Inforce Security 4-30 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual (5.1.0.0)
DVR user manual
(Version 5.1.0.0)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4-30 and is the answer not in the manual?

Questions and answers

Summary of Contents for Inforce Security 4-30

  • Page 1 User Manual (5.1.0.0) DVR user manual (Version 5.1.0.0)

  • Page 2: Hardware Specification

    HARDWARE Specification 1.1 Product Specification Models 4-30 /4-60 / 4-120 / 8-60 / 8-120 / 8-240 / 12-90 / 16-120 / 16-240 / 16-480, 24-180, 32-240 30fps(NTSC), 25fps(PAL)/30, 25/60, 50/60, 50/120, 100/120, 100/240, 200/120, 100/240, 200/480, 400/480, Displaying Speed 400/480, 400/240, 200...
  • Page 3 User Manual (5.1.0.0) CHAPTER 2 SOFTWARE INSTALLATION Steps: 1. Insert DVR CD. 2. A menu shows up and select the program to install.
  • Page 4 User Manual (5.1.0.0) 2.1 Automatic Installation 2.1.1 Click to install the DVR program 2.1.2 Installation Method Selection 2.1.3 Choose Installation Directory...
  • Page 5 User Manual (5.1.0.0) 2.1.4 Select Features 2.1.5 Begin Installation...
  • Page 6 User Manual (5.1.0.0)
  • Page 7 User Manual (5.1.0.0) 2.1.6 DVR File System Installation Select the available drive(s) on the left hand side and click “Add” to put the selected drive(s) to the right hand side. Then, click button “Initialization” prepare drive(s) for video storage. Selecting “Quick Initialization” will initialize the entire drive capacity added.
  • Page 8 User Manual (5.1.0.0) At least one of “available disk drive” must be added for data storage. Otherwise, the alert message will pop up.
  • Page 9 User Manual (5.1.0.0) 2.1.5 Completion...
  • Page 10 User Manual (5.1.0.0) 2.3 Remote Client Installation 2.3.1 Using DVR installation CD Click to install...
  • Page 11 User Manual (5.1.0.0)
  • Page 12 User Manual (5.1.0.0) 2.3.2 Using Web Browser 1. Type in the IP address of DVR server. 2. Log in first before downloading Remote Client Program.
  • Page 13 User Manual (5.1.0.0) 1. Live View 2. Screen splits and channel selection 3. PTZ control: Only users with proper authority to control PTZ remotely. 4. Advanced: Controlling preset, tour and E-map only for authorized users. 5. Speed: PTZ speed control 6.
  • Page 14 User Manual (5.1.0.0) 1, Searched Image 2. Selection for image search 3. Playback (Fast back, Back, Stop, Play, Fast Play) 4. Save: AVI, JPEG, BMP 5. Audio 6. To change Tab to CONTROL 7. Log out and go back to LOG IN page...
  • Page 15 User Manual (5.1.0.0) 3. Click the “Install Remote Client” button for downloading.
  • Page 16 User Manual (5.1.0.0) Follow the instruction until it comes to the end like the figure below.
  • Page 17 User Manual (5.1.0.0) 2.4 Uninstallation of DVR program Click “remove” to uninstall program.

