Summary of Contents for Acces i/o P104-COM232-8
- Page 1 10623 Roselle Street, San Diego, CA 92121 (858) 550-9559 Fax (858) 550-7322 contactus@accesio.com www.accesio.com MODEL P104-COM232-8 USER MANUAL FILE: mP104-COM232-8.A1f...
- Page 2 ACCES, nor the rights of others. IBM PC, PC/XT, and PC/AT are registered trademarks of the International Business Machines Corporation. Printed in USA. Copyright 2003, 2007 by ACCES I/O Products, Inc. 10623 Roselle Street, San Diego, CA 92121. All rights reserved.
- Page 3 Other than the above, no other warranty, expressed or implied, shall apply to any and all such equipment furnished or sold by ACCES. Manual P104-COM232-8...
-
Page 4: Table Of Contents
Figure 2-1: PC/104 Key Information ................8 Chapter 3: OPTION SELECTION...................9 Figure 3-1: Option Selection Map ..................9 Chapter 4: ADDRESS SELECTION ..................10 Chapter 5: CONNECTOR PIN ASSIGNMENTS..............11 Table 5-1: P1 Connector Pin Assignment ..............11 Table 5-2: P2 Connector Pin Assignment ..............12 Chapter 6: SPECIFICATIONS....................13 Manual P104-COM232-8... -
Page 5: Chapter 1: Introduction
Programming Interface. This means every program you've ever used with a standard serial port in Windows will also work with these ports, no problem. In addition, we provide several utility and sample programs to help you write your own code, if you're not using something off-the-shelf. Manual P104-COM232-8... - Page 6 Figure 1-1: Block Diagram Manual P104-COM232-8...
-
Page 7: Chapter 2: Installation
CPU board (signal group 3). Place the SEL-1 switch to the left and SEL-2 to the right to select signal group 1, place the SEL-1 switch to the right and SEL-2 to the left to select signal group 2. Manual P104-COM232-8... - Page 8 Position the slide switches to select the clock, IDSEL, and interrupt signal group. Install the card in a PC/104-Plus stack. Install I/O cables at P1 and P2. Inspect for proper fit of the card and cable and then tighten the screws. Manual P104-COM232-8...
-
Page 9: Chapter 3: Option Selection
Most PCI bus signals are common to all four cards in the PCI stack. However, there are four unique signal groups, one for each card. The slide switches select which signal group goes to each card. The card in the stack closest to the CPU board must get signal group 0. Figure 3-1: Option Selection Map Manual P104-COM232-8... -
Page 10: Chapter 4: Address Selection
PCIFind uses the Vendor ID and Device ID to search for your card, then reads the base address and IRQ. If you want to determine the base address and IRQ yourself, use the following information. The Vendor ID for the card is 494F. (ASCII for "IO") The Device ID for the card is 10A8. Manual P104-COM232-8... -
Page 11: Chapter 5: Connector Pin Assignments
Tx 2 CTS 2 Data Terminal Ready 2 Ring Indicator 2 ground no connection Carrier Detect 3 Data Set Ready 3 Rx 3 RTS 3 Tx 3 CTS 3 Data Terminal Ready 3 Ring Indicator 3 ground no connection Manual P104-COM232-8... - Page 12 Tx 6 CTS 6 Data Terminal Ready 6 Ring Indicator 6 ground no connection Carrier Detect 7 Data Set Ready 7 Rx 7 RTS 7 Tx 7 CTS 7 Data Terminal Ready 7 Ring Indicator 7 ground no connection Manual P104-COM232-8...
-
Page 13: Chapter 6: Specifications
Meets or exceeds the IEEE RS-232 standard Environmental Operating Temperature Range: -40 C to +85 C Humidity: 5% to 95%, non-condensing Storage Temperature Range: -65 C to +125 C Power Required: 50mA quiescent, 150mA maximum Size: PC/104-Plus format, 3.5" x 3.75" Manual P104-COM232-8... - Page 14 If you experience any problems with this manual or just want to give us some feedback, please email us at: manuals@accesio.com. Please detail any errors you find and include your mailing address so that we can send you any manual updates. 10623 Roselle Street, San Diego CA 92121 Tel. (858)550-9559 FAX (858)550-7322 www.accesio.com Manual P104-COM232-8...
