Summary of Contents for HeartCheck MD100B

  • Page 2 VER1.0B1 HeartCheck HANDHELD ECG MONITOR Copyright This document is intended to be used solely for the use of the HeartCheck© ECG monitor. No part of this work may be copied or disseminated without prior written approval from the distributor. All information contained in this publication is believed to be correct at the time of publishing.
  • Page 3 VER1.0B1 HeartCheck HANDHELD ECG MONITOR Notes on Safety This device monitors and records ECG waveforms, it is not intended for medical diagnosis. Please refer any recordings to a qualified physician for medical interpretation. This device is not a substitute for seeking medical attention. If you believe you are experiencing any adverse medical event, you are to seek medical attention immediately.
  • Page 4 VER1.0B1 HeartCheck HANDHELD ECG MONITOR General Avoid extremes in temperature and humidity. Do not use this device in locations subject to high or low temperatures or humidity. Use at a temperature within 5°C to 40 °C and below 80% RH.

  • Page 5: Table Of Contents

    VER1.0B1 HeartCheck HANDHELD ECG MONITOR Contents General Description..................... - 5 - Battery Installation....................... - 7 - Setting Date and Time....................- 8 - Taking a Measurement....................- 9 - Displaying an ECG..................... - 19 - System Settings ......................- 21 - Data Management ......................

  • Page 6: General Description

    VER1.0B1 HeartCheck HANDHELD ECG MONITOR 1. General Description 1.1 Know Your Device Picture 1-1 Description of Picture 1-1: ① POWER button: Power on or off the device. ② Right Metal Electrodes: Hold these two with right index finger when taking a measurement.

  • Page 7: Intended Use

    VER1.0B1 HeartCheck HANDHELD ECG MONITOR ⑩ USB interface: Transmit data to the PC through this interface. 1.2 Product Features Small, portable and easy to use. Choice of two measuring modes. USB data transmission. Fast measurement in just 30 seconds. Up to 200, 30 seconds ECG Strips recorded.
  • Page 8 VER1.0B1 HeartCheck HANDHELD ECG MONITOR 1.4 Display The device screen is used to display the ECG waveform, a confirmation of the ECG quality, other parameters, such as time & date, battery status and the status of data storage in memory.

  • Page 9: Battery Installation

    Picture 1-2 Picture1- 3 “ Measurement”: Enter this menu to select the measurement mode and take a measurement. GRAPH Menu”: Enter this menu to review, delete, and lock the detected ECG “ waveform and ECG quality result. Enter this menu to set the Date & Time, Brightness, Beep Tone “...

  • Page 10: Setting Date And Time

    VER1.0B1 HeartCheck HANDHELD ECG MONITOR Battery life Two new AAA batteries will last for approximate 400 measurements. The batteries enclosed in the package are used for demonstration purposes. It is possible that these batteries will not last for 400 measurements.

  • Page 11: Taking A Measurement

    VER1.0B1 HeartCheck HANDHELD ECG MONITOR 2. Select the “Set Menu” item, as shown in Picture 3-1 Picture . And then press the “OK” button to enter. Picture 3-2 3. Select the “Date and Time” item, as shown in Picture , then press the “OK” button.
  • Page 12 VER1.0B1 HeartCheck HANDHELD ECG MONITOR ---- Do not wipe or get disinfectant alcohol on parts other than the electrodes. Do not move during measurement. ---- Movement, including talking, coughing, or sneezing, during measurement can affect the quality of the measurement results.
  • Page 13 VER1.0B1 HeartCheck HANDHELD ECG MONITOR Notes: During measurement, the device will only respond to the “MENU” or “OK” button to discontinue the measurement. If the contact between the electrodes and skin becomes loose, or the conditions change during measurement, the recording may be inaccurate.
  • Page 14 VER1.0B1 HeartCheck HANDHELD ECG MONITOR Measurement for Female Locate the ECG monitor at the lower end of the breastbone and move horizontally to the middle of the left part of the chest. If necessary, gently lift the breast and place the left metal electrodes under the left breast.
  • Page 15 VER1.0B1 HeartCheck HANDHELD ECG MONITOR 4.2.3 Cable Measurement If palm measurement is not ideal and it is not convenient to adopt the chest measurement, the cable measurement is recommended. 1. Place the electrode patches on the appropriate body areas as depicted in Picture 4-4. Connect the cables to the patches with the matching colour ends.
  • Page 16 VER1.0B1 HeartCheck HANDHELD ECG MONITOR or the connection of the unit and lead cable. Wrong Operation Methods: A. Cables are mounted incorrectly. B. Electrode patches have been placed on the body incorrectly 4.3 Measurement Mode: There are two measurement modes for your selection easy mode and continuous mode.
  • Page 17 VER1.0B1 HeartCheck HANDHELD ECG MONITOR Picture 4-9 Description of Picture 4-9: “2010-04-23”: The current date. “09:05:47”: The current time. “010/200”: Indicates that ten measurement results have been saved in the device and the device may store up to a maximum of 200 records.
  • Page 18 VER1.0B1 HeartCheck HANDHELD ECG MONITOR Description of Picture 4-11 “2010-04-23”: The current date “09:05:47”: The current time “010/200”: Indicates ten measurement results have been saved in the device and the device can store up to 200 records. Indication of the power level of the battery.
  • Page 19 VER1.0B1 HeartCheck HANDHELD ECG MONITOR Picture 4-14 To input the first name, press button to change the character from A to the required letter (such as J in John) and then press the OK button to move the cursor to the next space. Set each character of the first name based on the afore mentioned steps.
  • Page 20 VER1.0B1 HeartCheck HANDHELD ECG MONITOR Picture 4-16 Picture 4-17 To turn off the device press the button for three seconds Note: If you forget to turn the device off, it will automatically shut down within one minute. Users can set the auto power off time limit (1 minutes, 2 minutes…10 minutes) in “System Settings”...