  • Page 18: Program Execution

    User Manual (5.1.0.0) 2.5 Program Execution Find the icons on the desktop to execute “DVR Server” or find “DVR Server” under “All Programs”.
  • Page 19 User Manual (5.1.0.0) CHAPTER 3 Main System Application (Control) 3.1 Startup Screen The above screen will appear as DVR Server system starts. 3.2 Login The default values for User and Password are “admin” and “no password”. Click “OK” to execute DVR Server system. To give “admin” a password and to create new users, certain configurations are required (Setup/User).
  • Page 20 User Manual (5.1.0.0) 3.3 Exit/Logout To end DVR Server system, select “Exit” and type in password. 3.4 System Information Click on System Information to see DVR system information, such as OS version, CPU, RAM, HDD, IP address, DVR model and DVR software.
  • Page 21 User Manual (5.1.0.0) 3.5 Control Screen Date/Time User Mode Model Name Setup Network Adjust PTZ Adjustment Preset Camera Layout Panel Touring E-map I-phone Volume Light PTZ Control Power Camera Selection Panel Manual Output Panel Control Status Search...
  • Page 22 User Manual (5.1.0.0) 3.6 Setup 3.6.1 System 3.6.1.1 DVR Information Create a DVR name and put in admin. info. They will be displayed on outgoing e-mails.
  • Page 23 User Manual (5.1.0.0) 3.6.1.2 System Time Setup By clicking System Time Setup, user is able to set Date and Time in DVR software.
  • Page 24 User Manual (5.1.0.0) 3.6.1.3 System Power Management * Period: Select a day that DVR system reboots automatically by the period. * Reserved time: Time set to shut down or to reboot computer * Disable: selected when System Power Management is not to be used * Shutdown: selected when shutting down computer is required at the time set...
  • Page 25 User Manual (5.1.0.0) 3.6.1.4 Auto-switching Interval Auto-switching Interval is a function that allows green square around selected camera to move to the next one at the interval set. e.g.) Camera 1 -> 10 sec. -> Camera 2 ->10 sec. -> Camera 3…. 3.6.1.5 E-map Click on the “E-map”...
  • Page 26 User Manual (5.1.0.0) The above is a designed E-map sample. Drag mouse to position Camera/Input/Output and design E-map.
  • Page 27 User Manual (5.1.0.0) Click on the E-map button positioned next to the I-phone button to open E-map. White Camera: Not on Recording, Yellow Camera: On Recording, White Input/White Output: Not Activated, Yellow Input/Yellow Output: Activated 3.6.1.6 TV-OUT TV-OUT is a function that sends selected cameras to a call monitor (external analog monitor).
  • Page 28 User Manual (5.1.0.0) The Number of TV-out Supported 4-30 8-60 12-90 16-120 CA4-60 CA8-120 CA16-120 CA16-240 CA8-240 16-480/240 Manual Channel Selection - Channels are selected manually. Once “Manual Channel Selection” is selected, channels can also be selected manually on Control screen by placing mouse on camera picture and clicking the right mouse.
  • Page 29 User Manual (5.1.0.0) On a camera screen, you may click one right mouse to control OSD as bellows. * Show Camera Names and Status: By checking it, camera names and status will be displayed on camera pictures. * Show Motion Detection Blocks: By checking it, green motion detection blocks will be displayed on camera pictures when recording schedule is set as “M”...
  • Page 30 User Manual (5.1.0.0) 3.6.1.8 Text Inserter Text Inserter is a function that allows DVR system to integrate with POS machines. Simply select POS driver like selecting PTZ driver to enable POS text inserter program and transactions that occur will be displayed on selected camera pictures.
  • Page 31 User Manual (5.1.0.0) * Text Filter: Register important goods and useless text to display distinguishably and search POS data conveniently. Important goods items: Pre-registered items will displayed in red characters. * Useless text: It is not going to be displayed during transaction.
  • Page 32 User Manual (5.1.0.0) Font Settings: Font change on screen display. Postion Setting: Position change on screen display.
  • Page 33 User Manual (5.1.0.0) 3.6.1.9 Hard Disk Usage Hard Disk Usage is to select data storage method. If “Once” is selected, data will be stored up to the point where HDD reaches its maximum capacity. If “Recycle” is selected, data will be overwritten from the point HDD reaches its maximum capacity based on “First In First Out”.
  • Page 34 User Manual (5.1.0.0) 3.6.1.11 Maintenance Log It is used to record and view maintenance history. 3.6.2 Device Device sub-screen is divided into 5 different setup categories; Camera, Output, Input, Audio and Alert. All devices in each category can be set up on one same page.
  • Page 35 User Manual (5.1.0.0) 3.6.2.1 Camera Cameras will be enabled by checking the boxes. Different resolutions recording frame rates can be set up for different cameras. * Video Signal Type: Select either NTSC or PAL. Auto Channel Scan: automatically identifies all the active video channels.

