107 Transmission channel When this is selected, the screen shown below will be displayed. When “At alarm generation” is specified in selecting the e-mail transfer conditions, the data of the channel registered in this screen is written to the mail main text and the mail is sent. When nothing is registered, the data of the channel on which an alarm was generated is written and sent.
Page 108 Select “Account” from the E-mail settings screen to get the following screen. ■ POP3 address This address is used when the SMTP server requires POP3 authentication. Enter the address of the POP3 server. Do not enter anything if POP3 authentication is not required. ■...
Page 109: System Settings
11.11. System settings 11.11.1. Clock The date and time of the recorder’s internal clock can be set. • Start from the MENU screen. • Press the ▼ button for the item to be set and then move to the input screen. Date and time ・...
Page 110 11.11.2. Key lock • Start from the MENU screen. • Press the ▼ button for the item to be set and then move to the input screen. When the key lock is ON, use of the MENU screen settings and entry into setting screens is disabled without a password.
Page 111 11.11.3. Password • Start from the MENU screen. • Press the ▼ button for the item to be set and then move to the input screen. This password is used for the following: To unlock the keys To log in and display the web page ■...
Page 112 Start from the MENU screen. • Press the ▼ button for the item to be set and then move to the input screen. ■ TCP/IP port number • Not used by the ARF200 series. 11.11.5 Graduation adjustment • Start from the MENU screen.
Page 113 11.11.6 Touch panel calibration • Start from the MENU screen. • Press the ▼ button for the item to be set and then move to the input screen. When touch panel calibration in the system screen is selected from the MENU setting menu screen, the screen shown below will be displayed.
Page 114 11.11.5. Other • Start from the MENU screen. • Press the ▼ button for the item to be set and then move to the input screen. ■ Language Sets either Japanese or English as the interface language. ■ Instrument name This name is used as the sender in e-mail messages.
Page 115 ■ Pen coordinate calculation* • Select either Smooth or Direct as the method of calculating the trend coordinates. • If “Smooth” is selected, the trend coordinates, even when affected by changes of data, will not change unless the amount of data change exceeds the equivalent of 1 dot on the screen. Thus the trend line will not be out of alignment if data fluctuates only within a range equivalent to 1 dot.
Page 116: Chapter 12. Web Screen
Chapter 12. WEB SCREEN 12.1. Remote monitoring and configuration Recorder settings related to inputs and recording can be configured using a web browser, and also recorded data can be displayed. 12.1.1. Top Page After accessing the IP address of the recorder via the web browser (Internet Explorer in the image below), and after password authentication, the screen seen below is displayed.
Page 117 12.1.2. Recorder display The same contents seen on the recorder can be displayed. The buttons at the bottom of the screen act like the keys on the recorder. Because an image file is used, loading this page takes more time than loading other pages.
Page 118 12.1.4. Input settings The recorder’s input parameters can be set. Click the “Set” button after entering each item, and the settings are written to the recorder. The settings for 6 channels at a time are displayed on the screen. To change to a different block of channels, click the desired link under "Channel Number"...
Page 119 12.1.5. Alarm settings Alarm parameters can be set using the web browser. Click the “Set” button after entering each item, and the settings are written to the recorder. The settings for 12 channels at a time are displayed on the screen. To change to a different block of channels, click the desired link under “Channel Number”...
Page 120 12.1.6. Calculation settings These settings determine whether calculation is used, and which formula is used for each channel. Click the Set button after entering each item, and the settings will be written to the recorder. The settings cannot be changed while recording is in progress. Available settings Item Description...
Page 121 12.1.7. Group settings Parameters related to recording can be changed. Click the Set button after entering each item, and the settings will be written to the recorder. The settings of one group are displayed on one screen. Click the desired group number at the top of the screen to change groups. Groups from Group 1 to the recorder’s group count setting (in System settings →...
