USER GUIDE
HOTTAP
MODEL: JCA11001
INFO.
MONITOR
IMPORTANT!
It is important that you read these instructions carefully and understand the operation and
safety features of this appliance. Familiarise yourself with the appliance before connecting it
to the gas cylinder. Failure to follow the warnings and instructions may result in damage to
unit and / or serious injury. Keep these instructions for future reference.
Advertisement
Table of Contents
Summary of Contents for JOOLCA JCA11001
- Page 1 USER GUIDE HOTTAP MODEL: JCA11001 INFO. MONITOR IMPORTANT! It is important that you read these instructions carefully and understand the operation and safety features of this appliance. Familiarise yourself with the appliance before connecting it to the gas cylinder. Failure to follow the warnings and instructions may result in damage to...
- Page 2 Guarantee Today Thank you for choosing to buy a Joolca Product. Your Joolca product will be covered for parts & labour for 2 years from the date of purchase. If you purchased directly through us, your items are already registered.
-
Page 3: Safety Warnings
This appliance is intended for the supply of heated water for the purpose of washing and cleaning only. WARNING! Check and confirm safe water temperature before using this appliance. Water from this appliance may be very hot. CAUTION! This appliance must be protected from rain. 02 JOOLCA HOTTAP – MODEL JCA11001 USER GUIDE... -
Page 4: General Information
1. HOTTAP Water Heater 4. 5M Shower Hose 7. Water Inlet & Outlet Adapters 2. Shower Head 5. Mounting Screws 8. GASKNECT Quick Coupler 3. Shower Head Holder 6. 1.2M Gas Hose 9. User Guide 03 JOOLCA HOTTAP – MODEL JCA11001 USER GUIDE... -
Page 5: Safety Instructions
• Only use the hose assembly as supplied with this natural convection. appliance for connection to the cylinder – • Do not use adaptors or modify the appliance to fit DO NOT USE ADAPTORS. 04 JOOLCA HOTTAP – MODEL JCA11001 USER GUIDE... - Page 6 Rectangular areas have been used in these figures – the same principles apply to any other shaped areas. FIGURE B2 – Outdoor Area Example 3. With both ends open. 05 JOOLCA HOTTAP – MODEL JCA11001 USER GUIDE...
- Page 7 During operation ensure that both air inlets and the wall area and 30% or more in total of the top exhaust are kept free from obstructions and remaining wall area is open and unrestricted. closure. 06 JOOLCA HOTTAP – MODEL JCA11001 USER GUIDE...
-
Page 8: Preparing For Use
PREPARING FOR USE 1. Connect the ‘blue’ and ‘red’ Joolca quick connect fittings to the ‘Water Input’ and ‘Water Output’ threads respectively. 2. Connect the male side of the GASKNECT quick coupler to the gas inlet of the appliance. Apply Teflon tape to avoid leaks. - Page 9 6. Attach the female side of the GASKNECT quick coupler to the end of your gas hose. Apply Teflon tape to avoid leaks. 08 JOOLCA HOTTAP – MODEL JCA11001 USER GUIDE...
- Page 10 PREPARING FOR USE 7. Connect the gas regulator to the POL ULPG gas cylinder. Hand-tighten the connection in an anti-clockwise direction. Ensure gas is in the ‘OFF’ position. 09 JOOLCA HOTTAP – MODEL JCA11001 USER GUIDE...
- Page 11 This guide will use a mains pressure (i.e. garden tap) as the water input source. FOR USE WITH WATER INPUT SOURCES, SUCH AS THE FLOTAP LOW VOLTAGE PUMP, PLEASE CONSULT THE PUMP INSTRUCTION MANUAL OR CALL JOOLCA CUSTOMER CARE ON 1300 669 500. 1. Find a suitable, sturdy, non-combustible vertical surface to hang the appliance on via the carry handle.
- Page 12 Check the connection for leaks by coating orifices with soapy water. DO NOT use a flame. If bubbles occur or a leak is detected, turn the cylinder valve off, ‘Close’, retighten all connections and retest. 11 JOOLCA HOTTAP – MODEL JCA11001 USER GUIDE...
- Page 13 Turn the gas cylinder off. NOTE The gas cylinder must be positioned away and to the side of the appliance. It must never be directly aside, below or above the appliance. 12 JOOLCA HOTTAP – MODEL JCA11001 USER GUIDE...
-
Page 14: Operation
It is important that when starting the appliance that the water regulator is set to the ‘maximum’ position (i.e. turned clockwise completely to the left). 3. Turn the gas cylinder on, ‘Open’, in an anticlockwise direction one full turn. 13 JOOLCA HOTTAP – MODEL JCA11001 USER GUIDE... - Page 15 Water should not flow out as the shower nozzle is in the ‘Off’ position. 5. When ready, slide the flow regulation switch on the shower nozzle to the ‘On’ position. Water will start to flow. 14 JOOLCA HOTTAP – MODEL JCA11001 USER GUIDE...
- Page 16 ‘Off’ position. The burner will extinguish. To reignite the burner, slide the flow regulation switch on the shower head to the ‘On’ position. Water flow will commence and the burner will automatically ignite. 15 JOOLCA HOTTAP – MODEL JCA11001 USER GUIDE...
- Page 17 2.2 Disconnect the gas hose from the appliance by pulling down on the female side of the GASKNECT quick coupler. 3. Disconnect the quick connect adaptors from the ‘Water Input’ and ‘Water Output’. 16 JOOLCA HOTTAP – MODEL JCA11001 USER GUIDE...
-
Page 18: Care Instructions
Before each use, check that the screen filter on the ‘Water Input’ pipe is in place and cleaned of any particles. DO NOT Submerge the appliance in a sink or bowl. DO NOT Use abrasive cleaners or bleach. 17 JOOLCA HOTTAP – MODEL JCA11001 USER GUIDE... -
Page 19: Troubleshooting
TROUBLESHOOTING Joolca Well of Wisdom Check out the Joolca Well of Wisdom. There’s a wealth of information on your product including some very handy getting started videos & troubleshooting tips. Visit http://support.joolca.com.au and navigate to your product. This guide should be followed in case of failure of the appliance to operate correctly. If symptoms persist contact Joolca Customer Care on 1300 669 500. - Page 20 Check if there is a blue flame in the ‘viewing window’. If you see a yellow flame it could mean a breakdown in the gas regulator - immediately shut down the unit. Please call Joolca Customer Service directly if this happens, DO NOT attempt to use the appliance.
- Page 21 JOOLCA WARRANTY Your Joolca appliance will be covered for parts and labour for 2 years from the date of purchase, as detailed in the terms of the Joolca guarantee on the Joolca Website: http://support.joolca.com.au/warranty If you have a query about your Joolca appliance, call the Joolca Customer Care quoting your serial number and details of where and when you purchased the appliance (If applicable).