  • Page 36: Motion Detection

    User Manual (5.1.0.0) [Motion Detection] Select a function among Motion detection, Object detection and People Count. Motion detection is a function that software detects every movement or motion by Zone Setting: comparing a frame with its 1. Drag mouse on desired place to set motion detection zones. previous frame.
  • Page 37 User Manual (5.1.0.0) Zone All: Displays all areas together that have been set for the zones. Setting All: Select whole area Delete Zone: Deletes zones one by one.
  • Page 38 User Manual (5.1.0.0) [Object Detection] It is a function that marks all the changes occurred from the original scene. DVR will detect new & missing objects after a certain period of time (detecting interval). *Detecting Interval: An interval that DVR tries repeatedly to detect any object change in the zone set.
  • Page 39 User Manual (5.1.0.0) Object Detection Blocks Click the right mouse and select “Clear Object Detection Blocks” to remove all the blocks. How to Set up: Tick the “Object Detection” box and click on “Zone Settings”. • Drag the mouse to select object detection zone (same as “Motion Detection”). •...
  • Page 40 User Manual (5.1.0.0) [People Counter] It is a function that counts people coming in and out of a certain place. How to Set up: 1. Set Count Interval. 2. Set zone by dragging mouse. 3. If a directional counting is needed, select one.
  • Page 41 User Manual (5.1.0.0) [Mosaic] It is a function that veils restricted areas to keep regular users uninformed. How to Set up: Click on “Advanced”. • • Tick the “Use Mosaic” box. Click on “Mosaic Zone Settings”. • • Set “Mosaic Zone”. Go to the “Control Screen”...
  • Page 42 User Manual (5.1.0.0) [Data Retain] It is a function that retains data only for the period set. For example, if 10 days is set, DVR will delete all previous data before 10 days regardless of the capacity remaining in HDD. How to Set up: •...
  • Page 43 User Manual (5.1.0.0) [PTZ Camera Setup] When using a PTZ camera, check the box and select a model name. DVR system supports nearly 40 different protocols. * Camera ID: Leave it as it is if only one PTZ camera is used.
  • Page 44 User Manual (5.1.0.0) [Preset & Touring] Either click the right mouse on camera picture or click on the Preset (Touring) button for Preset (Touring) setup and use. “Preset” is a function that enables a camera to move from one position to another automatically. [Preset]...
  • Page 45 User Manual (5.1.0.0) * Steps to Set up Presets * 1. Move camera to a desired position using the PTZ Control on Control screen. 2. Click the right mouse. 3. Name the preset. 4. Repeat the above for setting up as many as 256 presets.
  • Page 46 User Manual (5.1.0.0) [Touring] “Touring” is a function that enables a group of selected presets to work repeatedly. * Steps to Set up a Tour * 1. Click the right mouse. 2. Name the tour. 3. Click on “Add”. 4. Select a preset. 5.
  • Page 47 User Manual (5.1.0.0)
  • Page 48 User Manual (5.1.0.0) Advanced PTZ setup can be done by one right mouse click. Make sure that the PTZ camera to set up supports advanced PTZ control functions first.
  • Page 49 User Manual (5.1.0.0) [Access Control] It is a function that integrates Access Control into DVR system. For Access control DVR, please refer to another document “Access control DVR”. How to Set up: Click on “Advanced” • Click “Access Control • Integration”...
  • Page 50 User Manual (5.1.0.0) 3.6.2.2 Output Device DVR system can be equipped with as many as 8 output devices. Simply check the boxes for use. In addition, outputs can be manually activated from Control screen (Manual Alarm). Double-click “Output” individual output setup. * Name: Output device name.
  • Page 51 User Manual (5.1.0.0) 3.6.2.3 Input Device DVR system can be equipped with as many as 16 input devices. Simply check the boxes for use. Each and every input can be tuned independently. Signal Types: NO(+) & (-) detached normally NC(+) & (-) attached normally...
  • Page 52 User Manual (5.1.0.0) 3.6.2.4 Audio DVR system is equipped with as many as 8 audio channels. Simply connect cameras to audio channels for use, and audio recording will be completed as chosen. (e.g.) The above selections indicate that Audio2 will record Camera3, Audio3 will record Camera5, etc.
  • Page 53 User Manual (5.1.0.0) 3.6.2.5 Alert DVR system is equipped with 1 alert device. Alert is the beep inside the system that sounds in the case of event. Check the box for use and select an alert mode. Length of Activation: The length of alert activation (1-60 sec.).
  • Page 54 User Manual (5.1.0.0) *Event Sound Settings: To differentiate alert sound by Events (Sensor, Motion, and No video Signal), select a Wave File for each.
  • Page 55 User Manual (5.1.0.0) 3.6.3 Event “Event” consists of 3 different groups; “Input”, “Motion Detection” and “No Video Signal”. On this menu, devices can be set to respond to different events. 3.6.3.1 Input * Length of Full Screen Display: The time length for full screen display in the case of input device activation.
  • Page 56 User Manual (5.1.0.0) 3.6.3.2 Motion Detection The same identical concepts and methods as “Input” are applied to “Motion Detection”.
  • Page 57 User Manual (5.1.0.0) 3.6.3.3 No Video Signal The same identical concepts and methods as “Input” are applied to “No Video Signal”. 3.6.3.4 Watchdog The same identical concepts and methods as “Input” are applied to “Watchdog”. When “Video Capture Error” is occurred, it is linking to Alert and Output.
  • Page 58 User Manual (5.1.0.0) The same identical concepts and methods as “Input” are applied to “Audio Capture Error”. When “Audio Capture Error” is occurred, it is linking to Alert and Output. User can link the event to Reboot, Message on DVR. The same identical concepts and methods as “Input”...
  • Page 59 User Manual (5.1.0.0) The same identical concepts and methods as “Input” are applied to “Recording Error”. When “Disk Writing Failed” is occurred, it is linking to Alert and Output. User can link the event to Reboot, Message on DVR.
  • Page 60 User Manual (5.1.0.0) 3.6.4 Schedule “Schedule” is a place where the different activities of different devices are determined. Each camera can have different recording options; scheduled recording by time & day and selective recording. * R: Recording at all times * E: Recording on event * N: Stop recording * H: Recording at all times and higher...
  • Page 61 User Manual (5.1.0.0) The holiday recording schedule set at the bottom of the “Schedule” table will be applied to selected dates. 3.6.4.1 Recording [Manual (Instant) Recording] It is a function that enables users to react on an emergency situation properly by making DVR start recording immediately.
  • Page 62 User Manual (5.1.0.0) 3.6.4.2 Device Select detailed schedule for recording on motion detection.

