STOCKWELL - PORTABLE STEREO LOUDSPEAKER

USER MANUAL

WWW.MARSHALLHEADPHONES.COM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Marshall STOCKWELL and is the answer not in the manual?

Questions and answers

Summary of Contents for Zounds Marshall STOCKWELL

  • Page 1: User Manual

    STOCKWELL - PORTABLE STEREO LOUDSPEAKER USER MANUAL WWW.MARSHALLHEADPHONES.COM...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS • Read these instructions – All the safety and operating instructions should be read before this product is operated. • Keep these instructions – The safety and operating instructions should be retained for future reference. • Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to. •...

  • Page 3: Fcc Statement

    COMPLIANCE MARKS CAUTION: To prevent the risk of electric shock, do not remove cover (or back plate). There are no user serviceable parts inside. Refer servicing to qualified service personnel. This appliance may not be treated as regular household waste. Management of WEEE (Waste Electrical and Electronic Equipment) is applicable in member states of the European Union and other European countries with individual national policies on the management of...

  • Page 4: Compliance Marks

    COMPLIANCE MARKS received, including interference may cause undesired operation. IC Statement ICC Statement The content of this document is for information purposes only. Zound Industries reserves the right to change information without prior notifications and at any time. Hereby, Zound Industries International AB, declares that this [insert product info] is in compli ance with the essential requirements and other relevant provisions of Directive...

  • Page 5: Table Of Contents

    INDEX ENGLISH SECTIONS PAGE 002. IMPORTANT SAFETY INSTRUCTIONS 003. COMPLIANCE MARKS 005. LANGUAGE INDEX 006. BOX CONTENTS 007. DEVICE LAYOUT 008. CHANGING THE POWER ADAPTER PLUG 009. PLUGGING IN AND CHARGING THE STOCKWELL 011. TURNING THE POWER ON/OFF 012. USING THE STOCKWELL WITH YOUR DEVICES 014.

  • Page 6: Language Index

    LANGUAGE INDEX FRENCH - FRANÇAIS TRADITIONAL CHINESE - PAGE 032 PAGE 224 JAPANESE - 日本語 FINNISH - SUOMI PAGE 064 PAGE 225 RUSSIAN - РУССКИЙ GERMAN - DEUTSCH PAGE 288 PAGE 096 SPANISH - ESPAÑOL DUTCH - NEDERLANDS PAGE 128 PAGE 320 PORTUGUESE - PORTUGUÊS ITALIAN - ITALIANO...

  • Page 7: Box Contents

    001. POWER ADAPTER WITH A CORD AND REGION SPECIFIC PLUGS 002. DOUBLE-ENDED COIL CORD WITH 3.5MM STEREO PLUGS TO CONNECT TO YOUR MUSIC PLAYER 003. QUICK START USER MANUAL AND SAFETY INFORMATION 004. MARSHALL STOCKWELL ACTIVE STEREO LOUDSPEAKER 005. MARSHALL FOLDABLE FLIP COVER (OPTIONAL) 003. 001.

  • Page 8: Device Layout

    DEVICE LAYOUT 001. INPUT FOR 3.5MM STEREO PLUG 006. TREBLE KNOB 002. SOURCE BUTTON 007. PHONE BUTTON 003. SOURCE INDICATORS 008. PAIR BUTTON 004. VOLUME KNOB 009. POWER BUTTON 005. BASS KNOB 010. ON/OFF INDICATOR...

  • Page 9: Changing The Power Adapter Plug

    CHANGING THE POWER ADAPTER PLUG THE INCLUDED 15V POWER ADAPTER COMES WITH THREE INTERCHANGEABLE PLUGS (US/EU/UK). BEFORE USING THE STOCKWELL, ENSURE THAT THE CORRECT PLUG FOR YOUR REGION IS INSTALLED. 001. PUSH AND HOLD THE BUTTON NEXT TO THE PLUG WHILE TURNING THE PLUG SLIGHTLY ANTICLOCKWISE.

  • Page 10: Plugging In And Charging The Stockwell

    PLUGGING IN AND CHARGING THE STOCKWELL THE STOCKWELL IS EQUIPPED WITH AN INTERNAL BATTERY SUPPORTING A PLAYING TIME FOR UP TO 25 HOURS AT MID VOLUME. THE BATTERY IS RECHARGEABLE AND CAN BE FULLY CHARGED IN 3 HOURS, WHEN COMPLETELY DISCHARGED.
  • Page 11 PLUGGING IN AND CHARGING THE STOCKWELL 001. THE RED ON/OFF INDICATOR FLASHES WHEN THE BATTERY IS CHARGING. 002. THE RED ON/OFF INDICATOR STAYS LIT WHEN CHARGING IS DONE. 001. 001. 002. 002. NOTE: THE SPEAKER CAN BE USED WHILE CHARGING THE BATTERY.

  • Page 12: Turning The Power On/Off

    TURNING THE POWER ON/OFF 001. PUSH AND HOLD POWER BUTTON FOR 1 SECOND TO TURN ON THE SPEAKER. 002. THE RED ON/OFF INDICATOR ON TOP PANEL LIGHTS UP. 003. PUSH AND HOLD THE POWER BUTTON FOR 3 SECONDS TO TURN OFF THE SPEAKER.

