IBASE Technology FWA8408 User Manual

1u rackmount network appliance
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FWA8408
FWA8406
1U Rackmount
Network Appliance
User's Manual
Version 1.0
(Aug. 2017)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FWA8408 and is the answer not in the manual?

Questions and answers

Related Manuals for IBASE Technology FWA8408

Summary of Contents for IBASE Technology FWA8408

  • Page 1 FWA8408 FWA8406 1U Rackmount Network Appliance User’s Manual Version 1.0 (Aug. 2017)
  • Page 2 No part of this publication may be reproduced, copied, stored in a retrieval system, translated into any language or transmitted in any form or by any means, electronic, mechanical, photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc. (hereinafter referred to as “IBASE”).

  • Page 3: Compliance

    0.1% by weight (1000 ppm) except for cadmium, limited to 0.01% by weight (100 ppm). • Lead (Pb) • Mercury (Hg) • Cadmium (Cd) • Hexavalent chromium (Cr6+) • Polybrominated biphenyls (PBB) • Polybrominated diphenyl ether (PBDE) FWA8408 & FWA8406 User Manual...

  • Page 4: Important Safety Information

    You are not suggested to disassemble, repair or make any modification to the device. Disassembly, modification, or any attempt at repair could generate hazards and cause damage to the device, even bodily injury or property damage, and will void any warranty. FWA8408 & FWA8406 User Manual...

  • Page 5: Caution

    Software in use (such as OS and application software, including the version numbers) 3. If repair service is required, you can download the RMA form at http://www.ibase.com.tw/english/Supports/RMAService/. Fill out the form and contact your distributor or sales representative. FWA8408 & FWA8406 User Manual...

  • Page 6: Table Of Contents

    Jumpers Quick Reference ..............24 2.4.1 ME Register Clearance (JBAT3) .......... 24 2.4.2 CMOS Data Clearance (JBAT4) ........... 25 Connectors Quick Reference ..............26 2.5.1 System Function Connector (JP3) ........27 2.5.2 Digital I/O Port (JP4) ............29 FWA8408 & FWA8406 User Manual...
  • Page 7 BMC SOL Function ..............47 3.8.2 BMC Network Configuration ........... 48 Appendix ...................... 49 I/O Port Address Map ................50 Interrupt Request Lines (IRQ) ............... 55 Digital I/O Sample Code ................ 59 Watchdog Timer Configuration .............. 64 FWA8408 & FWA8406 User Manual...

  • Page 8: Chapter 1 General Information

    Chapter 1 General Information The information provided in this chapter includes: • Features • Packing List • Optional Accessories • Specifications • Overview • Dimensions...

  • Page 9: Introduction

    1.1 Introduction FWA8408 & FWA8406 series are specifically designed for the network security and management market. There are plenty of applications adopting network security or network management as listed below. FWA8408 & FWA8406 include the following models: • FWA8408 (with a single PSU) •...

  • Page 10: Features

    DDR4 DIMM 2133 MHz (ECC supported per CPU SKUs) • GbE LAN ports with 2 advanced LAN Bypass pairs • Optional IPMI 2.0 module to output through VGA port for FWA8408 • CF slot and PCIe (x8) expansion slot(s) •...

  • Page 11: Specifications

    Steel with textured black color paint Dimensions 438 x 44 x 422 mm (17.24” x 1.73” x 16.61”) (W x H x D) Weight 9 kg (19.84 lb) Certificate CE / FCC Class A / LVD FWA8408 & FWA8406 User Manual...
  • Page 12 (for FWA8408 & FWA8406) AC Power • Inlet 2 x AC inlet 100 ~ 240V, full range 300W, 1+1 redundant power supply (for FWA8408-RPSU & FWA8406-RPSU) 1 x CF slot Display 1 x VGA port (Reserved and optional) 3 x system fan module •...

  • Page 13: Overview

    1.6 Overview Front View Name Name LCM Display with 4 buttons Reserved Area (FWA8408: for IBN module or FWA8406: for HDD) LED Indicators USB 3.0 Ports (from top to bottom: Status, HDD, Power) Console Port Factory Default Button (GPIO Signal)
  • Page 14 General Information Rear View • Models with redundant PSUs (FWA8408-RPSU / FWA8406-RPSU) • Models with a single PSU (FWA8408 / FWA8406) Name Name Expansion Slots Power Switch VGA Port Single PSU / Reduntant PSU (Reserved & optional) System Fans Alarm Beep...