  • Page 63: Dvr Server

    User Manual (5.1.0.0) 3.6.5 Network 3.6.5.1 DVR Server * Supported Network: 1. TCP/IP - Connecting to DVR Server from Client using Lan or DSL 2. PSTN - Connecting to DVR Server from Client using PSTN or ISDN modem 3. None - Not allowed to connect to DVR Server remotely * Port No.: The default port number is 9091.

  • Page 64: Web Server

    User Manual (5.1.0.0) * Transmitted Video Quality: Video quality to be transmitted to Client. As a reminder, the higher video quality gets, the slower network transmission speed becomes. Therefore, it is often recommended to select low video quality when using “Narrowband”. * Bandwidth: Make sure to select the right bandwidth to have the right network performance.
  • Page 65 User Manual (5.1.0.0) Choose events to report to Central Station server and set reporting time period. 3.6.5.4 E-mail E-mail is a function that enables DVR system to send out e-mails when selected events occur. Check the box and click on “Properties” for setup. Note : Some e-mail servers may require authentication for ID and Make sure to put in the right IP...
  • Page 66 User Manual (5.1.0.0) Send camera(s) to send out image(s) when the event occurs.
  • Page 67 User Manual (5.1.0.0)
  • Page 68 User Manual (5.1.0.0) 3.6.5.5 Dial Alarm “Dial Alarm” is a function that enables DVR system to call out on selected events. Check the box and click on “Properties” for setup. Modem card must be installed inside DVR system to make this function work. Type in phone (mobile) number to report.
  • Page 69 User Manual (5.1.0.0) Click right mouse and select Properties for IP setup for DVR’s network functions. 3.6.6 User Users can be added, deleted or modified with different authorized access and control levels. There are no limits in the number of users created.
  • Page 70 User Manual (5.1.0.0) * Authorized Access: Checked functions will be allowed to access remotely. * Accessible Channels: Checked channels will be allowed to view remotely. * Control Level: The lowest number will be allowed to have the first priority to set up, control, etc remotely.
  • Page 71 User Manual (5.1.0.0) CHAPTER 4 View Log Application (Status) 4.1 Screen Features Recording Camera: It shows recording status. Sensor Detection: It shows sensor detection status. Motion Detection: It shows motion detection status. Alarm: It shows alarm activation status. HDD Capacity: It shows HDD capacity used for recording. Event: It shows events occurred.
  • Page 72 User Manual (5.1.0.0) 4.1.1 Event Log * Date: All dates with events will be marked in bold numbers. * List: All events for a certain selected date will be shown. * Delete All Logs: If clicked, all the previous records will be deleted.
  • Page 73 User Manual (5.1.0.0) CHAPTER 5 Playback Application (Search) 5.1 Search Features 1 Calendar: All dates with recorded data will be marked in bold numbers. Blur/Sharp/Normal: Buttons to adjust sharpness of image Zoom: Buttons to zoom in/out Brightness: buttons to adjust brightness Contrast: buttons to adjust contrast Default: Default for Zoom/Brightness/Contrast 5.2 Search Features 2...
  • Page 74 User Manual (5.1.0.0) For playback, simply select date, screen mode (1, 4, 9, 16, etc.), time by one click on the time bar and click the play button. What different colors mean on the time bar: Blue: Recorded data by sensor & motion detection Purple: Recorded data by 24-hour-recording White: No recorded data in all cameras Gray: No recorded data for some cameras...

