- Page 1 Network IP Digital Media Player ID # 516 Operation Manual...
- Page 2 Introduction The Network IP Digital Media Player provides the solution for both file data transfer and update via the Internet and being able to access your picture, movie and audio files without a PC. Fully compatible with most Internet network connections like Ethernet, Fixed IP address, ADSL PPPoE, Dynamic IP(DDNS) etc.
- Page 3 Connection IR SENSOR : Infrared input of remote controller. POWER ON/OFF and LED : Switch and Power indicative LED NTSC/PAL : Selects NTSC or PAL video, system. Stop/ Ray/Pause : Audio or video display will be stop or restart. t/Right To select item on the OSD Menu.
- Page 4 S-TIME : Slide show time adjustment 1; 3; 5,10, 30, 60 seconds. S-MODE: Slideshow effect with sequential, random etc S-MUSIC: Select the background music when slideshow. ROTATE/ZOOM/MIRROR : Select the effect of display OUTPUT MODE : selection video, s-v deo, YCbCr, YPbPr and VGA output.. Remote Control...
- Page 5 Plug your RJ-45 cable into your router...
- Page 6 in the CD." and click "Update" • Execute the "IpEdit.exe" "http://19 2.168.1 .100/" has been listed in the left side, and double click "...http://19 2.168.1. 100/" to login the IP Controller Edit the IP Address, t is depend on your router, if your router IP is •...
- Page 7 Log in from Internet all over the world: Execute Internet Explorer and type the Real IP address used by the router ex : http://61.30.13.14.80/” or http://61.3.13.40/ If you cant connect to the FTP folder, Please Add or Remove the item Internet Explorer->Internet Options->Advanced->Use Passive FTP (for firewall modem capability) then close the FTP folder and try one more time.
- Page 8 If you also cant connect to the FTP folder, please refer to HELP 4.3 Limitation of FTP Protocol on the CD Specifications 1. -Video System: NTSC/PAL. 2. -Video Outputs: Composite, S-Video, VGA 15 pin D-sub. 3. -Audio Outputs: RCA Phono-jack. 4.
