- Page 1 ® Dellking Helmet Bluetooth Headset User Manual Model: F1...
- Page 2 Please read below content carefully before using Thanks for purchasing F1 Bluetooth helmet intercom headset, may you will enjoy it. Please read the “Safety Instructions” before using the product for your safety and correct use. Caution Do not immerse in water to avoid damaging the product as well as shortening its lifetime.
-
Page 3: Product Overview
Product Overview: A. Power on/off Button/Pairing Button B. Multi-functional Button C. LED Indicator D. Charging E. Headset jack About Charging LED flash indicator Indicated State LED Indicators off Power off Red/Blue lights flashing alternately Pairing state Blue light flash every 1 secs. Standby/working state Red light flash every 3 secs. -
Page 4: Technical Specification
Technical Specification Name of Product Helmet Bluetooth Headset Model Microphone Type DSP Noise Suppression MIC Bluetooth Version V3.0 Class 1 Chip CSR BlueCore5MM Bluetooth Profile HSP, HFP, A2DP, AVRCP, INTERCOM Operation Range 10 meters Intercom Range Up to 800 meters Frequency Range 2.402-2.480GHz Sensitivity... - Page 5 How to fit It’s very easy to fit F1 on your helmet. Please follow below steps: 1．Removing adhesive protective sticker from back of Velcro pieces and firmly applying one speaker to ear pocket inside helmet on right side. 2．Applying the other speaker to ear pocket inside helmet on left side and applying the microphone support also on the left inner liner of the helmet.
- Page 6 2cm, improper installation may led to low voice or even no voice. 3.Putting the wires behind the inner liner of the helmet. 4.Sticking the F1 main unit by Velcro tapes on proper site on the helmet. Installed F1 Headset...
-
Page 7: Main Features
One cell phone and one GPS navigator with Bluetooth HFP/HSP profile One radio device with DELLKING BT Adapter/Dongle and one GPS navigator with Bluetooth HFP/HSP profile Can listen the merged audio from both connected devices or talk group at the same time ... - Page 8 Sharing the audio from the GPS Navigation. The USB port is for power charger only Connect with DELLKING Bluetooth adapter/dongle Switchable PTT function, can select to control two radio phones Mix listen to two radio phone, and talk to one radio at the same time ...
- Page 9 Pairing between F1 Bluetooth headset and Mobile. ① Place the F1 Bluetooth Helmet Intercom headset and the mobile phone in a visible area within 1 meter range. ② Make sure the Bluetooth Helmet Intercom headset is in power off state.
- Page 10 ⑤ From the found devices in your mobile phone, select the device named “ F1”, and then connect to pair with it, when it prompts to enter password, enter password <0000>. Once paired successful, LED Indicator will change from Blue/Red alternately to Blue flashing. Now you can use the headset to answer you phone call, or enjoy the music from your mobile phone.
-
Page 11: Last Number Redial
Bluetooth Intercom talking ①Turn on Bluetooth Intercom talking function F1 Bluetooth Intercom headset has memory function.When they paired successfully once, they will remember each other. You can start the intercom directly when both of the headsets are powered on. -
Page 12: Volume Control
press the Power on/off button once to end the intercom; if one user want to turn on the intercom talking function again, then short press the power on/off button once or say “Hello” loudly to the microphone, then the Intercom call will be activated. Stereo music play control and Volume control ①Play forward/backward Rotating the Multi-functional Button to the right (backward) to select next music. -
Page 13: Gps Navigator
First power off the F1, then connecting the F1 Bluetooth headset to a PC by proper USB cable. Once such a cable is inserted into both the F1 Bluetooth headset and PC USB port, the F1 is put into the battery power off charging state. - Page 14 When pairing successful, the Multi-functional Button of the headset will work as a remote PTT button to control the two-way radio that connects with the Dellking adapter; when the headset is connected with the adapter, user cannot use the Multi-functional Button to control FM any more or the music from the mobile phone.
- Page 15 When pairing successfully, the Power on/off button of the remote control act as a multi-functional button, now you can control calls and music by remote control. FAQ: 1.Can not power on It might low battery, please try again after charging for 3-4 hours,then plug and unplug the USB connector to reset the device.
- Page 16 TV transmitting tower, GSM base or airport radar, the headset would crash. It can be reset by charging after get away from interface software. 9.Abnormal instruction of charging indicator A.When the headset haven’t been used for long time or overused, it need to be pre-charge for an Hour, then pull out and insert the charger, it will indicate normal charging.
-
Page 17: Guarantee Card
The following situations are not guaranteed for free repairing or refund or exchange: 1.Damage due to incorrect installation ignoring the user manual 2.All damage due to man-made and other accidents 3.Damage due to unreasonable refitting and repairing without Dellking’s confirmation. 4.The scratch on the product surface. 5.The guarantee period is over. - Page 18 The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types F1 (FCC ID: 2AIO2-F1) has also been tested against this SAR limit. The highest reported SAR values for body-worn accessory is 0.12 W/kg respectively. This device was tested for typical body-worn operations with the back of the device kept 0mm from the body.
