An HDMI 201 system consists of a transmitter (Tx) and a receiver (Rx). The pair can handle a single link of HDMI digital video and a bidirectional RS-232 link. The HDMI 201 A D also converts a computer audio input into balanced or unbalanced stereo audio output.
Page 8
• HDMI 201 A D Tx/Rx — These units are housed in enclosures that can be mounted in UL standard wall boxes with decorator-style face plates. These units also convert computer level audio to balanced or unbalanced stereo audio.
Skew-free A/V cable was designed for most Extron TP transmitter/receiver applications, but the HDMI 201 Tx/Rx does not work properly with this cable. Control Communications The RS-232 or infrared (IR) communications are pass-through only; the transmitter and receiver do not generate or respond to these signals.
HDMI signal, so that the remote display can be controlled without the need for additional cabling. Audio routing — The HDMI 201 A D Tx/Rx also routes unbalanced stereo audio when both units are the decorator-style form factor.
Installation and Operation This section describes the installation and the operation of the HDMI 201, including: • Mounting the Transmitter or Receiver • Connections • Operation • Technical Points for Digital Video and Content Protection Encryption • Troubleshooting • Application Examples...
UL guidelines for rack mounting The following Underwriters Laboratories (UL) guidelines pertain to the installation of an HDMI 201 unit onto a rack. Elevated operating ambient — If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient.
Page 13
The unit can be mounted under a horizontal surface using an optional MBU 125 under- desk mounting kit. Mount the unit under a desk or table as follows: Remove feet from the bottom of the HDMI 201 unit if installed. Secure the under-desk mounting brackets to the transmitter or receiver with the four machine screws provided in the mounting kit (figure 4).
Page 14
If the screws are inaccessible to a screwdriver: Mark the location of the brackets relative to the screws. Remove the transmitter or receiver from inside the furniture. Tighten the screws. Replace the unit inside the surface (step 5). HDMI 201 • Installation and Operation...
On the front mounting plate, the device is typically mounted on the inside of the bracket. If the power supply is connected to the receiver, use the two included tie wraps to strap the power supply to one of the brackets. HDMI 201 • Installation and Operation...
Page 16
NOTE: The supplied U-bolt fits a typical (1.5 inch to 2.0 inch diameter) ceiling pole. HDMI 201 • Installation and Operation...
Page 17
NOTE: The supplied U-bolt fits a typical (1.5-inch to 2.0-inch diameter) ceiling pole. Mount Plate Flange Contoured Base U-bolt L-shaped Bracket Slotted Hole in PMK Tray L-shaped Bracket Screws Ceiling Pole Figure 9. Hanging the Tray on the Pole HDMI 201 • Installation and Operation...
Page 18
Secure the front and rear plates to the mounting tray with four of the included #6 screws. If desired, choose one of the provided four sizes of self-adhesive cover sheets, and apply it to the underside of the mounting tray. HDMI 201 • Installation and Operation...
Decorator-style Unit Mounting The HDMI 201 A D transmitter and receiver can be installed in a one-gang electrical wall box with a decorator-style wall plate cover (supplied). The installation must conform to national and local electrical codes and to the size requirements of the wall plate.
Page 20
Connect front panel devices (see Connections, later in this manual, for connector details), restore the power supply, and test the transmitter/receiver system. Make any cabling adjustments before final installation, as the cables will be inaccessible afterwards. HDMI 201 • Installation and Operation...
Page 21
-2 3 D IO edge of box. Extron HDMI 201 A D Figure 12. Mounting the Transmitter or Receiver At the power outlet, reconnect the power supply. This powers up both units. HDMI 201 • Installation and Operation...
Figure 14, on the next page, Figure 13 shows the front panel of the HDMI 201 A D Tx. shows the rear panel of both HDMI 201 Tx models. HDMI 201 A D Tx Front Panel INPUT...