  • Page 21: Displaying An Ecg

    VER1.0B1 HeartCheck HANDHELD ECG MONITOR transmission software. To use the data transmission software connect the device to a computer by using the data cable provided. Recordings may be saved in the software on the computer once the transmission is complete.
  • Page 22 VER1.0B1 HeartCheck HANDHELD ECG MONITOR Picture 5-3 Description of picture “001/200”: It indicates one measurement has been saved in the device and the device can store up to 200 records. : ECG amplitude ruler : ECG waveform : Measurement progress bar : The interval of the current ECG waveform.

  • Page 23: System Settings

    VER1.0B1 HeartCheck HANDHELD ECG MONITOR record can NOT be deleted. To unlock the records， select the icon again and press the “OK” button. Picture 5-5 System Settings Select “Set Menu” in the main menu by pressing the button, and then press the “OK”...

  • Page 24: Data Management

    VER1.0B1 HeartCheck HANDHELD ECG MONITOR Picture 6-2 6.3.2 Press the “OK “button to save the settings, and to return to the previous interface. Auto Power-off Setting 6.4.1 Press the button to select the “Auto Power off” item, and then press the “OK”...

  • Page 25: Version

    VER1.0B1 HeartCheck HANDHELD ECG MONITOR Picture 7-1 Press the “OK” button to erase all data. Picture 7-2 Select either “YES” or “NO” by using the & buttons. If selecting “YES” all data on the device will be deleted. Selecting “NO” will cancel the function.

  • Page 26: Key Symbols

    VER1.0B1 HeartCheck HANDHELD ECG MONITOR out. 1. The electrodes have 1. Place the electrodes correctly. not made good contact 2. When measuring, please keep The device is with your body. quiet and avoid moving. failure in 2. Movement occurred 3. Keep away from...

  • Page 27: Technical Data

    VER1.0B1 HeartCheck HANDHELD ECG MONITOR 12. Technical Data Classification: According to the type of protection against electric shock, it can be classified as internally powered equipment. The device’s application type is CF and it is a movable common facility with no defibrillator or protection.

  • Page 28: Maintenance And Storage

    VER1.0B1 HeartCheck HANDHELD ECG MONITOR Backlight：LCD backlight Data Storage: Every record stored holds 30 seconds of ECG data. The device can store 200 ECG recordings. Dimension and Weight: Dimension: 136mm×84mm×21mm（Length × Width × Height） Weight: 120g (Not including Two AAA batteries)

  • Page 29: General Information About The Heart And Ecg Measurements

    VER1.0B1 HeartCheck HANDHELD ECG MONITOR Do not place objects on top of the device. This could damage the device. Do not disassemble the device. Do not sterilize this device in an autoclave, ultraviolet sterilizer or gas sterilizer (EOG, formaldehyde, high density ozone etc.).
  • Page 30 VER1.0B1 HeartCheck HANDHELD ECG MONITOR An ECG monitor is able to measure the electrical impulse as it passes across and through the heart, causing the heart to beat. An ECG does not measure the movement of your heartbeat, but rather the electrical activity that causes the heart to beat. The measurements recorded by an ECG monitor, when combined with a medical examination, can help your doctor monitor your heart condition.

  • Page 31: Appendix

    VER1.0B1 HeartCheck HANDHELD ECG MONITOR What is Arrhythmia? Arrhythmia is a condition where the heartbeat rhythm is abnormal due to flaws in the bio-electrical system that drives the heartbeat. Typical symptoms are skipped heartbeats, premature contraction, an abnormally rapid (tachycardia) or slow (bradycardia) heart rate.
  • Page 32 VER1.0B1 HeartCheck HANDHELD ECG MONITOR Guidance and manufacture's declaration - electromagnetic immunity for EQUIPMENT and SYSTEMS that are not LIFE-SUPPORTING Guidance and manufacture's declaration - electromagnetic immunity The Handheld ECG Monitor is intended for use in the electromagnetic environment special below. The customer or the user of Handheld ECG monitor should assure that it is used in such an environment.
  • Page 33 VER1.0B1 HeartCheck HANDHELD ECG MONITOR Field strengths from fixed transmitters, such as base situation for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered.
  • Page 34 VER1.0B1 HeartCheck HANDHELD ECG MONITOR 3.6893 7.7386 11.6667 23.3334 For transmitters rated at a maximum output power not listed above, the recommended separation distance in meters (m) can be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer.
