    The Stomp−Head 5 is an ultra light, very compact floor amplifier with integrated foot−switch, designed to be set on the pedal board, along with effects or, placed directly on the stage floor. It greatly benefits the player with immediate access to all amps potentiometers and options.

  • Page 3: Front And Rear Panel

    FRONT & REAR PANEL NORMAL MIX MODE Ch−1 RETURN POWER Ch−2 (PA-INPUT) CAUTION! EXT. CTRL. TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER.REFER SERVICING TO QUALIFIED 4−8−16 Ch−3 SERVICE PERSONNEL LOOP BOOST Fuse: 2.5A WARNING! SEND GAIN NUMBER: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,...

  • Page 4: Tone Controls

    TONE CONTROLS Each channel is equipped with a regular three point EQ (BASS, MIDDLE, TREBLE) and switches which change the character of the sound. The MID−RANGE switch changes the range of frequency of the MIDDLE potentiometer. This option is very useful in the proper setting of the guitar’s sound in an overall band mix depending on the style of music played and type of guitar used.

  • Page 5: External Controller

    EXTERNAL FOOT SWITCH CONNECTION The graph below shows how the external foot−switch should be connected in order to control amplifier functionalities. If the external foot switch is connected, therefor, the internal amp foot−switches become disconnected. Note: external controller should be implemented with momentary or bistable switches type 0FF− [ON]. External controller OFF/ON BOOST...
  • Page 6 EFFECT AND MIXER CONNECTION The external effects may be connected between both preamps (CLEAN and LEAD) and the MASTER section through the parallel EFFECT LOOP .This type of connection is recommended when the Volume pedal or Delay, Reverb, Flanger type of effects are used.IMPORTANT: The volume potentiometers in channels 1−2−3 determinate the amount of gain sent to the effects.

  • Page 7: External Devices Connection

    EXTERNAL DEVICES CONNECTION External devices such as a preamp or a guitar DSP can be connected to the Stomp Head. Both devices may be set−up by two different method. 1. To the amp input – in this configuration all potentiometers and foot−switches will be active. 2.
  • Page 8 PRECAUTIONS Amplifier produces high volume levels. Staying in places of high volume levels could cause permanent hearing loss. Do not use the amplifier in humid and dusty places. Do not operate the amplifier through the unearthed socket. Do not leave the amplifier in the vicinity of children. Do not use the amplifier with broken power outlet or improper power cord.
