一. Main Features
This product is a new feature of wireless Android platform VR game glasses, a variety of
games to support Android platform, built in exclusively Nibiru game application platform.Also
supports 3D video function, transfer 3D video+game mode directly. It supports external device
HDMI 1080P HD video input as well. And quad-core CPU using RK3288 A17 32 Bit 1.8GHz.
Performance parameters
二.
Operation system
CPU model
RAM Capacity
ROM Capacity
Storage
Expandable memory
Sensor
WIFI
Indicator
Display
PPI Pixel
Refresh rate
View Angle
Power Management
Control Key
Configuration Interface
Sensor
Standby Current
Shutdown Current
Working Voltage
Battery Capacity
Full Charging Time
Play Games Working Time
Watch Video Working Time
Antutu run test
Weight
Shen zhen G.A.P Electronics Co.,LTD
D3 Tongfuyu Industrial Area Community of Shajing Town, Baoan, Shenzhen, China
TEL:+86-0755-33895959
EMAIL:gappzb@gapelectron.com
MYGT VR AIO
DAVRAV01
User
Manual
Android 5.1
RK3288 Quad Cores A17, 32Bit 1.8GHz
DDR3 2GB
16GB
Micro SD Card
64GB
Gyroscope
IEEE 802.11 n/b/g (Only used for DAVRAV01)
LED light to show charge status
5.5 Inch HD 1920*1080
440ppi
60FPS
100FOV
Input 5V/2A
Direction Key, Up/Down/Left/Right/Enter,Reset,ON/OFF,VOL+,VOL-
1.MICRO USB Input 5V/2A（Support OTG function like:Wired game controllers/Wired
Mouse/Keyboard/USB flash dish）
2.SD Card support 64G
3.3.5MM headphone jack(Stereo with call function)
4.HDMI
Accelerator， Magnetometer， Distance.
27mA
150uA
3.7V
4200mAh
About 3H
About 2H
About 3H
34000 Scores
490g
Advertisement
Table of Contents
Summary of Contents for AuraVisor DAVRAV01
- Page 1 ROM Capacity 16GB Storage Micro SD Card Expandable memory 64GB Gyroscope Sensor WIFI IEEE 802.11 n/b/g (Only used for DAVRAV01) Indicator LED light to show charge status Display 5.5 Inch HD 1920*1080 PPI Pixel 440ppi Refresh rate 60FPS View Angle...
- Page 2 三．Function Introduction...
- Page 3 Buttons and interfaces specification Power button Long press for 5s will turn it on Menu 1.Helmet mouse opened/closed 2.VR mode Switch ON/Off 3.Game Operation Figure 4.Peripheral connection 5.Quit game Use the navigation+Enter key to select “Force Quit Applications” 6.Back to Application VOL- VOL- VOL+...
- Page 4 1.Use the Navigation+Enter key to enter the settings 1.1 Connect WIFI step by step 1.3 Select General menu to set language 1.3.1 Click the “language” menu 1.3.1.1 Select the language you wanted. 2. Multimedia Player Select video-player ， enter into playlist. Knob down Menu, to operate as the following picture, then select360°model, and it can play.
- Page 5 3.Long press for 2 seconds to back home and enter into App Store for Game installation and Download Manager To download the game, select “Game”to download installation 4. HDMI Input Content with HDMI output devices can be displayed on the VR glasses. Connect HDMI cable （HDMI A TO HDMI C）.Press Direction Button and Enter ，you can connect game device such as XBOX ONE、...
- Page 6 5.2 You should do related game settings when not opening the gyroscope function which exists in games, such as “Modern Warfare4”. 6. Game Controller Introduction 2. Game controller Performance Parameters 2.1 Working distance 8-10M. 2.2 Indicator light of game controller: 2.2.1 Power off charging(button switch to OFF) red light will on when charging, full of orange light 2.3 Charger time：2-3Hours.
- Page 7 10 This product can not be experienced with myopic galsses. 八.FAQ 1. What is APK? A: APK is Android Package Acronym，Android installation package. 2. How to get APK？ A: You can download and install online via PC, or download and install form “Android Market”. 3.
- Page 8 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
