SPECIFICATIONS
Model number
302
300g
T
-602
600g
T
-1002
1000g
T
-2001
2000g
T
-3001
3000g
T
-5201
5200g
T
Platter
Net/gross weight
Package
6 Units in one box:
Operating Temperature
Power source
ERROR CODE
Error
Reason
Code
Err-O
Overload
Err-Z
1).Exceeded the zero
tracking range when
powering on.
2).Forgot to install pan
when
performing
linearity calibration.
Err-S
Inner code unstable
when powering on.
Err-L
Calibrating without a
weight or the weight
is not the correct value.
Err-P
Counting setting error.
Capacity
Division
0.01g
0.01g
0.01g
0.1g
0.1g
0.1g
136x140mm
3.5lb/4.5lb
Standard carton: 33.5×23×14(cm
48.5×39.5×46(cm
0-40℃(32-104℉)
6XAAor AC/DC
Adapter 12V/500mA
Trouble Shooting
Use within capacity.
1). Pan should be empty on power up.
Remove any weight from pan.
2). Install pan and then recalibrate scale
（linearity calibration）.
1) Make sure the scale is stable when
powering on.
2) Low battery, change or charge battery.
3) Allow for longer warm up period.
Place a calibration weight of the value
shown on the display and then press
calibration button.
Place the correct size parts sample when
setting up counting mode.
COMPACT SCALE
INSTRUCTION MANUAL
3
)
3
)
/
BALANCE
Advertisement
Table of Contents
Summary of Contents for VERITAS T-302
-
Page 1: Specifications
SPECIFICATIONS Model number Capacity Division 300g 0.01g -602 600g 0.01g -1002 1000g 0.01g -2001 2000g 0.1g COMPACT SCALE BALANCE -3001 3000g 0.1g -5201 5200g 0.1g Platter 136x140mm INSTRUCTION MANUAL Net/gross weight 3.5lb/4.5lb Standard carton: 33.5×23×14(cm Package 6 Units in one box: 48.5×39.5×46(cm Operating Temperature 0-40℃(32-104℉) - Page 2 SAFETY PRECAUTIONS CALIBRATION All safety messages are identified by the following the words "WARNING" and When to calibrate "CAUTION". These words mean the following: 1. Press [ON/OFF] to turn the power on for 15 minutes for warm up. 2. With scale turned off, press [ON/OFF] to turn the power on. Important information to alert you to a situation that 3.
- Page 3 PARTS DESCRIPTION FUNCTION SETTINGS 1. Press [ON/OFF] to turn on the scale, the display will show flash digits and then --------, press [PRINT], the display will shows the serial port b xxx BAU value. Press [UNIT] to RIGHT SIDE select among 1200, 2400, 4800 and 9600, our default setting is 9600. Press [ZERO] to enter Parity mode, the display will show P XXX PAR, press [UNIT] to AC adaptor select odd, even, none (odd stands for 7 data bits with odd parity, even stands for 7 data...
- Page 4 PREPARATION WEIGHING Before weighing 1.Installing batteries/Connecting the AC adaptor Whenever possible, please allow the balance to warm up for 10 minutes after first turning to power on, so that the balance will function properly and accurately. Calibration may be required before weighing. Read "CALIBRATION"...