  • Page 15: Dimensions

    1.7 Dimensions Unit: mm • FWA8408-RPSU FWA8408 & FWA8406 User Manual...
  • Page 16 General Information Unit: mm • FWA8408 FWA8408 & FWA8406 User Manual...
  • Page 17 Unit: mm • FWA8406-RPSU FWA8408 & FWA8406 User Manual...
  • Page 18 General Information Unit: mm • FWA8406 FWA8408 & FWA8406 User Manual...

  • Page 19: Chapter 2 Hardware Configuration

    Chapter 2 Hardware Configuration The information provided in this chapter includes: • Essential installations before you begin • Information and locations of connectors...

  • Page 20: Essential Installations Before You Begin

    IPMI card & mini-PCIe card (IPMI & mini-PCIe slots are both available for FWA8408 only), fans, you need to disassemble the device cover first by loosening 6 screws. This is illustrated by the example of FWA8408 as below. Configuration inside FWA8408 & FWA8406: Areas A and B allow for optional HDD/SSD and expansion cards installation.

  • Page 21: Cpu Installation / Replacement

    Then you can install the CPU cooler and fan back. Note: Ensure that the CPU cooler and the CPU top surface are in total contact to avoid CPU overheating problem that would cause your system to hang or be unstable. FWA8408 & FWA8406 User Manual...

  • Page 22: Memory Installation / Replacement

    4. Gently push the module in an upright position until the ejector tabs of the memory slot close to hold the module in place when the module touches the bottom of the slot. To remove the module, press the ejector tabs outwards with your fingertips to eject the module. FWA8408 & FWA8406 User Manual...

  • Page 23: Hdd Installation / Replacement

    1. Remove 4 screws for each HDD/SSD (8 screws for two HDD/SSD) and take out from the tray. 2. Install a new HDD/SDD onto the tray and fasten 4 screws for each HDD/SDD. FWA8408 & FWA8406 User Manual...
  • Page 24 Hardware Configuration 3. Secure the tray with HDD from the bottom of the device. Note the screw holes for different sizes of HDD/SSD as ilustrated below. FWA8408 & FWA8406 User Manual...

  • Page 25: Cf Card & Ipmi Module Installation / Replacement

    CF card: Locate the CF slot and Insert the CF card to the slot. To remove the CF card or IPMI module, pull it out with your thumb and index finger directly. FWA8408 & FWA8406 User Manual...

  • Page 26: Fan Module Installation / Replacement

    Redundant Power Supply Unit Installation / Replacement If you need to install or replace a redundant power supply unit, push the latch downwards, grasp the handle, pull the PSU out carefully and replace with a new one. FWA8408 & FWA8406 User Manual...

  • Page 27: Ibn Module Installation / Replacement

    2.1.7 IBN Module Installation / Replacement IBN module is optional for FWA8408 only. To install or replace an IBN module, follow the steps below. 1. Remove the IBN door by releasing two screws as below. 2. Install the module into the device.

  • Page 28: Setting The Jumpers

    Hardware Configuration 2.2 Setting the Jumpers Set up and configure your FWA8408 & FWA8406 by using jumpers for various settings and features according to your needs and applications. Contact your supplier if you have doubts about the best configuration for your use.

  • Page 29: Jumper & Connector Locations On Motherboard

    2.3 Jumper & Connector Locations on Motherboard Motherboard: MBN800-8L FWA8408 & FWA8406 User Manual...
  • Page 30 Hardware Configuration Motherboard: MBN800-6L FWA8408 & FWA8406 User Manual...

  • Page 31: Jumpers Quick Reference

    2.4 Jumpers Quick Reference Function Connector Name Page ME Register Clearance JBAT3 CMOS Data Clearance JBAT4 2.4.1 ME Register Clearance (JBAT3) Function Pin closed Illustration Normal (default) Clear ME Register FWA8408 & FWA8406 User Manual...

  • Page 32: Cmos Data Clearance (Jbat4)

    Hardware Configuration 2.4.2 CMOS Data Clearance (JBAT4) Function Pin closed Illustration Normal (default) Clear CMOS FWA8408 & FWA8406 User Manual...

  • Page 33: Connectors Quick Reference

    External VGA Port IPMI Connector* M.2 M2280 Slot* Mini-PCIe Slot* USB 3.0 Port DDR4 Slot FWA8408: J4, J5, J6, J7 FWA8406: J5, J7 LAN Port FWA8408: U61 (quadruple), CN7, CN8, CN9, CN10 (single) FWA8406: U61 (quadruple), CN7, CN8 (single) CF Card Slot SATA 3.0 Port...

