Summary of Contents for Ghost eye 600TC
- Page 1 600TC WIRELESS HDMI/SDI VIDEO TRANSMISSION SYSTEM GHOST EYE MANUAL BOOK © 2017 Cine Gears INC. All Rights Reserved.
-
Page 2: Table Of Contents
Contents Cautions Ghost Eye Wireless Video Transmission Systems Product Features Specifications Transmitter Receiver User Manual Setting Up the Unit Channel Settings Intercom Troubleshooting Disclaimers About Cinegears © 2017 Cine Gears INC. All Rights Reserved. -
Page 3: Cautions
Cautions Warning Please read this user introduction manual to become familiar with the features of the Ghost-Eye series products before operation. Failure to operate the product correctly can result in damage to the product, or interference with other devices. This is a sophisticated product which must be operated with caution and common sense. -
Page 4: Ghost Eye Wireless Video Transmission Systems
Ghost-Eye Wireless Video Transmission kits, across the affordable price range spectrum. Ghost Eye wireless video transmission kits each fit a different set of wireless HD video transmission needs. The most powerful video transmitters and receivers will satisfy even the most high end profesional film crew, and our lightweight models fit a more versatile brand of film set. -
Page 5: Product Features
Product Features Transmits 10-bit color, YCbCr, 4:2:2 color depth, proprietary color matching algorithm on OFDM chips. Optimized uncompressed 10-bit 4:2:2 2GBps video stream, or 12-bit 4:4:4 3GBPs wireless video transmission on other models. Optimized video processor for on-screen movement. Fully supports all audio formats. Static channel selection. -
Page 6: Specifications
Specifications ITEM SPECIFICATION 5.1-5.9(GHz)*Subject different regulations in different regions. Frequency range 2.4-2.483GHz with ISM band Up: 40MHz Occupied Bandwidth Down: 1MHz HDMI: 525i, 625i, 720p 50/59.94/60, 1080i 50/59.94/60, 1080p 23.98/24/25/29.9/ Video Formats 30/50/59.94/60; HDMI Type A Supported SDI: 3G, HD, SD-SDI (auto-selected), SMPTE 259/274/292/296/372/424/425;... - Page 7 Specifications Net Weight(with 418g antenna) Dimensions 163mm(L)×105mm(W)x22mm(H) Temperature -10-50º (Operating); -40-80º (Storage) Receiver External Antenna 5G × 5pcs Antenna External Antenna 2G x1pcs Receiving Sensitivity -75dBm SDI Output (BNC Female); HDMI Output (Type A Female); 6x Antenna Port; 3x3.5mm Functional Interface Headset Port;...
-
Page 8: Transmitter
Transmitter 5G Antenna Link Indicator Light Video Indicator Light 2.4G Antenna 2.4G Antenna Menu Screen USB Output Channel HDMI Output Volume/Call SDI Loop Out SDI Input Mute/Call Indicator Light XLR Input ON/OFF Switch 3.5mm Tally Output Jack 3.5mm Stereo In Jack 7-36V DC IN ©... -
Page 9: Receiver
Receiver Link Indicator Light 5G Antenna Video Indicator Light 5G Antenna 2.4G Antenna Menu Screen USB Output Signal Indicator Light Channel HDMI Output Volume/Call Mute/Call Indicator Light SDI Output ON/OFF Switch XLR Input 3.5mm Tally Jack Intercom/Tally Input 7-36V DC IN ©... -
Page 10: User Manual
User Manual 1. Fix the four antennas to the transmitter and arrange them to be a right angle as below figure to get better performance. 2. On transmitter side, when both SDI and HDMI source are inputted, the transmitter will automatically select the SDI source for transmission 3. - Page 11 User Manual Transmitter Fix the four antennas respectively. Connect the SDI or HDMI video source to the “SDI IN”/”HDMI IN” of transmitter (when both SDI and HDMI video are inputted, it will auto select the SDI video for transmission). If needed, you can connect the SDI out (loop through) to other equipment as well. Connect the DC power to the transmitter or use a battery on the battery plate.
-
Page 12: Intercom
User Manual Changing Channel on Transmitter Power on the Transmitter Press the “CH” button to unlock channels, then press “CH” to scroll through channels. Press “OK” to confirm. Transmitter channel setting accomplished. Changing the Channel on Receiver Power on the Receiver. Press “OK”... -
Page 13: Troubleshooting
User Manual Troubleshooting If the Receiver fails to output video correctly, follow the chart below to find possible causes and solutions. ISSUE SOLUTION Displaying “Waiting for Connection...” for a Prolonged Period Transmitter is not powered up. Turn on the transmitter. Transmitter or receiver is not placed Place the TX or RX correctly. - Page 14 User Manual No Signal Input to Receiver or TV/Monitor Receiver is turned off. Turn on the receiver. Receiver and TV are not connected. Connect receiver and TV/Monitor via SDI/HDMI input. TV/Monitor not switched to SDI/HDMI Switch TV/Monitor to SDI/HDMI input. input Bad cable connection of receiver or Disconnect and re-connect the SDI/HDMI...
-
Page 15: Disclaimers
Disclaimers FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 16 Disclaimers Terms and Conditions Congratulations on purchasing your new CINEGEARS product. Please read this manual carefully before using the product. By using this product, you hereby agree to this disclaimer and signify that you have read it in full. You agree that you are responsible for your own conduct and any content created while using CINEGEARS products, and for any consequence thereof.
-
Page 17: About Cinegears
About Cinegears Cine Gears Inc. is an industry leading company that designs and manufactures digital wireless follow focus systems, lens control systems, camera motion control systems and accessories for film and broadcast industry. As a big believer in the power of creativity and ideas, we designed the Pegasus cablecam, the wireless motor drive that integrated a built in wireless transmitter, and the wireless finger wheel controller.
