Summary of Contents for SoloStrength Ultimate Series
- Page 3 SoloStrength is not intended for use by children under 12 years old, and all minors should be supervised by an adult while using the system to ensure proper use and safety.
-
Page 4: Table Of Contents
• SoloStrength is intended for indoor use, or covered outdoors. It is recommended to keep your system out of direct sunlight for extended periods, high humidity or wet environments. If set outdoors, we recommend a covered roof or gazebo of your deck or outdoor living area. -
Page 5: Safety Instructions & Labels
DO NOT SWING YOUR BODY ON SOLOSTRENGTH SYSTEMS. AT NO TIME IS IT SAFE TO USE SOLOSTRENGTH AS A SWING BAR, IT IS MEANT AS SUPPORT FOR FULL OR PARTIAL BODYWEIGHT TO EXECUTE ONLY THE SUGGESTED ACTIVITIES IN THE SPEEDFIT PROGRAM GUIDE THAT COMES WITH THIS PACKAGE. -
Page 6: Product Specifications
L x W x H: 4.0” x 41.0”x 86.5 (82.5)” WALL MOUNT SYSTEM 12” Height Extensions • Weight: approx. 31.5 lbs (OPTIONAL) (OPTIONAL) • Fits standard door widths (28”-36”) • Corner mounting brackets optional Your SoloStrength Package includes assembly and instructional video access online. www.solostrength.com... -
Page 7: Box Contents
BOX CONTENTS SPEEDFIT UL TIMATE 87/83 PART NO. PART NAME PICTURE Q'TY(PCS) Allen pan-headed bolt Nylon nut Connection piece(Small) Allen countersunk bolt Connection piece(Big) Allen pan-headed bolt Foot pad L shaped clip (Big) L shaped clip (Small）(tight corner) Countersunk self tapping screw Washers Plastic nail (wall mount -drywall) Expansion bolt (wall mount -concrete) -
Page 8: Assembly Manual (Ultimate Main/Doorway/Freestanding/Corner/Wall)
UL TIMATE MODELS 87/83 *********************************************RESOURCES****************************************** Visit www.solostrength.com/assembly-tips/ for any updates to these instructions and tips to assist in a quick and successful installation. Some videos are available. If you experience difficulty you can always reach our Customer Service with your questions and we will be happy to assist. - Page 9 ASSEMBLY MANUAL UL TIMATE MODELS 87/83 STEP 3 • Slide part# 9 into parts 5-A & 5-C, and install 1/4” screws (part #8) as shown on the left. • Repeat on the opposite side with 5-B & 5-D. Check Point 1: Be sure that the screw head is flush with the extrusion.
- Page 10 ASSEMBLY MANUAL UL TIMATE MODELS 87/83 DOOR FRAME STEP 6 • Measure the inside width of the door frame. Loosely adjust part# 13 to the door frame width. • • OPTIONAL: for tighter corners/wall space, use part #14 on one side. WIDTH IMPORTANT: Step 7 below, start by setting bar in second lowest hole to square...
-
Page 11: Inspection, Maintenance & Storage
Check that the support bar is traveling correctly in the groove on each side and free of resistance. ROUTINE MAINTENANCE • Wipe down your SoloStrength System on a regular basis using a clean cloth and light soapy solution. Do not leave wet towels or workout clothing laying or hanging on the equipment. •... -
Page 12: Warranty
Warranty Dedication to Quality SoloStrength Lifestyle Products warrants this product to be free from all defects in material and workmanship when used according to the manufacturer’s instructions. See Limited Warranty Card or website for more details. www.SoloStrength.com If you have any comments or questions contact our... -
Page 13: Regulation Information
Any changes or modifications not expressly approved by SoloStrength could void the user’s authority to operate this device and warranty. Please consult website for updated information. www.SoloStrength.com. There are no serviceable parts included. Using SoloStrength for any reason other than expressly displayed may result in serious harm or damage. - Page 14 N O T E S...