  • Page 34: System Function Connector (Jp3)

    BYPASS8_LED- 5VDUAL BYPASS9_LED- ATXPWR_BTN# FRST_OUT VCC3_3 -HDD_LED JP3 is utilized for system indicators to provide light indication of the computer activities and switches to change the computer status. It provides interfaces for the following functions. FWA8408 & FWA8406 User Manual...
  • Page 35 Bypass LED1 (Pins 9 and 10) The two pins make an external LED connector light for LAN bypass. • Bypass LED2 (Pins 11 and 12) The two pins make an external LED connector light for LAN bypass. FWA8408 & FWA8406 User Manual...

  • Page 36: Digital I/O Port (Jp4)

    Hardware Configuration 2.5.2 Digital I/O Port (JP4) Assigment Assigment 5VDUAL INT0_SIOGP22 INT0_SIOGP25 INT0_SIOGP23 INT0_SIOGP26 INT0_SIOGP24 INT0_SIOGP27 FWA8408 & FWA8406 User Manual...

  • Page 37: Chapter 3 Bios Setup

    Chapter 3 BIOS Setup This chapter the different settings available in the AMI describes BIOS that comes with the board. The topics covered in this chapter are as follows: • Main Settings • Advanced Settings • Chipset Settings • Security Settings •...

  • Page 38: Introduction

    These defaults have been carefully chosen by both AMI and your system manufacturer to provide the absolute maximum performance and reliability. Changing the defaults could make the system unstable and crash in some cases. FWA8408 & FWA8406 User Manual...

  • Page 39: Main Settings

    3.3 Main Settings BIOS Setting Description System Date Sets the date. Use the <Tab> key to switch between the data elements. System Time Set the time. Use the <Tab> key to switch between the data elements. FWA8408 & FWA8406 User Manual...

  • Page 40: Advanced Settings

    3.4.1 CPU Configuration BIOS Setting Description Intel(R) SpeedStep (tm) Enables / Disables the function to allow more than two frequency ranges to be supported. Turbo Mode Enables / Disables Turbo Mode. FWA8408 & FWA8406 User Manual...

  • Page 41: Trusted Computing

    TPM. Reset of platform is required. Note: This feature is not supported on IB990AF-C236. Pending operation Schedule an operation for the security device. Note: Your computer will reboot during restart in order to change the state of security device. FWA8408 & FWA8406 User Manual...

  • Page 42: Sata Configuration

    Gen1 / Gen2 / Gen3. Serial ATA Port 0~4 Enables / Disables Serial Port 0 ~ 5. 3.4.4 SMART Setting BIOS Setting Description SMART Selft Test Enables / Disables SMART selft test on all HDDs during POST. FWA8408 & FWA8406 User Manual...

  • Page 43: Nct5523D Super Io Configuration

    You can enable / disable the serial port and select an optimal settings for the Super IO device. Restore AC Power Loss Chooses an AC power state to apply after a power failure. Options: Power On, Power Off, Last State FWA8408 & FWA8406 User Manual...
  • Page 44 IO=2F8h ; IRQ=3, 4, 5, 6, 7, 9. 10, 11, 12 • IO=3E8h ; IRQ=3, 4, 5, 6, 7, 9. 10, 11, 12 • IO=2E8h ; IRQ=3, 4, 5, 6, 7, 9. 10, 11, 12 FWA8408 & FWA8406 User Manual...
  • Page 45 IO=2F8h ; IRQ=3, 4, 5, 6, 7, 9. 10, 11, 12 • IO=3E8h ; IRQ=3, 4, 5, 6, 7, 9. 10, 11, 12 • IO=2E8h ; IRQ=3, 4, 5, 6, 7, 9. 10, 11, 12 FWA8408 & FWA8406 User Manual...

  • Page 46: Hardware Monitor

    85°C, 90°C, 95°C Temperatures / Voltages These fields are the parameters of the hardware monitoring function feature of the motherboard. The values are read-only as monitored by the system and showing the PC health status FWA8408 & FWA8406 User Manual...

  • Page 47: Lan Bypass Configuration

    Options: Bypass, Normal, Firewall, Custom Define 3.4.8 Console Port Configuration BIOS Setting Description Console Redirection Enables / Disables console redirection. Console Redirection Sets up the terminal type, bits, parity, flow control, Settings combo key, recorder mode, resolution and putty keypad. FWA8408 & FWA8406 User Manual...
  • Page 48 Enabling this mode allows only text to be sent. This is to capture terminal data. Resolution 100x31 Enables / Disables extended terminal resolution. Putty Keypad Selects function eky and keypad on Putty. Options: VT100, Linux, XTERMR6, SC0, ESCN, VT400 FWA8408 & FWA8406 User Manual...

