Summary of Contents for Attonic ARFS-02
- Page 1 ARFS Series Digital Force Gauge ARFS-series OPERATION MANUAL ATTONIC CO., LTD ATTONIC...
- Page 2 ・The limit of ＨＩ(HIGH) and ＬＯ(LOW) can be made by comparator out-put. ・Selectable 3 units (Ｎ、Kg ｆ、lbf) ・Battery Volume can be checked on display. ・Power auto-off function When there is no key 2-3minutes,a power supply is turned off automatically. －１－ ATTONIC...
- Page 3 Do not store and operate in the following conditions ※ Wet area ※ Where dew condensation ※ Dusty area ※ Where oil or chemicals Do not disassemble, trouble-shoot and remodel Should you perform any of these, that may cause malfunction of the unit. －２－ ATTONIC...
-
Page 4: Specifications
” 0 “) ※In case of over load setting 1 ～ 100 %, “ OVER LOAD “ will be indicated on display when the load is reached over your setting value. (Regarding over load setting, please see page No.9.) －３－ ATTONIC... - Page 5 ■Standard Attachments ●ＡＲＦＳ－１～５０ ・Material:In case of 5N ～20N type=Aluminum In case of 50N～500N type=Steel ＊Measuring Shaft･･･Ｍ６×１ ●Model and Description Ｓ－１･･･Ｖ-type(A)、Ｓ－２･･･Ｖ-type(B)、Ｓ－３･･･Cone-type、Ｓ－４･･･Flat-type Ｓ－５･･･Hook-type、Ｓ－６･･･Extension Rod、Ｓ－７･･･Fork Hook-type ●ＡＲＦＳ－０２ 、０５ ・Material: Aluminum SS-1 SS-2 SS-3 SS-4 SS-5 ＊Measuring Shaft･･･Ｍ３×０.５ ●Model and Description ＳＳ－１･･･Ｖ-type(A)、ＳＳ－２･･･Ｖ-type(B)、ＳＳ－３･･･Cone-type ＳＳ－４･･･Flat-type、ＳＳ－５･･･Hook-type －４－ ATTONIC...
- Page 6 2 0 .0 0 Kg 4 4 . 0 0 l b Power Switch Data Output Switch RE SET Function Switch Reset Switch Serial Number Sticker N O . 0 1 2 3 4 Loadcell Connector ＡＬ－１０Ｎ Measuring Shaft Loadcell Connector －５－ ATTONIC...
-
Page 7: Lcd Display
RS-232C signal. (Caution) It outputs the digital signal when using a function feature. Also, in case of function feature (FU), it can be changed Peak Hold and Tracking, the reading of memory data and various setting of value. －６－ ATTONIC... - Page 8 ・ SERIAL NUMBER STICKER Serial number is mentioned on this sticker. ・ MEASURING SHAFT This shaft is for detecting the force. The size of shaft screw is M6 X 1. Attachment can be set on this top of shaft screw. －７－ ATTONIC...
- Page 9 Push F button ③ Set up Comparator Function (HI) Set up the upper limit of comparator function Figure rising by D-button and Digit rising by RESET-button. When not using this function, setting to the 0. (Initial setting : 0) ↓ －８－ ATTONIC...
- Page 10 ↓ Push F button TO ① Change Peak Hold (PEAK) and Tracking (TRUCK) Keep to push F button about 6 seconds, the gauge is now ready to measure. －９－ ATTONIC...
- Page 11 -0 000 - 000 0 - 000 0 PEAK PEAK PEAK - 000 0 -0 000 - 000 0 ＊Display reversed with D Switch ■Digital indication for warning messages ■Low Battery Indication ■Over Load Indication OVER LOAD BATT －10－ ATTONIC...
- Page 12 15．Digimatic output (REQ) 16. GND ■Connector Form 14 16 ●RS-232C Format 1． Interfacing (Bit) Spec. ・Start Bit : 1 bit ・Date Length : 8 bit ・Stop Bit : 1 bit ・Parity : None ・Baud Rate : 9600 BPS －11－ ATTONIC...
- Page 13 ATTONIC CO., LTD. 00-5 HIGASHI TAKADACHO, TOYOHASHI AICHI 441-8115 JAPAN. TEL : (0532)-41-5357 FAX : (0532)-41-4826 ＵＲＬ：http：//www.attonic.co.jp E-mail：info＠attonic.co.jp...