  • Page 75: Object Search

    User Manual (5.1.0.0) Select channels for Event Search. Select one event from the event list and click “OK”, and the selected event will be displayed. Click Refresh” to update the list. [Object Search] Object Search is only to search certain selected objects for a certain period of time. Scan: Set the time period for object search Motion Detection Zone: Select “Set”...
  • Page 76 User Manual (5.1.0.0) [Text Search ] It is to search POS text data with image according to selected time period and item. Put in an item (Reference), select time period and click on “Search”, and a list with transactions will be displayed. Searched words will be retained in the combo box in down-list format so the data can be easily shown in next search.
  • Page 77 User Manual (5.1.0.0) [People Count Search] It is to search people count statistics according to selected time period & camera. Through this function, the results of people count and POS transaction can be analyzed by the hour and cameras. Select date, camera & time, and statistics will be shown as below.
  • Page 78 User Manual (5.1.0.0) * How to read data and graph 1. Counted number of (T)ransaction/ Counted number of (P)eople count Red Color: Rate of people count Green Color: Rate of Transaction The Pie Graph will show at a glance how many transactions have been performed, compared to the number of people counted.
  • Page 79 User Manual (5.1.0.0) 5.2.3 Monitoring & Searching It is a feature that enables user to view live video while searching recorded data. Click the right mouse and select “Monitoring On” to view live video. Click the right mouse again and select “Monitoring Off”...
  • Page 80 User Manual (5.1.0.0) 5.2.4 Bookmark & Go To Bookmark (Favorites): Added data from “ Object Search” are stored here. Go To: Select desired time to search and click “OK”. 5.2.5 Save Watermark(Image) Using Watermark(Image): To attach a certain logo or special picture on AVI file.
  • Page 81 User Manual (5.1.0.0) Watermark Setting Select each for desirable watermark setting. Click on “Browse” to find watermark image logo.
  • Page 82 User Manual (5.1.0.0) [Save in AVI Format] Click “Start” to start saving and “Stop” to stop saving. Mute: Saving video only (no audio) High Speed: Saving in high speed Click time period settings and put the time period that you want to save.
  • Page 83 User Manual (5.1.0.0) Click “Start”and select “BMP” as you save images. [Save in BMP Saved images can be checked using “Watermark Proofer”. Format] [Watermark Proofer] Execute “Watermark Proofer” and check if certain saved images are forged or not.
  • Page 84 User Manual (5.1.0.0) Click “Start” and select “JPEG” as you save images. [Save in JPEG Format] Select time period and select channels to be saved in [Save in JPEG with Time Period] JPEG. 5.2.6 Print Click the “Print” button and follow the same printing procedure as you would normally print out documents.
  • Page 85 User Manual (5.1.0.0) 5.2.7 Backup The recorded data can be copied from the hard disk to external storage devices, such as CD-R, DVD. Back up recorded data using various backup devices. 5.2.7.1 DFS Back up...
  • Page 86 User Manual (5.1.0.0) DFS: Save in DFS file format. Dialog: Show the directory of burning software (e.g..Nero Burning) External CD Burning Program: User can run the other CD burning program such as Nero burning. After successfully back up the file, user can burn the data onto CD.
  • Page 87 User Manual (5.1.0.0) Select Time Period : Specify time period for backup. The minimum period for backup is 1 minute. If password is set, viewing backup data will be possible only when it is typed in. Backup Folder: Click the “Browse” button, select a drive to back up and enter a desired folder name.
  • Page 88 User Manual (5.1.0.0) Play CD-Burning: Check to burn the backup data through an external Burning program. Log File: Shows “Backup Start Time”, ”Directory”, ”Status-fail or Success”.
  • Page 89 User Manual (5.1.0.0) 5.2.7.2 EXE Back up Any recorded data can be saved as “.exe” file. No viewer program is required to see saved data. Note : 1. file size limited up to 1 GB. 2. 1 channel backup only.
  • Page 90 User Manual (5.1.0.0) Select “EXE File”. Specify time period, password, drive, etc. Select ONE channel to back up. Specify file size up to ONE GB. If it is larger than 1GB, multiple exe files will be created. Tick the “Once Make EXE File” box to create only one file with the file size specified. Double-click the exe file created to see data.
  • Page 91 User Manual (5.1.0.0)
  • Page 92 User Manual (5.1.0.0) 5.2.7.3 Run CD Burner ( For Non Windows XP Users) 1. Install bundle CD and install INCD. 3. After installing INCD, run “InCDL.exe” which is the INCD Launch Program. 4. Insert a blank RW CD and then start formatting it (If it is a brand-new one, click “Format” instead of “Quick Format”).
  • Page 93 User Manual (5.1.0.0)
  • Page 94 User Manual (5.1.0.0) 5. Leave the DVR Program and insert the blank RW CD which has been formatted. 6. Select “Backup” and click “Next” to start. 7. Select time period & password and click “Browse” to create a folder.
  • Page 95 User Manual (5.1.0.0)
  • Page 96 User Manual (5.1.0.0) 5.2.7.4 Run CD Burner ( For WindowsXP Users Only) Windows XP users can back up data directly in a CD without exiting the DVR Program. 1. Tick the “Save in CD data of backup” box and click “Next”.
  • Page 97 User Manual (5.1.0.0) Select Time Period : Specify time period and password. Select CD-RW drive. Create folder name if it should be used and click “Next”. CD information will be shown as below.
  • Page 98 User Manual (5.1.0.0) Select 1 channel to back up. Identify the maximum file size indicated. An attempt to back up more than the size indicated will result in a failure.
  • Page 99 User Manual (5.1.0.0) After completing back up, find the files created in the CD.
  • Page 100 User Manual (5.1.0.0) 5.2.7.5 Playback Click the “Start” button and run the “DVR’s Playback Program”. Select a folder (subfolder) to see saved data.
  • Page 101 User Manual (5.1.0.0) CHAPTER 6 Remote Monitoring System (Client) 6.1 Program Execution Double-click on the “DVR Client” icon on the desktop to execute Remote Monitoring System (Client). Click “Add” to register DVR servers. Note: Make sure to put the same Port No. as DVR server.
  • Page 102 User Manual (5.1.0.0) There can be more than one DVR server registered. Select one from “Servers”, click on “Login” and type in password to log in. * Edit: Login info. changes can be made here. * Delete: Registered servers can be deleted with one click. Full Screen Display on Event: If checked, full screen will be displayed on events.