  • Page 49: Usb Configuration

    XHCI Hand-pff This is a workaround for OSes without XHCI hand-off support. The XHCI ownership change should be claimed by XHCI driver. USB Mass Storage Driver Enables / Disables USB mass storage driver Support support. FWA8408 & FWA8406 User Manual...

  • Page 50: Security Settings

    BIOS Setup 3.5 Security Settings BIOS Setting Description Administrator Password Sets an administrator password for the setup utility. User Password Sets a user password. FWA8408 & FWA8406 User Manual...

  • Page 51: Boot Settings

    Enables / Disables Quiet Boot option. New Boot Option Policy Controls the placement of newly detected UEFI boot options. Options: Default, Place First, Place Last Boot Option Priorities Sets the system boot order priorities for hard disk, CD/DVD, USB, Network. FWA8408 & FWA8406 User Manual...

  • Page 52: Save & Exit Settings

    Description Save Changes and Reset Resets the system after saving the changes. Discard Changes and Resets system setup without saving any Reset changes. Restore Defaults Restores / Loads defaults values for all the setup options. FWA8408 & FWA8406 User Manual...

  • Page 53: Server Management

    30 seconds to initialize Host to BMC. BMC SOL Function Enables / Disables BMC Sol features. System Event Log Erases log options. Options: Yes (on every reset), No BMC network Configures IPV4 and IPV6 support. Configuration FWA8408 & FWA8406 User Manual...

  • Page 54: Bmc Sol Function

    Chooses options for reactions to a full SEL. Options: Do nothing, Erase Immediately Log EFI Status Codes Disables the logging of EFI status codes or log only error code or only progress code or both. Option: Disables, Both, Error Code, Progress Code FWA8408 & FWA8406 User Manual...

  • Page 55: Bmc Network Configuration

    (by BIOS or BMC). Options: Unspecified, Static, DynamicBmcDhcp, DynamicBmcNonDhcp BIOS Setting Description IPV6 Support Enables / Disables LAN1 IPV6 support. Configuration Address Configures LAN channel parameters statically or Source dynamically (by BIOS or BMC). Options: Unspecified, Static, DynamicBmcDhcp FWA8408 & FWA8406 User Manual...

  • Page 56: Appendix

    Appendix This section provides the mapping addresses of peripheral devices and the sample code of watchdog timer configuration. • I/O Port Address Map • Interrupt Request Lines (IRQ) • Watchdog Timer Configuration...

  • Page 57: I/O Port Address Map

    Intel(R) 100 Series/C230 Series Chipset Family PCI Express Root Port #9 - A118 0x00000040-0x00000043 System timer 0x00000050-0x00000053 System timer 0x00000800-0x0000087F Motherboard resources 0x0000A000-0x0000AFFF Intel(R) 100 Series/C230 Series Chipset Family PCI Express Root Port #6 - A115 FWA8408 & FWA8406 User Manual...
  • Page 58 Programmable interrupt controller 0x000000B4-0x000000B5 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000004D0-0x000004D1 Programmable interrupt controller 0x00009000-0x00009FFF Intel(R) 100 Series/C230 Series Chipset Family PCI Express Root Port #5 - A114 0x00001854-0x00001857 Motherboard resources FWA8408 & FWA8406 User Manual...
  • Page 59 0x0000004E-0x0000004F Motherboard resources 0x00000061-0x00000061 Motherboard resources 0x00000063-0x00000063 Motherboard resources 0x00000065-0x00000065 Motherboard resources 0x00000067-0x00000067 Motherboard resources 0x00000070-0x00000070 Motherboard resources 0x00000070-0x00000070 System CMOS/real time clock 0x00000080-0x00000080 Motherboard resources 0x00000092-0x00000092 Motherboard resources 0x000000B2-0x000000B3 Motherboard resources 0x00000680-0x0000069F Motherboard resources FWA8408 & FWA8406 User Manual...
  • Page 60 Intel(R) HD Graphics 630 0x000003C0-0x000003DF Intel(R) HD Graphics 630 0x0000FF00-0x0000FFFE Motherboard resources 0x0000E000-0x0000EFFF Intel(R) 100 Series/C230 Series Chipset Family PCI Express Root Port #10 - A119 0x0000F060-0x0000F07F Intel(R) 100 Series/C230 Series Chipset Family SMBus - A123 FWA8408 & FWA8406 User Manual...
  • Page 61 0x000000A4-0x000000A5 Programmable interrupt controller 0x000000A8-0x000000A9 Programmable interrupt controller 0x000000AC-0x000000AD Programmable interrupt controller 0x000000B0-0x000000B1 Programmable interrupt controller 0x000000B4-0x000000B5 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000004D0-0x000004D1 Programmable interrupt controller 0x00001854-0x00001857 Motherboard resources FWA8408 & FWA8406 User Manual...

