736HPA High Pressure
Dispense Valve
INSTALLATION GUIDE
Electronic pdf files of EFD manuals are also available at
www.efd-inc.com/manuals.html.
USA & Canada: 800-556-3484 or +1-401-434-1680
Europe: 0800 585733 or +44 (0) 1582 666334
Asia: +86 (21) 5854 2345
technical@efd-inc.com www.efd-inc.com
Introduction
The 736HPA is a normally closed, air-actuated, balanced
spool-type valve designed to operate at fluid pressures
up to 2,500 psi (172 bar). Ideal for consistent dispensing
of industrial sealants and greases, the 736HPA valve is
simple to use and will operate many millions of cycles
without wear or leakage.
Control air hose
Fluid supply line
Fluid inlet fitting
Dispensing tip
®
A NORDSON COMPANY
TM
Air cylinder
body
Advertisement
Summary of Contents for EFD 736HPA
- Page 1 736HPA High Pressure ® A NORDSON COMPANY Dispense Valve INSTALLATION GUIDE Electronic pdf files of EFD manuals are also available at www.efd-inc.com/manuals.html. USA & Canada: 800-556-3484 or +1-401-434-1680 Europe: 0800 585733 or +44 (0) 1582 666334 Asia: +86 (21) 5854 2345 technical@efd-inc.com www.efd-inc.com...
- Page 2 Thread the fluid inlet fitting into the fluid the valve output or use a dispensing tip nozzle and actuate the valve until fluid inlet hole. Note: The fluid inlet fitting and adapter (#2186) with EFD SafetyLok ™ flows steady. hose must be obtained from the high dispensing tips.
- Page 3 At the end of the cycle, spring force on the piston shifts the spool to the closed position, stopping fluid flow. During the closing action, the 736HPA provides snuff-back of fluid for clean cutoff. The stroke adjustment can be used to regulate snuff-back to an amount appropriate for the fluid being dispensed.
-
Page 4: Specifications
® For consistent dispense valve operation and easy adjustment A NORDSON COMPANY of valve output, EFD recommends using the ValveMate 8000 For EFD sales and service in over 30 countries, controller on all automatic, semi-automatic and benchtop contact EFD or go to www.efd-inc.com/contact applications.