Page 122 12.1.8. Marker settings Annotations used by the recorder’s marker function can be changed. Click the “Set” button after entering each item, and the settings will be written to the recorder. When a text is entered in the last row (No. 10 in the figure), 10 more rows appear. Up to 50 annotations can be registered. See. 7.3 and 7.6 for writing the annotations on the trends.
Page 123: Chapter 13. Recording To Usb Memory
Chapter 13. RECORDING TO USB MEMORY 13.1. Overview The USB port provided on the ARF200 can be used to record to USB memory instead of the CF card and to copy data recorded to CF card to USB memory. 13.2 Connectable Media Use only the following devices.
Page 124: Chapter 14. Calibration
(2) The recorder should be ON for at least an hour of warm-up time in order to stabilize. Handling Precautions ・ The checking and adjusting of measured values requires careful attention, in addition to standard tools and reference conditions. When checking and adjustment are required, contact your dealer or Azbil Corporation.
Page 125: Connections
14.4. Connections Connections differ depending on the input type. Connect standard tools to the measurement input terminals that are to be adjusted. Caution To prevent electric shock, turn off the power source before making connections. <For ARF2 _ _ AS models> (1) DC voltage input Adjustment is done on three input terminals （＋）...
Page 126 (3) Thermocouple input Adjustment is done on three input terminals of each input terminal unit: INPUT CH1, CH6 and CH12. For thermocouple adjustment, connect to CH1, CH6 and CH12 as shown in the figure below. Thermocouple wire* ■ INPUT CH1, CH6 and CH12 are used for adjusting 3 elements for measuring the （＋）...
Page 127 <For ARF2 _ _ AL models> (1) DC voltage input Adjustment is done on 1 input terminal （＋） of each input terminal unit: INPUT CH2. Connect the INPUT CH2 as shown in the figure on the right. （－） All channels of that unit are adjusted by adjusting INPUT CH2.
Page 128: Zero And Span Adjustment
14.5. Zero and span adjustment 14.5.1. Calibration screen • Adjust ranges by inputting zero and span values into each INPUT channel (terminal) used for adjustment. • With the arrow keys, move the focus to “Go” in the range to be adjusted. In the operation screen, if [Operation]-[MENU Settings] is selected and then [System Settings]-[Gradation Settings] is selected, the adjustment screen below is displayed.
Page 129 (2) The input voltage is displayed on the screen. Input this voltage into the recorder. (3) Adjust the zero point。 Example: To adjust the ±2V range • Input 0V by the DC voltage current generator. (4) Wait about 5 seconds after inputting the zero voltage, and then press [Go] button. (5) Adjust the span.
Page 130 14.5.3. Adjustment of resistance temperature detector input range Connect as shown in 14.4, “Connection. (2) Resistance temperature detector input.” For the ARF112, input the resistance for the range being adjusted. (1) Select “Go” at the range to be adjusted, and press the [ENTER] key. (2) The resistance that should be input is displayed on the screen.
Page 131 (2) Select “Go” for the “RJ 0°C” range on the calibration screen, and press [Go] button. (3) Wait about 30 seconds, then press the [Go] button. (4) After finishing the adjustment, the calibration screen for all ranges will be displayed. (5) Press [ESC] key, and the MENU screen will be displayed.
Page 132: Chapter 15. Part Replacement
Chapter 15. PART REPLACEMENT Replacing parts periodically is recommended as preventive maintenance, for long and productive use of the paperless recorder. Caution Return the recorder to the factory when part replacement is needed. Replacing parts yourself might result in electric shock or fire. 15.1.
Page 133: Chapter 16. Troubleshooting
If the power is turned off in this state, data in internal memory, such as operating data and settings (see below), may be lost. For this reason, stop data recording at once and save data from the internal memory to the CF card. Promptly request Azbil Corporation to replace the battery.
Page 134 No., date code, observations, and other pertinent information at hand. Data in internal memory can be deleted unexpectedly during repair. Back up data to the CF card before sending the recorder for repair. Azbil Corporation is not liable for data in internal memory that is lost or damaged.
