Instruction Manual
v1.4
Model:
ONE64LED
Realtime Play Action Car
PAT. PENDING
Add real functional lights to your
1:64 or larger scale model cars
No programming skills necessary
Head lights | Tail Lights | Break Lights| Signal Lights
Parking Lights | Backup Lights | Interior Light | Fog Lights
Emergency | Strobes | Horn
Buttons Setup and Features
are
PATEND PENDING
Code is Copyrighted 2016
www.technickldesigns.com
Advertisement
Table of Contents
Summary of Contents for Technickl Designs ONE64LED
-
Page 1: Instruction Manual
Instruction Manual v1.4 Model: ONE64LED Realtime Play Action Car PAT. PENDING Add real functional lights to your 1:64 or larger scale model cars No programming skills necessary Head lights | Tail Lights | Break Lights| Signal Lights Parking Lights | Backup Lights | Interior Light | Fog Lights... - Page 2 No other functions will work in this MODE. Only the two following functions will work: Top button pressed less then 1 second: ==> Goes to the next MODE Top button held for more than 1 second: ==> Goes back to the OFF lights MODE (Reset) www.technickldesigns.com - MODEl: ONE64LED Rev 1.4...
- Page 3 Functions Configuration Chart - MODEl: ONE64LED 1. The 5 pairs of pads on the bottom side of the PCB selects which functions are turned off or on. 2. There is a small trace connecting the upper pads to the lower pads respectively. Resulting in a total of 5 jumpers.
- Page 4 PCB Pin Outs - MODEl: ONE64LED 1. Remember to pre-configure your functions before installing if you are going to cover up the jumpers. 2. Select the functions you desire by cutting or resoldering the upper pad to the lower pad respectively.