  • Page 13: Using The Stockwell With Your Devices

    USING THE STOCKWELL WITH YOUR DEVICES THERE ARE TWO WAYS TO CONNECT YOUR PHONE, TABLET, LAPTOP TO YOUR SPEAKER, WHETHER USING A PHYSICAL CORD OR VIA WIRELESS BLUETOOTH ® BELOW YOU WILL FIND MORE DETAILS ABOUT THE CONNECTION SOURCES, IN TWO CATEGORIES: •...
  • Page 14 USING THE STOCKWELL WITH YOUR DEVICES THE STOCKWELL HAS A USB POWER OUTPUT SOCKET ON THE BACK. YOU CAN PLUG IN AND CHARGE YOUR USB CHARGEABLE DEVICE. THE STOCKWELL WILL POWER YOUR USB DEVICE EVEN THOUGH IT IS PLAYING MUSIC AND RUNNING ON BATTERY POWER.

  • Page 15: Connecting Via Bluetooth (Pairing)

    CONNECTING VIA BLUETOOTH (PAIRING) WITH THE HELP OF BLUETOOTH TECHNOLOGY YOU CAN EASILY CONNECT YOUR BLUETOOTH-COMPATIBLE DEVICES TO THE STOCKWELL OVER A SHORT RANGE WIRELESS CONNECTION. THIS ALLOWS YOU TO USE THE STOCKWELL AS A SPEAKER PHONE WITH YOUR BLUETOOTH-ENABLED SMARTPHONE OR CONNECT IT WITH A TABLET OR COMPUTER AND STREAM MUSIC DIRECTLY TO IT.
  • Page 16 CONNECTING VIA BLUETOOTH (PAIRING) 004. ENABLE BLUETOOTH FUNCTIONALITY ON YOUR DEVICE. (SMARTPHONE, TABLET, COMPUTER). 005. ON YOUR DEVICE, SELECT THE STOCKWELL FROM THE BLUETOOTH LIST AND ACCEPT PAIRING. 006. THE BLUETOOTH INDICATOR ON THE STOCKWELL TURNS TO A STEADY RED AND THE UNITS ARE NOW CONNECTED.

  • Page 17: Bluetooth Auto Connection

    BLUETOOTH AUTO CONNECTION IF A BLUETOOTH CONNECTED DEVICE IS MOVED OUTSIDE THE RANGE OF THE STOCKWELL (APPROXIMATELY 10 METRES WITHOUT OBSTACLES), IT IS DISCONNECTED. THE DEVICE IS AUTOMATICALLY CONNECTED AGAIN WHEN IT IS MOVED BACK WITHIN RANGE. THE SPEAKER STORES UP TO FIVE DEVICES AND TRIES TO CONNECT TO THE LAST CONNECTED BLUETOOTH DEVICE FIRST.

  • Page 18: Connecting Sound Source By Cable

    CONNECTING SOUND SOURCE BY CABLE THERE IS ANOTHER WAY TO CONNECT TO YOUR STOCKWELL – THE OLD FASHIONED WAY, USING THE INCLUDED COIL CORD AND THE 3.5MM INPUT. USE THE DOUBLE-ENDED COIL CORD WITH 3.5MM PLUGS TO CONNECT TO AUDIO SOURCES THAT HAVE AUDIO OUTPUT SUCH AS A MOBILE TELEPHONE, IPHONE/ IPAD/IPOD, MP3 PLAYER, OR AIRPORT EXPRESS.
  • Page 19 CONNECTING SOUND SOURCE BY CABLE 001. CONNECT THE CORD WITH THE 3.5MM STEREO PLUG TO THE INPUT ON THE STOCKWELL. 002. CONNECT THE CORD WITH THE 3.5MM STEREO PLUG TO THE MUSIC PLAYER. 003. SELECT INPUT AS SOURCE BY PUSHING THE SOURCE BUTTON UNTIL THE INPUT INDICATOR IS LIT 001.

  • Page 20: Choosing Your Source

    CHOOSING YOUR SOURCE THE INPUT SOURCE THAT IS CURRENTLY SELECTED IS SHOWN BY A LIT INDICATOR. TO SELECT A DIFFERENT SOUND SOURCE: 001. PUSH THE SOURCE BUTTON TO CHOOSE BETWEEN BLUETOOTH AND 3.5MM STEREO PLUG. 002. A LIT INDICATOR SHOWS WHICH SOURCE YOU HAVE SELECTED. •...

  • Page 21: Using The Stockwell In Speaker Phone Mode

    USING THE STOCKWELL IN SPEAKER PHONE MODE THE STOCKWELL CAN BE USED AS A SPEAKER PHONE. WHEN CONNECTED TO A PHONE THROUGH BLUETOOTH, YOUR RINGTONE WILL SOUND IN THE STOCKWELL. 001. TO ANSWER AN INCOMING CALL, PUSH THE PHONE BUTTON ONCE. 002.