Page 135: Chapter 17. Disposal
Handling Precautions ・ Removing and replacing the battery may cause damage or malfunction. Except when discarding the recorder, contact the azbil Group for battery removal/replacement. Removing/replacing the battery Remove the front pane. Open the key case and remove the 2 screws attaching the front pane to the case (main unit).
Page 136: Chapter 18. Specifications
Chapter 18. SPECIFICATIONS  General specifications Rated voltage: 100–240 VAC Power consumption: 50／60Hz (variable voltage range power supply) Operating conditions: Reference operating conditions Ambient temperature/humidity: 21–25 ºC , 45–65 % RH Power 100 Vac ± 1 %, 50/60 Hz ± 0.5 % Left/right, forward/backward tilt: 0°...
Page 137: Input Specifications
Input specifications  Measurement input channels: 12, 24, 36, 48 Input type: Full multi range DC voltage: ±13.8 mV, ±27.6 mV, ±69.0 mV, ±200 mV, ±500 mV, ±2V, ±5V , ±10V , ±20V ±50V *: With built-in resistance voltage divider DC current: Available by adding external shunt resistor Thermocouple:...
Page 138: Recording Specifications
 Recording specifications Internal memory: Recording cycle: Selectable from: Seconds 0.1, 0.2, 0.5, 1, 2, 3, 5, 10, 15, 20, 30 s Minutes 1, 2, 3, 5, 10, 15, 20, 30, 60 min Recorded data: Measurements Group name, recording start date/time, recording cycle, measured data, alarm data, marker function annotations Programmed parameters All parameters...
Page 139: Alarm Specifications
Touch panel specifications Type: Analog resistance membrane Chemical resistance: Toluene, trichloroethylene, acetone, alcohol, gasoline, machine oil, aqueous ammonia, glass cleaner, mayonnaise, ketchup, wine, salad oil, edible vinegar, lipstick, etc. Alarm Specifications Number of settable alarms: Up to 4 per channel Alarm types: Upper limit, lower limit, differential higher limit, differential lower limit, error Alarm memory:...
Page 140: Measurement Range, Indication Accuracy, And Display Resolution
Measurement range, indication accuracy, and display resolution Input type Measurement Reference Indication accuracy Display range range resolution -200.0 to +300.0 °C ±13.8 mV -200.0 to 0 °C ±0.2 % FS ± 1 digit 0.1 °C 0 to +300.0 °C ±0.1 % FS ± 1 digit -200.0 to +600.0 °C ±27.6 mV -200.0 to 0 °C...
Page 141 Input type Measurement Reference Indication accuracy Display range range resolution -200.0 to +250.0 °C ±13.8 mV -200.0 to 0 °C ±0.3 % FS ± 1 digit 0.1 °C 0 to +250.0 °C ±0.15 % FS ± 1 digit -200.0 to +500.0 °C ±27.6 mV -200.0 to 0 °C ±0.3 % FS ±...
Page 142: External Dimensions
■ External dimensions Unit: mm Option Option...
Page 143 Revision History (CP-UM-5613E) Printed Edn. Revised pages Description July 2011 ARF990DA0000, for “Windows98/Me/2000/XP” → “for Windows” Sep. 2013 Tropical treatment, With inspection results + tropical treatment was deleted. WARNING was added.  Standards was changed. End of a book AAS-511A-014-03 June 2015 CE marking, EMC directive, and Low voltage directive were deleted.
Page 144 1. Warranty period and warranty scope 1.1 Warranty period Azbil Corporation's products shall be warranted for one (1) year from the date of your purchase of the said products or the delivery of the said products to a place designated by you.
Page 145 Azbil Corporation's products every 5 to 10 years unless otherwise specified in specifications or instruction manuals.
Page 146 Specifications are subject to change without notice. (09) 1-12-2 Kawana, Fujisawa Kanagawa 251-8522 Japan URL: http://www.azbil.com 1st edition: July 2011 (M) 6th edition: Aug. 2017 (V)
