Summary of Contents for Saftronics PC10
- Page 1 PC10 Relay Output Card Saftronics, Inc. CARD NO. 100-0159-01 DOC. NO. 027-0159 11/01 5580 Enterprise Pkwy., Ft. Myers, FL 33905 Telephone: (941) 693-7200 Fax: (941) 693-2431 www.saftronics.com...
- Page 2 SAFETY FIRST ! LETHAL VOLTAGES MAY BE PRESENT! PLEASE READ THIS INSTRUCTION MANUAL THOROUGHLY BEFORE ATTEMPTING ANY INSTALLATION, OPERATION, MAINTENANCE OR INSPEC- TION. FAILURE TO FOLLOW THE RECOMMENDED PROCEDURES OR CAUTIONS IN THIS MANUAL COULD RESULT IN INJURY TO PERSONNEL AND/ OR DAMAGE TO EQUIPMENT.
- Page 3 Description The 100-0159-01 RELAY OUTPUT CARD, provides (2) relay form C outputs for the PC10 Inverter. It has “hard pins” to assemble directly to the PC10’s control terminals and screw type output terminals. Specifications Output relays - Form C contacts: 120 VAC @ 0.5A / 24 VDC @ 1.0A...
- Page 4 y t i u l i e f i PAGE 4...
- Page 5 PC10 INVERTER 100-0159-01 PC10 RELAY INTERFACE PAGE 5...
- Page 6 All products designed to incorporate a component part manufactured by Saftronics , must be supplied to the end user with appropriate warn- ings and instructions as to the safe use and operation. Any warnings provided by Saftronics must be passed through to the end user.
