Summary of Contents for Electric Signal MMXV AD

  • Page 1 User manual Delta Transconductance band Compressor Electric Signal MMXV Electric Signal 2016 - Revision Alpha...
  • Page 2 Delta Transconductance band Compressor User manual Electric Signal MMXV AD Serial a priori number Line voltage...
  • Page 3: Table Of Contents

    2.2. high to mid 12dB/oct - mid to low 12dB/oct 2.3. high to mid 12dB/oct - mid to low 6dB/oct 2.4. high to mid 6dB/oct - mid to low 12dB/oct Delta Transconductace band Compressor Page 3 Page 4 Electric Signal MMXV AD User Manual...
  • Page 4: Thank You

    There are dogma’s and standing on a many shoulders, no integrated circuit's, electrolytes or transistors Electric Signal is always innovating. Pushing the in the audio chain. The input and output are envelope further and tries to leave the real transformer balanced.
  • Page 5: Getting Started

    Make sure that the ventilation slots are not obstructed. When rack mounting this equipment, an external fan may be required to provide sufficient airflow. Delta Transconductace band Compressor Page 7 Page 8 Electric Signal MMXV AD User Manual...
  • Page 6: Powering Up The Machine

    9pins d-sub sockets, with the the stage. numbering of pins: Left Pinout 1, 2: High 3, 4: Mid zero 5, 6: Low 7, 8: Main : Gnd Delta Transconductace band Compressor Page 9 Page 10 Electric Signal MMXV AD User Manual...
  • Page 7: Output Stage Balance

    ‘high’ compressor working over the whole (20hz- 20kHz) frequency range. Delta Transconductace band Compressor Page 11 Page 12 Electric Signal MMXV AD User Manual...
  • Page 8 0.08 0.10 0.13 link Gain reduction Balance leds measurement Meter zero Balance Attack time Release time Threshold Stereo link System bypass XLR Input XLR Output Delta Transconductace band Compressor Page 13 Page 14 Electric Signal MMXV AD User Manual...
  • Page 9: Control Matrix

    (dB)/mute reduction used to mix the low, mid and high band together. Delta Transconductace band Compressor Page 15 Page 16 Electric Signal MMXV AD User Manual...
  • Page 10: Stereo Link

    1dB per step, Notify that this control can effect every compressor in the unit. In combination with the input gain 121 gain combinations are possible Delta Transconductace band Compressor Page 17 Page 18 Electric Signal MMXV AD User Manual...
  • Page 11: Filter Block Chain

    Phase 1st order 2nd order inverter Audio signal low pass filter low pass filter 2nd order Control signal Bypass Filter I/O Delta Transconductace band Compressor Page 19 Page 20 Electric Signal MMXV AD User Manual...
  • Page 12: Bode Plot's Of Filter Settings

    Delta Transconductace band Compressor Page 21 Page 22 Electric Signal MMXV AD User Manual...
  • Page 13: High To Mid 12Db/Oct - Mid To Low 12Db/Oct

    Delta Transconductace band Compressor Page 23 Page 24 Electric Signal MMXV AD User Manual...
  • Page 14: High To Mid 6Db/Oct - Mid To Low 12Db/Oct

    Delta Transconductace band Compressor Page 25 Page 26 Electric Signal MMXV AD User Manual...
  • Page 15 Delta Transconductace band Compressor Page 27 Page 28 Electric Signal MMXV AD User Manual...
  • Page 16: Filter

    . Notify the frequency multiplier switch(1x white or 4x red) so Twelve cross over frequency values can be set, Delta Transconductace band Compressor Page 29 Page 30 Electric Signal MMXV AD User Manual...
  • Page 17: Tube Complement

    6h2p socket (contact electric signal for more information) 6ba6/5749/6k4p Not every ECC83 is usable due to the maximum rating specifications, contact electric signal for more information. See next subject for tube replacement. To remove a tube, press the screening can down and twist anti-clockwise, when it will spring out.
  • Page 18: Disclaimer

    Contact Electric Signal how to send it to us. Delta Transconductace band Compressor Page 33 Page 34...
  • Page 19: Edison Effect

    1,000 Kelvin The science dealing with this phenomenon has been known as "thermionics", but this name seems to be gradually falling into disuse. Electric Signal Electricsignal.eu info@electricsignal.eu Phone 0031640237096 Leiden, Netherlands 2332PZ Delta Transconductace band Compressor Page 35 Page 36 Electric Signal MMXV AD User Manual...
  • Page 20: Recall Sheet

    Input Gain (dB)/ Attack time (ms)/ Recovery time (s)/ Threshold (dBu) Recovery gain Crossover frequency Gain Calibration Main stereo link time adder time adder (dB)/mute (Hz)/filter settings reduction Delta Transconductace band Compressor Page 37 Page 38 Electric Signal MMXV AD User Manual...
