ASSEMBLY
1.
Fit middle sections together.
L L O O W W E E R R
P P I I N N
3.
Place door in base, fitting lower
pin on door into hole in base.
T T O O P P
C C O O N N N N E E C C T T O O R R S S
5.
Fit 2 top sections together. Fit top
connectors onto top sections.
(Tabs on connectors fit into holes
in top sections; forks on connectors
fit into slots in top sections.)
R R A A M M P P
T T R R A A C C K K P P I I E E C C E E
7.
Fit lip on track piece into top
slot on base ramp.
M M I I D D D D L L E E S S E E C C T T I I O O N N S S
D D O O O O R R
B B A A S S E E
T T O O P P
S S E E C C T T I I O O N N S S
2.
Snap 2 middle connectors onto
middle sections as shown.
K K E E Y Y
4.
Snap middle section assembly
onto base, fitting upper pin on
door into hole in middle section.
6.
Snap top section assembly
onto middle section assembly.
4 4
2 2
8.
Peel and apply labels to the
outside of track as shown.
M M I I D D D D L L E E C C O O N N N N E E C C T T O O R R S S
U U P P P P E E R R P P I I N N
3 3
1 1
