Summary of Contents for Aulong 09GH001
- Page 1 Totum --- 2.4G Wireless Audio System (with LED Light Bar) 1. Description 2. Product Overview 3. Operation 4. Accessories 5. Specification 6. Troubleshooting 2009.7 Aulong Technology Company Limited Tel: (852) 31722560 Fax: (852) 31192417 E-mail: info@aulong-tech.com - 1 -...
- Page 2 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected Consult the dealer or an experienced radio/TV technician for help MODEL: 09GH001 Please read the below information carefully. ℃ The maximum ambient temperature should not exceed 35 .
- Page 3 Totum --- 2.4G Wireless Audio System (with LED Light Bar) 1. Description Totum 2.4G Wireless Audio System (with LED Light Bar) can transmit the PC Audio (USB port) or Analog Audio (MP3) to the Speakers through 2.4GHz ISM band in a broadcasting mode.
- Page 4 Totum --- 2.4G Wireless Audio System (with LED Light Bar) Broadcasting mode: In the broadcasting mode, one Transmitter Box can be connected to 50 Heaters. - 4 -...
-
Page 5: Product Overview
Totum --- 2.4G Wireless Audio System (with LED Light Bar) 2. Product Overview a) Transmitter Box Item Name Description Battery RWR switch Battery Power Switch USB port USB Port (support USB 2.0 high speed) LED indicator a) always on: normal operation (audio is transmitting) b) flash (1sec): no audio source c) flash (0.25sec): ID Leaning operation ID button... - Page 6 Totum --- 2.4G Wireless Audio System (with LED Light Bar) b) Totum Heater (Receiver) Item Name Description L. Speaker Left Speaker R. Speaker Right Speaker L. LED Light Bar Left LED Light Bar R. LED Light Bar Right LED Light Bar Control Box Control board (with 2.4GHz Receiver Module) Control Knob...
- Page 7 Totum --- 2.4G Wireless Audio System (with LED Light Bar) Control Box (Receiver) Item Name Description Power Receptor Receptor for the supplied power adapter Battery compartment Battery compartment Battery LiFePO4 Rechargeable Battery Pack - 7 -...
- Page 8 Totum --- 2.4G Wireless Audio System (with LED Light Bar) Speaker (Receiver) Item Name Description Rigging Points Rigging Points used to fix the speaker in the Heater Speaker cable 24 AWG cable - 8 -...
- Page 9 Totum --- 2.4G Wireless Audio System (with LED Light Bar) III) LED Light Bar (Receiver) Item Name Description Each Light Bar has 30pcs LED (RGB colour) Light Bar cable 24 AWG cable - 9 -...
-
Page 10: Operation
Totum --- 2.4G Wireless Audio System (with LED Light Bar) 3. Operation 3.1 Transmitter Box Operation For direct line in playback, please use the battery power open the battery compartment on the bottom, put in 4 x AA battery and close the compartment Turn on the battery power switch connect the Audio cable provided to the audio source and the 3.5mm audio jack... - Page 11 Totum --- 2.4G Wireless Audio System (with LED Light Bar) 4. Accessories 4.1 Transmitter box USB Cable (Aulong Technology) Audio Cable (Aulong Technology) III) 4 x AA battery (Grand Hall) 4.2 Receiver (Totum Heater) LiFePO4 Rechargeable Battery Pack (Grand Hall)
- Page 12 Totum --- 2.4G Wireless Audio System (with LED Light Bar) 5. Specification RF Specification Item Specification Unit Note Frequency Range 2406 ~ 2472 Channel Modulation GFSK RF TX Power 16±2 (typ) Radiation Power RX Sensitivity -79 (typ) Audio Specification Item Specification Unit Note...
-
Page 13: Troubleshooting
Totum --- 2.4G Wireless Audio System (with LED Light Bar) 6. Troubleshooting Transmitter (No sound output from the speaker): Direct Line In Battery compartment with battery? Turn on the Battery Power Switch? Direct Line in connect to the 3.5mm Audio jack properly? Analog Audio Player (e.g.