  • Page 22: Adjusting The Sound

    ADJUSTING THE SOUND THE SOUND OF THE STOCKWELL CAN BE ADJUSTED BY TURNING THE RETRACTABLE VOLUME, BASS AND TREBLE KNOBS. 001. PUSH THE RETRACTABLE KNOB FOR IT TO POP UP. 002. TURN THE KNOB TO ADJUST THE SOUND TO YOUR LIKING. 003.
  • Page 23 ADJUSTING THE SOUND THE STOCKWELL HAS THREE KNOBS FOR ADJUSTING THE SOUND: 001. VOLUME KNOB 002. BASS KNOB 003. TREBLE KNOB 001. 002. 003. 001. 002. 003.

  • Page 24: Replacing The Internal Battery

    REPLACING THE INTERNAL BATTERY IF THE INTERNAL BATTERY IS BROKEN OR WORN OUT, YOU CAN REPLACE IT WITH A NEW ONE. THE FAULTY BATTERY PACK MUST ALWAYS BE RECYCLED ACCORDING TO LOCAL LAWS AND REGULATION. 001. UNPLUG THE POWER ADAPTER FROM THE WALL SOCKET. 002.
  • Page 25 REPLACING THE INTERNAL BATTERY 005. USE A TORX SCREWDRIVER (SIZE T10) TO REMOVE THE TWO SCREWS ON THE BATTERY HATCH ON THE BACK OF THE STOCKWELL. 006. OPEN THE BATTERY HATCH AND REMOVE IT FROM THE SPEAKER. 007. PULL THE BATTERY TAB AND CAREFULLY LIFT THE BATTERY WITHOUT PULLING THE CABLE CONNECTING THE BATTERY TO THE STOCKWELL.

  • Page 26: Using The Flip Cover (Optional)

    USING THE FLIP COVER (OPTIONAL) THE FLIP COVER CAN BE FOLDED UP NEATLY ON THE BACK OF THE STOCKWELL WHEN YOU ARE USING THE SPEAKER. 001. UNFOLD THE FLIP COVER, STARTING FROM THE FRONT BOTTOM OF THE STOCKWELL ALL THE WAY OVER THE SPEAKER. 002.
  • Page 27 USING THE FLIP COVER (OPTIONAL) THE FLIP COVER CAN BE FOLDED INTO A TILT STAND FOR THE STOCKWELL. 001. UNFOLD THE FLIP COVER, STARTING FROM THE FRONT BOTTOM OF THE STOCKWELL ALL THE WAY OVER THE SPEAKER. 002. FOLD THE TOP OF THE FLIP COVER UNDER THE STOCKWELL. 003.

  • Page 28: Removing The Flip Cover (Optional)

    REMOVING THE FLIP COVER (OPTIONAL) 001. UNFOLD THE FLIP COVER, STARTING FROM THE FRONT BOTTOM OF THE STOCKWELL ALL THE WAY OVER THE SPEAKER. 002. ON THE BACK OF THE STOCKWELL, GRAB THE FLIP COVER BY THE BOTTOM AND GENTLY PULL. THE COVER IS HELD IN PLACE BY HIDDEN MAGNETS. 003.
  • Page 29 ATTACHING THE FLIP COVER (OPTIONAL) THE FLIP COVER IS SOLD SEPARATELY AND ALSO INCLUDED IN SOME MODELS OF THE STOCKWELL. IT CAN PROTECT YOUR STOCKWELL WHEN IT IS NOT IN USE AND CAN ALSO BE FOLDED TO A STAND FOR THE SPEAKER. 001.

  • Page 30: Technical Information 030

    TECHNICAL INFORMATION SOUND SPECIFICATION • ACTIVE STEREO LOUDSPEAKER WITH BASS REFLEX SYSTEM • TONE CONTROLS: - BASS: 300H , +6 B TO -12 - TREBLE: 3 , +6 B TO -12 • CLASS D AMPLIFIER: 2 • WOOFER: 2 2.25” •...

  • Page 31: Trouble Shooting

    TROUBLE SHOOTING PROBLEM CAUSE ACTION THE STOCKWELL The internal battery is Insert the power cord into WILL NOT TURN ON. the 15V power socket and discharged or the power cord is not properly the power adapter to the wall connected into a working wall socket.
  • Page 32 TROUBLE SHOOTING PROBLEM CAUSE ACTION SHARP CRACKLING/ Clipping when the amplifier Turn down the volume on the CLICKING ON STOCKWELL or on the music runs out of power. player. Reduce the bass STRONG PASSAGES/ boost. TRANSIENTS. ERRATIC Move the STOCKWELL to Interference from another PERFORMANCE.
  • Page 33 TROUBLE SHOOTING PROBLEM CAUSE ACTION BLUETOOTH The Bluetooth connection Ensure that the STOCKWELL CONNECTION IS only works when it is near and the Bluetooth device the device. The connection are within 10 meters, and BROKEN OR is automatically broken if unobstructed by obstacles DISRUPTED.
