- Page 1 INSTRUCTION MANUAL WaterStep M-100 Chlorine Generator Read these instructions in order to safely and effectively use this product. 625 Myrtle St. Louisville, KY 40208 USA 001.502.568.6342 waterstep.org...
-
Page 2: Table Of Contents
WaterStep M-100 Chlorine Generator CONTENTS Important Safeguards ..................1 Warnings ......................2 What the Chlorine Generator Does ..............3 What is Included with the Chlorine Generator ........... 4-5 What Else is Needed ..................6 Installing the Chlorine Generator ..............6-7 Operating the Chlorine Generator .............. -
Page 3: Warnings
When possible, you should get your source water tested by a certified lab to see what it has in it. The M-100 can chlorinate water up to a level of 5 parts per million, but no third party or government agency has tested this machine for how effectively it kills bacteria or other microbes or viruses. -
Page 4: What The Chlorine Generator Does
WaterStep M-100 Chlorine Generator WHAT THE CHLORINE GENERATOR DOES The WaterStep M-100 Chlorine Generator was developed in response to a need that affects nearly 1 billion people around the globe . . . unsafe drinking water. In fact, waterborne disease claims more lives each day than armed conflict, HIV/AIDS, and cancer combined. -
Page 5: What Is Included With The Chlorine Generator
WaterStep M-100 Chlorine Generator WHAT IS INCLUDED WITH THE CHLORINE GENERATOR 5/8” I.D. Hoses (Qty: 2) Submersible Pump Chlorine Injector with Heat Exchanger 1/4” I.D. Tube Water Bottle/Salt Mixing Bottle Parts Bag... - Page 6 WaterStep M-100 Chlorine Generator WHAT IS INCLUDED WITH THE PARTS BAG Zip Ties Chlorine Test Kit Barb Fitting (Female) Measuring Cup (for salt) Barb Fitting (Male) Roll of Teflon Plumbers Tape OTHER: 1. 1” cap for fill tube 2. Pinch clamp 3.
-
Page 7: What Else Is Needed
WaterStep M-100 Chlorine Generator WHAT ELSE IS NEEDED 1. 12-volt DC battery (deep cycle/ 4. Slotted screwdriver marine type is best) 5. Measuring tape 2. Solar or electric battery charger 6. Large pair of pump pliers for 12-volt battery 7. Bucket to collect rinse water 3. - Page 8 WaterStep M-100 Chlorine Generator INSTALLING THE CHLORINE GENERATOR • Slide the heat exchanger into the oval- • Place the braided hose attached to the shaped injector into the tank or barrel that will opening collect/store the chlorinated water on top (discharge to tank).
-
Page 9: Operating The Chlorine Generator
WaterStep M-100 Chlorine Generator OPERATING THE CHLORINE GENERATOR This process begins after the chlorine generator is assembled. It is assumed you have a water tank or cistern containing water you wish to chlorinate. It also assumes that you have a means to dispense the water from the tank after it is treated. - Page 10 WaterStep M-100 Chlorine Generator CHLORINATION PROCESS • Pour the solution of water and salt into • If using plain water in the SODIUM the chlorine generator. Add more water HyDROxIDE side, pour about 5 grams to get the level to the maximum line...
- Page 11 WaterStep M-100 Chlorine Generator CHLORINATION PROCESS • VERY IMPORTANT: Be sure to draw • Look for a bubbling action in the CHLORINE side and small bubbles test sample from below surface of forming in the SODIUM HyDROxIDE water in the tank.
-
Page 12: Shutting Down The Chlorine Generator
WaterStep M-100 Chlorine Generator SHUTTING DOWN THE CHLORINE GENERATOR Before the unit is completely shut down and stored, have two empty containers - each of which will hold up to two liters of liquid. Use a permanent marker to write “Chlorine”... -
Page 13: What To Do With By-Products
WaterStep M-100 Chlorine Generator WHAT TO DO WITH BY-PRODUCTS If there is no use for the by-products, both solutions can be poured into the same bucket to neutralize into saline water. 1. Chlorine The chlorine solution may be used as a household disinfectant and cleaning agent.
