A64-OLinuXino 64-bit open source embedded computer QUICK START GUIDE Document revision A, September 2017 Designed and manufactured by OLIMEX Ltd, 2017 All boards manufactured by OLIMEX LTD are RoHS compliant... - Page 2 OLIMEX© 2017 A64-OLinuXino quick start A64-OLinuXino is a single-board open hardware computer. It is a system built on a single circuit board with all hardware for proper operation already available (such as processor, power management unit, memories, peripherals, connectors, and everything else required for basic operation).
- Page 3 The rubber feet allow the board to be placed safely on a flat surface without the risk of short- circuit. Here is a picture of A64-OLinuXino-1G4GW with the four rubber feet properly placed at the bottom and important parts labeled: 1.2.3.
- Page 4 OLIMEX© 2017 A64-OLinuXino quick start HDMI of the board. Connect the keyboard and the mouse to the USB ports. Connect LAN cable if you have available. Do not connect the power supply until rest of the hardware had been already connected. The general layout that we aim for is listed below: 1.2.5 Power the display and apply the power supply to the board.
- Page 5 Before you proceed ensure that you have the items listed in the this chapter available: 2.1.1. Any version of the A64-OLinuXino board. 2.1.2. An external source of power supply. It should be capable of providing at least 1A of current at 5V of voltage.
- Page 6 The rubber feet allow the board to be placed safely on a flat surface without the risk of short- circuit. Here is a picture of A64-OLinuXino-1G4GW with the four rubber feet properly placed at the bottom and important parts labeled: 2.2.3.
- Page 7 OLIMEX© 2017 A64-OLinuXino quick start layout of the board on where “UART debug” is located. Connect cable's RX to the TX of the connector; cable's RX to the TX of the connector; GND of the cable ot GND of the connector.
- Page 8 OLIMEX© 2017 A64-OLinuXino quick start We see that it is assigned COM #2. We need this information in order to start the PuTTY on the same serial port. As shown below – select the proper COM port, the speed, make sure that the connection is set to “Serial”...