  • Page 62: Interrupt Request Lines (Irq)

    Intel(R) I210 Gigabit Network Connection #4 IRQ 4294967262 IRQ 4294967263 ~ Intel(R) I210 Gigabit Network Connection #3 IRQ 4294967268 IRQ 4294967269 Intel(R) USB 3.0 eXtensible Host Controller - 1.0 (Microsoft) IRQ 4294967270 Intel(R) HD Graphics 630 FWA8408 & FWA8406 User Manual...
  • Page 63 Core(TM) PCIe Controller (x4) - 1909 IRQ 4294967293 Intel(R) Xeon(R) E3 - 1200/1500 v5/6th Gen Intel(R) Core(TM) PCIe Controller (x8) - 1905 IRQ 4294967294 Intel(R) Xeon(R) E3 - 1200/1500 v5/6th Gen Intel(R) Core(TM) PCIe Controller (x16) - 1901 FWA8408 & FWA8406 User Manual...
  • Page 64 Intel(R) I211 Gigabit Network Connection #4 4294967280 IRQ 4294967281 ~ IRQ Intel(R) I211 Gigabit Network Connection 4294967286 IRQ 4294967287 Standard SATA AHCI Controller IRQ 4294967288 Intel(R) 100 Series/C230 Series Chipset Family PCI Express Root Port #10 - A119 FWA8408 & FWA8406 User Manual...
  • Page 65 Family PCI Express Root Port #6 - A115 IRQ 4294967293 Intel(R) 100 Series/C230 Series Chipset Family PCI Express Root Port #5 - A114 IRQ 4294967294 Intel(R) Xeon(R) E3 - 1200/1500 v5/6th Gen Intel(R) Core(TM) PCIe Controller (x16) - 1901 FWA8408 & FWA8406 User Manual...

  • Page 66: Digital I/O Sample Code

    NCT5523D_DATA_PORT (NCT5523D_BASE+1) //--------------------------------------------------------------------------- #define NCT5523D_REG_LD 0x07 //--------------------------------------------------------------------------- #define NCT5523D_UNLOCK 0x87 #define NCT5523D_LOCK 0xAA //--------------------------------------------------------------------------- unsigned int Init_NCT5523D(void); void Set_NCT5523D_LD( unsigned char); void Set_NCT5523D_Reg( unsigned char, unsigned char); unsigned char Get_NCT5523D_Reg( unsigned char); //--------------------------------------------------------------------------- #endif //__NCT5523D_H FWA8408 & FWA8406 User Manual...
  • Page 67 Dio5Initial(); //for GPIO20..27 Dio5SetDirection(0x0F); //GP20..23 = input, GP24..27=output printf("Current DIO direction = 0x%X\n", Dio5GetDirection()); printf("Current DIO status = 0x%X\n", Dio5GetInput()); printf("Set DIO output to high\n"); Dio5SetOutput(0x0F); printf("Set DIO output to low\n"); Dio5SetOutput(0x00); return 0; //--------------------------------------------------------------------------- FWA8408 & FWA8406 User Manual...
  • Page 68 //NewData : 1 for input, 0 for output Set_NCT5523D_LD(0x07); //switch to logic device 7 Set_NCT5523D_Reg(0xE8, NewData); //--------------------------------------------------------------------------- unsigned char Dio5GetDirection(void) unsigned char result; Set_NCT5523D_LD(0x07); //switch to logic device 7 result = Get_NCT5523D_Reg(0xE8); return (result); //--------------------------------------------------------------------------- FWA8408 & FWA8406 User Manual...
  • Page 69 = Get_NCT5523D_Reg(0x20); if (ucDid == 0xC4) //NCT5523D?? goto Init_Finish; } NCT5523D_BASE = 0x00; result = NCT5523D_BASE; Init_Finish: return (result); //--------------------------------------------------------------------------- void Unlock_NCT5523D (void) outportb(NCT5523D_INDEX_PORT, NCT5523D_UNLOCK); outportb(NCT5523D_INDEX_PORT, NCT5523D_UNLOCK); //--------------------------------------------------------------------------- void Lock_NCT5523D (void) outportb(NCT5523D_INDEX_PORT, NCT5523D_LOCK); //--------------------------------------------------------------------------- FWA8408 & FWA8406 User Manual...
  • Page 70 Lock_NCT5523D(); //--------------------------------------------------------------------------- void Set_NCT5523D_Reg( unsigned char REG, unsigned char DATA) Unlock_NCT5523D(); outportb(NCT5523D_INDEX_PORT, REG); outportb(NCT5523D_DATA_PORT, DATA); Lock_NCT5523D(); //--------------------------------------------------------------------------- unsigned char Get_NCT5523D_Reg(unsigned char REG) unsigned char Result; Unlock_NCT5523D(); outportb(NCT5523D_INDEX_PORT, REG); Result = inportb(NCT5523D_DATA_PORT); Lock_NCT5523D(); return Result; //--------------------------------------------------------------------------- FWA8408 & FWA8406 User Manual...