Page 23
TO LAN Figure 14. HDMI 201 Tx Rear Panel Connectors Input Audio (HDMI 201 A D Tx only) connectors — Plug an unbalanced stereo audio input into this pair, left and right, of female RCA connectors (figure 15). Tip (Signal)
Page 24
5-wire audio cable to this 3.5 mm, 5-pole direct insertion connector. Connect the free end of the same cable from the transmitter to any compatibly wired unit, such as a switcher, an amplifier, or an HDMI 201 A D Rx (decorator-style) receiver (item on page 21).
UL standard wall boxes with decorator-style face plates. Figure 17 shows the rear panel of both HDMI 201 Rx models. Figure 18, on the next page, shows the front panel of the HDMI 201 A D Rx (decorator-style) receiver.
Page 26
RS-232 PASS THRU AUDIO-L Figure 18. HDMI 201 A D Rx Front Panel Connectors Receiver input ports — Connect one end of the two separate TP cables from the transmitter output connectors (item on page 18) to these RJ-45 female connectors.
Modulated IR Pass Through Application. Audio Input connector (HDMI 201 A D Rx only) — Connect one end of a 5-wire audio cable to this 3.5 mm, 5-pole direct insertion connector. Connect the free end of the same cable to any compatibly wired audio source unit, such as a output of...
A/V UTP cable to link the transmitter and receiver. Skew-free A/V cable was designed for most Extron TP transmitter/receiver applications, but the HDMI 201 Tx/Rx does not work properly with this cable. • In order to fit in the junction box, the TP cables and RJ-45 connectors should not have a boot installed.
Page 29
Feed each individual wire into the appropriate slot of the RJ-45 connector and crimp the cable in the normal manner, folding the tangs at the end of the connector over the shielded tape (figure 24). Crimped Connector Figure 24. Crimped RJ-45 Connector HDMI 201 • Installation and Operation...
Page 30
(National Electrical Code) ANSI/NFPA 70, article 725, et du Code canadien de l’électricité, partie 1, section 16. La source d’alimentation ne devra pas être fixée de façon permanente à une structure de bâtiment ou à une structure similaire. HDMI 201 • Installation and Operation...
Page 31
• Ne pas étamer les conducteurs avant de les insérer dans le connecteur. Les câbles étamés ne sont pas aussi bien fixés dans le connecteur et pourraient être retirés. HDMI 201 • Installation and Operation...
NOTE: Two units are shown. All transmitter and receiver models have power indicators in the locations shown. HDMI 201 Tx and HDMI 201 Rx Front Panel HDMI 201 A D Tx and HDMI 201 A D Rx Front Panel HDMI 201 Power...
HDMI 201 Tx (non-decorator-style) — This front panel LED lights green to indicate that the unit is receiving power: HDMI 201 A D Tx (decorator-style) — This two-color front panel LED lights to indicate signal and power status as follows: Amber —...
DTP26 cable. • The HDMI 201 works as described in point-to-point applications. Do not use any additional adapters, patch panels, or couplers with the input HDMI cables, output HDMI cables, and twisted pair cables. Additional links in the signal chain can result in the reduction of signal integrity and overall cable length performance.
Audio Conversion Figure 28 shows a standard installation with HDMI video and an audio input. The HDMI 201 A D Tx converts the video input into two proprietary TP outputs. The Tx outputs the audio directly on a captive screw connector.
2.79" (7.09 cm) Panel 1.9" (4.83 cm) 4.50" To install a (11.43 cm) 1-gang HDMI 201 A D Tx or HDMI 201 A D Rx SURFACE CUT-OUT directly into AREA FOR furniture or FURNITURE MOUNT wall, cut along this line.
Page 37
Extron Warranty Extron Electronics warrants this product against defects in materials and workmanship for a period of three years from the date of purchase. In the event of malfunction during the warranty period attributable directly to faulty workmanship and/or materials, Extron Electronics will, at its option, repair or replace said products or components, to whatever extent it shall deem necessary to restore said product to proper operating condition, provided that it is returned within the warranty period, with proof of purchase and description of malfunction to: USA, Canada, South America,...