  • Page 103: Remote Save And Backup

    User Manual (5.1.0.0) 6.2 Remote Save and Backup The instant AVI file save of real time video can be done remotely. Click the right mouse to start saving. Click the right mouse to stop saving. Remote Backup can also be done. The same procedure is used as “DFS Backup”.
  • Page 104 User Manual (5.1.0.0) 6.3 Real Time Audio Click the right mouse and select “Enable Audio” to hear real time audio. Note: Changing “Setup” remotely can be done if remote user is “Admin” or “Admin Mode”.

  • Page 105: Table Of Contents

    User Manual (5.1.0.0) Appendix 1 POS DVR TABLE OF CONTENTS 1.1 Hardware Installation 1.1.1 Parts 1.1.2 Installation 1.2 Software Installation 1.2.1 Installation & Setup...

  • Page 106: Hardware Installation

    User Manual (5.1.0.0) 1.1 Hardware Installation 1.1.1. Parts...

  • Page 107: Part Names

    User Manual (5.1.0.0) Part Names 1.RS232 Serial Cables (Cross & Direct) 2. RS232 Serial Cable 3. RS232 Serial Cable 4. RS232 Serial Converter (9 pins into 25 pins) 5. Gender Changer 6. #1 + #4 + #5 7. DVR 8. POS Printer 9.

  • Page 108: Installation

    User Manual (5.1.0.0) 1.1.2 Installation Part # 2 goes into the COM Port 1 of Part # 7. Part # 1 goes into the serial port of Part # 8. Part # 3 goes into the serial port of Part # 9.

