Command access PM300UNIV Installation Instructions

PM300UNIV

Installation instructions

Overview of Product
The PM300 is a power booster interface module that fits inside of an electric latch pullback exit device. When installed in the exit device
it typically allows for a much longer wire run from the power supply to the exit device (typically up to 700' with 18/2 wire) than the exit
device manufacturer's original recommendations. This is great solution for projects that were pre-wired with too thin of a gauge wire or
where a discerning architect wants all the power supplies consolidated in a central room for simplified maintenance. Additionally, this is a
great solution when the original exit device manufacturer's power supply is not available or is cost prohibitive.
Here's how the PM300 works – When the exit device is triggered, the power supply sends power to quickly charge the PM300. Within
500ms, the PM300 releases its high current pulse to the exit device solenoid giving it what it needs to retract the latch bolt. Once the latch
bolt is retracted, the PM300 switches to the Pulse Width Modulation (PWM) mode that reduces the current and allows the solenoid to
remain energized continuously, if desired. This unit is also equipped with a mode switch that allows the option of High Output mode for
those applications the require a higher pulse (special power supply required).
PM300UNIV
Models:
PM300UNIV-D
Specifications:
Operating Voltage Range: 26.5V +/-15%
Wires:
Relays: We recommend that minimum 5A relays are used with the PM300 when used with
Power Supply Options for PM300UNIV and PM300UNIV-D in Standard Mode:
The PM300 works best with the Command Access PS1N, PS2, PS2BB & all PS5 series regulated power supplies. The PM300 will also work
with most Regulated power supplies rated at 24VDC and 1.5A or higher. Although we do not recommend using power supplies that we
have not thoroughly tested with the PM300, if you choose to do so anyway we recommend you consider the following:
1. The Regulated power supply should be rated 24VDC at 1.5 Amps or higher.
2. If the output fuses are glass type, they will need to be rated at minimum of 3.5 A. If the fuses are the resetable type, they should
have a trip rating of 1Amp or higher and a hold of a 1/2 Amp or greater.
(
If these values are not listed, the power supply manufacturer should be able to give you this information. We recommend that you consult with the power supply
manufacturer to confirm that if replacing the fuses with a higher value is necessary that doing so will not damage the power supply or create any kind of safety risk)
(Note: Not compatible with Adams Rite, Dorma, Yale, Corbin Russwin, Precision latch retraction power supplies)
Power Supply Options for PM300UNIV and PM300UNIV in High Output Mode:
In High Output mode, the PM300 is design to be powered by the Command Access PS1N, PS5-4, and PS5-6 power supplies only.
**Command Access is not a licensee, or affiliated, associate or connected with Ingersol Rand, Assa Abloy, Dorma, Stanley
Wires directly to the solenoid for most solenoid activately devices. Adapter cables are offered
-
for numerous manufactures, such as, Adams Rite, Corbin/Yale, Precision, and more.
-
Sames as PM300UNIV above with the added feature of a .5 second delay.
Input to PM300 non-polarized Black (+), Black (-)
Output from PM300: Yellow=Pull Coil; Orange= Hold Coil; Green=Common
power supplies other than those listed below.
Security Solutions, Schlage, Cal Royal, Corbin Russwin, Precision, Sargent**
**Use of this item may void other factories warranties**
Comments? Please email us at orders@commandaccess.com
or call us: 1-888-622-2377 (6-ACCESS)
22901 La Palma Ave, Yorba Linda, CA 92287 www.commandaccess.com
PM300 Instructions Rev. 1.0 Page 1
