Minec Memor2000 User Handbook Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Memor2000
User Handbook

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Memor2000 and is the answer not in the manual?

Questions and answers

Related Manuals for Minec Memor2000

Summary of Contents for Minec Memor2000

  • Page 1 Memor2000 User Handbook...
  • Page 2 User Handbook Memor2000 Welcome as a Memor2000 user! The Memor2000, a Swedish-developed hand-held computer, incorporates the latest semiconductor technology. The Memor2000 is functional, compact and ergonomically designed, and sufficiently robust to withstand a wide variety of environments and working conditions.

  • Page 3: Table Of Contents

    User Handbook Memor2000 Contents Page 1. General information about the Memor2000 ... 4-7 2. Battery replacement..........8 3. Accessories ............9 4. Care and maintenance ........10 5. Troubleshooting ..........11 6. Technical specification ........ 12-13 7. Glossary of terms ..........14 8.

  • Page 4: General Information About The Memor2000

    1. General information about the Memor2000 On delivery The Memor2000 is supplied complete with batteries and is ready to use. Once you have taken the computer out of its box, check immediately that there are no visible signs of transport damage.
  • Page 5 ON/OFF Press the ON/OFF key to switch the Letter entering Memor2000 on or off. If no other key is pres- The method used to enter letters is both sed in the space of two minutes, the hand- simple and unique (patent pending). The...
  • Page 6 3 are interpreted as a CPU-card older than 2.0. All other numbers are regarded as defining CPU-cards with update 2.0. Make sure that the correct serial number has been stored in your Memor2000. * Does not apply to Memor2000 models with serial numbers beginning with 3.
  • Page 7 User Handbook Memor2000 Peripheral modules As the Memor2000 is a hand-held computer with many diffe- rent uses, it is designed to be fitted with a number of different exchangeable peripheral modules. On delivery the Memor2000 is fitted with the module that has been ordered. Should your requirements change, the existing module can replaced by another.

  • Page 8: Battery Replacement

    However, you can expect about a day’s further use. The message is repeated every time you switch the Memor2000 on or off until you replace the batteries. If you don’t replace the batteries it will finally be impossible to switch on the hand-held computer.

  • Page 9: Accessories

    Memor2000. PC-connection cable This is used to connect the Memor2000 to an ordinary PC. If you have a Memor2000 fitted with a COM-module you should connect the cable to this module. If you have a Docking station you can connect the cable to the Docking station.

  • Page 10: Care And Maintenance

    Memor2000 will give any years’ of trouble-free use. Don’t store the Memor2000 under conditions that are too hot or too cold (limits are +55°C and -20°C). High temperatures can damage the electronics or battery, or deform plastic parts. Low temperatures cause condensation when the hand-held computer warms up to normal tempera- ture, which in turn can damage the electronics.

  • Page 11: Troubleshooting

    It is impossible to switch on Check that the batteries are new the hand-held computer. and correctly inserted. Communication via the DS-S Check that the Memor2000 is doesn’t work. correctly placed in the DS-S, i.e. that the computer rests against the stops in the DS-S.

  • Page 12: Technical Specification

    NEC V25 at 8 Mhz (instruction compatible tested on an ordinary PC. The resulting with Intel´s 8088) program is downloaded to the Memor2000 where it can be stored on the RAM-disk or Operating System on the FLASH-disk.

  • Page 13: Technical Specification

    User Handbook Memor2000 Technical Specification Memor2000 Laser Memor2000 IBW Light Source Optical Resolution Visible laser diode, 670 +/-10 nm 0.19 mm Optical Resolution Light Source Element width minimum 0.154 mm 655 nm (red) Ambient Light Ambient Light Artificial: 1600 lux Maximum 100.000 lux...

  • Page 14: Glossary Of Terms

    User Handbook Memor2000 7. Glossary Application program The Memor2000 is a computer, just like a PC. A computer program is written for each specific application (called the application program). This program, or software, determines what happens to the data that is entered, how communication takes place, etc.

  • Page 15: Appendix

    User Handbook Memor2000 8. Appendix BIOS Menu This is where you get access to the system settings. These functions should be operated by the system manager. To enter the system menu: Restart the computer by opening and then closing the battery compartment cover.

  • Page 16: New Menu Functions

    ”With all keys”. The Memor2000 can be switched on by pressing any key except SHIFT. ”All after auto off”. The Memor2000 can be switched on by pressing any key, but only following automatic switch-off after time-out. * Does not apply to Memor2000 models with serial numbers beginning with 3.
  • Page 17 User Handbook Memor2000 BIOS M/2-DOS version 2.23 M/2-DOS version 2.23 has been developed so the SE1223 laser scanner can be used. Texts in the system menu have been changed slightly to facilitate settings that depend on the type of module fitted. The label on each module indicates the setting to select.
  • Page 18 1 metre. The drawing gives an idea of the IrDA operating angle from the Memor2000. Note that the Ir-window in the module is angled slightly downwards. Troubleshooting If the IrDA link doesn’t work, the reason may be among the following:...