  • Page 109: Software Installation

    User Manual (5.1.0.0) 1.2 Software Installation 1.2.1 Installation & Setup Install “text_inserter_plugin_for_pos” on DVR Server. Click “Next” to start.
  • Page 110 User Manual (5.1.0.0) Select “Typical Installation” for automatic installation. Select camera channels and click the com port buttons for serial port configuration. Make sure to select “COM1” if POS printer is connected to com port 1. The Baud rate value is normally 9600.
  • Page 111 User Manual (5.1.0.0) Click “Finish” to complete. Go to “Text Inserter” in the DVR setup and choose different fonts and different display corners.
  • Page 112 User Manual (5.1.0.0) Appendix 2 I-phone TABLE OF CONTENTS 2.1 Installation 2.2 Execution 2.3 Audio Setup...
  • Page 113 User Manual (5.1.0.0) 2.1 Installation Any system used for “Two-way Communication” must have static IP and “iphone(1.0.1.0).exe” must be installed. For iphone installation, double-click on iphone(1.0.1.0).exe”. Click “Next” to start installation process and select “Automatic Installation”.
  • Page 114 User Manual (5.1.0.0) Click “Finish” to complete the process. 2.2 Execution Go to “Start”, “All Programs”, find “I-phone” and select it for execution. Find the I-phone icon at the right bottom and click it for the next step.
  • Page 115 User Manual (5.1.0.0) Select “Call” for Two-Way Communication”, type in IP address and click “Connect”. Property: The default port number is 8015 and the default timeout value is 5 seconds. Leave them as they are unless other values must be used. 2.3 Audio Setup Go to “Control Panel”, ”Sounds, Speech and Audio Devices”...
  • Page 116 User Manual (5.1.0.0) Recording Control should be set up this way.

  • Page 117: Appendix 3 Mdvr

    User Manual (5.1.0.0) Appendix 3 MDVR...
  • Page 118 User Manual (5.1.0.0) 3.1 Installation 3.1.3 On Installing 3.1.1 Start: Click “Next” to start installation process. 3.1.2 Selection of Installation Method: Select “Automatic Installation”.
  • Page 119 User Manual (5.1.0.0) 3.1.4 Finish: Click “Finish” to complete installation.
  • Page 120 User Manual (5.1.0.0) 3.2 Overview Multi-site Search Exit Management Site Name Screen Mode Camera Control Setup E-Map Log in & Log Event Live Viewing Properties...
  • Page 121 User Manual (5.1.0.0) 3.3 Execution 3.3.1 Properties. Click on the “Properties” button to register group and site. Registration Steps: Click “Add group” to make group. One group can have up to 64 sites (cameras).
  • Page 122 User Manual (5.1.0.0) 2. After making all groups, select a group to register sites. Click on the “Add site” button. 3. Type in all the required information as below. Make sure to put in the same user and password used on DVR. 4.
  • Page 123 User Manual (5.1.0.0) 3.3.2 Log in & Log out Click on the “Log in & out” button to log in.
  • Page 124 User Manual (5.1.0.0) 3.3.3 Setup Click on the “Setup” button to use different opions. By checking the box, camera name, status, and POS text will be displayed on camera picture. By checking the box, MDVR user and password will be asked in the event of the execution of MDVR.
  • Page 125 User Manual (5.1.0.0) 3.4 E-Map Click on the “E-Map” button to configure E-Map. To create an E-Map image, click on the right mouse and select “Open E-Map”. Only BMP file can be in use.
  • Page 126 User Manual (5.1.0.0) Click on the right mouse and select “Camera Lock” to be able to position DVRs at desired locations. Click on the right mouse and select “Save Setting” to save image and camera locations.
  • Page 127 User Manual (5.1.0.0) After configuration, selected E-Map image and all DVR sites at selected locations can be viewed. To visit DVR site using E-Map, simply double-click on camera-shaped icon. Any DVR (camera-shaped icon) blinking in red and blue has event occurred. 3.5 Event “Event”...
  • Page 128 User Manual (5.1.0.0) 3.6 Search Save Backup Search Steps: 1. Select date from the calendar. 2. Select time from the time bar. 3.6.1 Save Image can be saved either in BMP File or in JPEG File...
  • Page 129 User Manual (5.1.0.0) 3.6.2 Backup Back up recorded data using various backup devices. If password is set, viewing backup data will be possible only when it is typed in.
  • Page 130 User Manual (5.1.0.0)

This manual is also suitable for:
