X300 Pro3 User Manual
X300 Pro3 User Manual
Statement
This handbook is the manual of X300 Pro3. Without the written permission from the manufacturer,
any company or individual shall not copy or backup it in any form (electronic, mechanical,
photocopying, recording or otherwise).This manual is only operating instructions for X300 Pro3. If
any result caused by using it on other equipment, the company does not assume any
responsibility for it.
If not quality problems of X300 Pro3，such as equipment failure caused by user abuse or misuse,
unauthorized disassembly, repair equipment yourself, not operate or maintain by the instructions,
lose it, the repair will not be free. Other product names mentioned in this manual are in order to
describe how to use X300 Pro3, and their copyrights are still observed by the original company.
X300 Pro3 and files are used for normal vehicles maintenance. If used for illegal purposes, the
company does not assume legal responsibility.
Advertisement
Table of Contents
Summary of Contents for Obdstar X300 Pro3
- Page 1 If not quality problems of X300 Pro3，such as equipment failure caused by user abuse or misuse, unauthorized disassembly, repair equipment yourself, not operate or maintain by the instructions, lose it, the repair will not be free.
-
Page 2: Table Of Contents
1.4.2 System Setting……………………………………………………………………………….4 1.4.2.1 Language Selection……………………………………………………………. 4 1.4.2.2 Contrast Adjustment……………………………………………………………5 1.4.2.3 Font Setting………………………………………………………………………5 1.4.2.4 Metric/Inch……………………………………………………………………….. 1.4.2.5 Data Logging…………………………………………………………………….. 1.4.3 System Information………………………………………………………………………5 1.4.4 Device Self-test………………………………………………………………………6 Chapter 2: How to update software for X300 PRO3……………………………………………6 2.1 Update Tool software Installation………………………………………………………….7 2.2 Software Updating……………………………………………………………………………….8... -
Page 3: Chapter 1: Summary
X300 Pro3 User Manual Chapter 1: Summary 1.1.Features 1.1.1. Advantages ●Multi-language environment can be applied in different countries and regions. ●The main unit system adopts ARM high speed chip to keep it running fast, stable and anti-jamming. ●Updating via SD card at any moment. -
Page 4: Introduction Of The Device
X300 Pro3 User Manual 1.2 Introduction of the device 1.2.1 The main unit and accessories(Picture as below) Name Instruction Testing cable port Connect to the main test cable for auto key programming Display Screen Show information Keyboard input option key... -
Page 5: Hardware Technical Specification
X300 Pro3 User Manual 1.3 Hardware technical specification ★Dimension: 23.9cm(L)*12cm(W)*3.6cm(H) :ARM7 ★CPU ★Power Supply:DC12V ★Operation Power:DC12V ★Operation Temperature: -20~60℃ ★Display Screen:320*240 TFT Screen 1.4 Functions Setting Power on， and then press ENTER on the screen， then go to the function setting, setting information as shown below: 1.4.1 Function Selection... -
Page 6: System Setting
X300 Pro3 User Manual Select different functions according to different requirements. Note: Software numbers and functions are different according to different product configuration. Further detailed information, please contact your distributor. 1.4.2 System Setting... -
Page 7: Language Selection
X300 Pro3 User Manual Select System Setting, language and contrast can be adjusted, as shown below: 1.4.2.1 Language Selection This device supports simplified Chinese, traditional Chinese, English, Russia, Greek, Spanish, Italian. In the language directory, select required language by Up and Down... - Page 8 X300 Pro3 User Manual 1.4.2.2 Contrast According to the environment, adjust the brightness of the screen by the left and right buttons, as shown below:...
-
Page 9: Font Setting
X300 Pro3 User Manual 1.4.2.3 Font Setting According to requirement, select different font. 1.4.2.4 Metric/Inch According to different requirements, select the Metric/Inch by the up and down keys, and press ENTER to confirm as show below, 1.4.2.5 Data Logging... -
Page 10: System Information
X300 Pro3 User Manual Any problems during testing, please use the Data Logging function to record the test process and send the data to us. Select ON by the up and down keys and press ENTER to confirm, shown as below, Note: Every time you need to select ON if you want to record the data before testing car. -
Page 11: Device Self-Test
X300 Pro3 User Manual 1.4.4 Device Self-test Device self-test includes screen display, keyboard testing. hardware self-testing, etc. If it cannot show enough pictures on the screen, keyboard not work, and hardware self-test not get through, please return this X300 Pro3 to the manufacturer. -
Page 12: Chapter 2: How To Update Software For X300 Pro3
X300 Pro3 User Manual Chapter 2: How to update software for X300 Pro3 2.1 Update Tool software installation Download the update tool and diagnostic software on www.obdstar.com, double click , then go to the next step: Step 1：Click “Next” Step 2: Click “Next... -
Page 13: Software Updating
X300 Pro3 User Manual Step 3: Click “Next” Step 4: Click “Finish” 2.2 Software Updating After Update Tool installation completed, click the Update Tool software icon on desktop to start update tools. Operation steps as following: Step 1：Open update tool... - Page 14 X300 Pro3 User Manual Step 2 Click the source menu, choose the program you want to update, click it and confirm Step 3: Click and select all the software then click “update” Step 4: Wait for several minutes then the updating finished Note：For new update software and questions during updating, please...
- Page 15 X300 Pro3 User Manual...