  • Page 71: Watchdog Timer Configuration

    NCT5523D_DATA_PORT (NCT5523D_BASE+1) //--------------------------------------------------------------------------- #define NCT5523D_REG_LD 0x07 //--------------------------------------------------------------------------- #define NCT5523D_UNLOCK 0x87 #define NCT5523D_LOCK 0xAA //--------------------------------------------------------------------------- unsigned int Init_NCT5523D(void); void Set_NCT5523D_LD( unsigned char); void Set_NCT5523D_Reg( unsigned char, unsigned char); unsigned char Get_NCT5523D_Reg( unsigned char); //--------------------------------------------------------------------------- #endif //__NCT5523D_H FWA8408 & FWA8406 User Manual...
  • Page 72 Nuvoton NCT5523D, program abort.\n"); return(1); WDTInitial(); WDTEnable(10); WDTDisable(); return 0; //--------------------------------------------------------------------------- void WDTInitial(void) unsigned char bBuf; Set_NCT5523D_LD(0x08); //switch to logic device 8 bBuf = Get_NCT5523D_Reg(0x30); bBuf &= (~0x01); Set_NCT5523D_Reg(0x30, bBuf); //Enable WDTO //--------------------------------------------------------------------------- FWA8408 & FWA8406 User Manual...
  • Page 73 = Get_NCT5523D_Reg(0xF0); bBuf &= (~0x08); Set_NCT5523D_Reg(0xF0, bBuf); //count mode is second Set_NCT5523D_Reg(0xF1, NewInterval); //set timer //--------------------------------------------------------------------------- void WDTDisable(void) Set_NCT5523D_LD(0x08); //switch to logic device 8 Set_NCT5523D_Reg(0xF1, 0x00); //clear watchdog timer Set_NCT5523D_Reg(0x30, 0x00); //watchdog disabled //--------------------------------------------------------------------------- FWA8408 & FWA8406 User Manual...
  • Page 74 NCT5523D_BASE = 0x2E; result = NCT5523D_BASE; ucDid = Get_NCT5523D_Reg(0x20); if (ucDid == 0xC4) //NCT5523D?? goto Init_Finish; } NCT5523D_BASE = 0x00; result = NCT5523D_BASE; Init_Finish: return (result); //--------------------------------------------------------------------------- void Unlock_NCT5523D (void) outportb(NCT5523D_INDEX_PORT, NCT5523D_UNLOCK); outportb(NCT5523D_INDEX_PORT, NCT5523D_UNLOCK); //--------------------------------------------------------------------------- FWA8408 & FWA8406 User Manual...
  • Page 75 Lock_NCT5523D(); //--------------------------------------------------------------------------- void Set_NCT5523D_Reg( unsigned char REG, unsigned char DATA) Unlock_NCT5523D(); outportb(NCT5523D_INDEX_PORT, REG); outportb(NCT5523D_DATA_PORT, DATA); Lock_NCT5523D(); //--------------------------------------------------------------------------- unsigned char Get_NCT5523D_Reg(unsigned char REG) unsigned char Result; Unlock_NCT5523D(); outportb(NCT5523D_INDEX_PORT, REG); Result = inportb(NCT5523D_DATA_PORT); Lock_NCT5523D(); return Result; //----------------------------------------------------------------------- FWA8408 & FWA8406 User Manual...
