Portwell WEBS-5491 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WEBS-5491
Fan-less Embedded System
User's Manual
Version 1.0
Copyright © Portwell, Inc., 2015. All rights reserved.
All other brand names are registered trademarks of their respective owners.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WEBS-5491 and is the answer not in the manual?

Questions and answers

Summary of Contents for Portwell WEBS-5491

  • Page 1 WEBS-5491 Fan-less Embedded System User's Manual Version 1.0 Copyright © Portwell, Inc., 2015. All rights reserved. All other brand names are registered trademarks of their respective owners.

  • Page 2: Table Of Contents

    Preface Table of Contents How to Use This Manual Chapter 1 System Overview ....................... 1-1 1.1 Introduction ....................... 1-1 1.2 Check List ......................1-1 1.3 Product Specification ..................1-3 1.4 Mechanical Dimension ..................1-4 Chapter 2 System Installation ....................2-1 2.1 Embedded Board H/W Jumper Setting Introduction .........

  • Page 3: How To Use This Manual

    Preface How to Use This Manual The manual describes how to configure your WEBS-5491 embedded system to meet various operating requirements. It is divided into five chapters, with each chapter addressing a basic concept and operation of Fan-less Embedded System.

  • Page 4: Chapter 1 System Overview

    System Overview Introduction Portwell Inc., a world-leading innovator in the Industrial PC (IPC) market and a Premier Member of the Intel® Internet of Things (IoT) Solutions Alliance, announced WEBS-5491, a fan-less embedded system. Builds on Intel® Baytrail SoC and takes advantages of Intel®...
  • Page 5 Power Switch Cable (from DC Jack to 3-pin TBC) Selectable I/O Kit 2x RS-232/422/485, 1x RS-232 (Expansion: Option 1) 1x RS-232/422/485, 2x USB ports and 1x Line-out (Expansion: Option 2) DVI to VGA cable DIN Rail kit (W/ 7*screws) WEBS-5491 Embedded System User’s Manual...

  • Page 6: Product Specification

    1.0G (CF/SSD/SD) and 0.5G (HDD) , Power on & 2.16G, Packaged; 5~500Hz Shock 15G peak acceleration, 11 ms (Power on condition) Package with Carton from 96.5 cm (1-Corner, 3-Axis, 6-Face) Drop Certification CE/FCC Class A WEBS-5491 Embedded System User’s Manual...

  • Page 7: Mechanical Dimension

    System Overview 1.4 Mechanical Dimension Front view of the WEBS-5491 system Rear view of the WEBS-5491 system Side view of the WEBS-5491 system WEBS-5491 Embedded System User’s Manual...
  • Page 8 System Overview Top view of the WEBS-5491 system Bottom view of the WEBS-5491 system WEBS-5491 Embedded System User’s Manual...

  • Page 9: Chapter 2 System Installation

    System Installation Chapter 2 System Installation This chapter provides you with instructions to set up your WEBS-5491 embedded system. Definitions and locations of all the interfaces are described so that you can easily configure your system. 2.1 Embedded Board H/W Jumper Setting Introduction WEBS-5491 Embedded system adopts PEB-99A4 mother board.
  • Page 10 Power Input Connector. (Terminal Blocks 3Px1/5.08mm female) SD Card. USB Port 3 Connector (1*4 Pin Wafer/2mm). Jumpers Clear CMOS. GPIO Voltage selection. Audio out.(From amplifier) LPC Debug Port. JP10 COM PORT RI and power source adjust pin. WEBS-5491 Embedded System User’s Manual...
  • Page 11 JP7: GPIO Power Selection PIN NO. DESCRIPTION 5V Level ★ Default 3.3V Level JP8: Internal Audio Connector PIN NO. DESCRIPTION Audio_R+ Audio_R- Audio_L+ Audio_L- JP9: LPC Debug Port Pin Assignment PIN NO. DESCRIPTION PIN NO. DESCRIPTION WEBS-5491 Embedded System User’s Manual...
  • Page 12 System Installation LAD0 3.3V LAD1 LPC_RESET LAD2 LPC_FRAME LAD3 LPC_CLCOK WEBS-5491 Embedded System User’s Manual...

  • Page 13: Selectable I/O Kit Installation

    *Note: Diagram of SW2 default setting 2.2 Selectable I/O Kit Installation In addition to default I/O interfaces, including 1x DVI, 2x RS-232/422/485, 4x USB and 2x Gigabit Ethernet, to further enhance system flexibility as well as to increase WEBS-5491 Embedded System User’s Manual...

  • Page 14: Memory Installation

    System Installation the versatility in application fields, WEBS-5491 allows users to select different I/O combinations for various market demands. 2.3 Memory Installation WEBS-5491 system supports one DDR3L SO-DIMM memory module. It’s easy to install by just opening the back cover.

  • Page 15: Hdd Installation

    6. Inside view of installed HDD in system 2.5 CF and SD card Installation CF and SD card are both supported in WEBS-5491 Series. It is easy to install CF and SD card by opening the cover at side and insert the card.

  • Page 16: Getting Started

    System Installation 2.6 Getting Started WEBS-5491 Series support 12~24V DV input via 3-pin terminal block connector. 1. Male-type 3-pin terminal block connector 2. Take the female type 3-pin terminal block located at rear I/O connector in accessory kit 3. Fix female type 3-pin terminal block 4.

  • Page 17: Rear View

    3x USB 2.0 & 1x USB 3.0 Option 1 1x USB 2.0 & 1x USB 3.0 Option 2 3x USB 2.0 & 1x USB 3.0 DVI-I: An external monitor can be provided via DVI-I interface. COM ports: Connectors for RS-232/422/485 connection WEBS-5491 Embedded System User’s Manual...
  • Page 18 With different I/O Total # of Details kit combination… Audio ports Default Option 1 Option 2 1x Line-out CF Cover: Remove the cover and install the CF card. *Note: Refer to section 2.5 for installation guide. WEBS-5491 Embedded System User’s Manual 2-10...

  • Page 19: Chapter 3 Bios Setup Information

    Chapter 3 BIOS Setup Information WEBS-5491 Series Panel PC adopts PEB-99A4 mother board. PEB-99A4 is equipped with the AMI BIOS stored in Flash ROM. These BIOS has a built-in Setup program that allows users to modify the basic system configuration easily.

  • Page 20: Main

    System Date The date format is <Day>, <Month> <Date> <Year>. Use [＋] or [－] to configure system Date. System Time The time format is <Hour> <Minute> <Second>. Use [＋] or [－] to configure system Time. WEBS-5491 Embedded System User’s Manual...

  • Page 21: Configuration

    BIOS Setup Information 3.3 Configuration Use this menu to set up the items of special enhanced features. WEBS-5491 Embedded System User’s Manual...
  • Page 22 Vander pool Technology. The choice: Disabled. Enabled(Default). EIST Enable/Disable Intel Speed Step. The choice: Disabled. Enabled(Default). CPU C6 report Enable or Disable the CPU C6 (ACPI C3) report to OS. The choice: Disabled(Default). Enabled. WEBS-5491 Embedded System User’s Manual...
  • Page 23 Enable or Disable the High Precision Event Timer. The choice: Disabled. Enabled(Default). Audio Controller Control Detection of the Azalia device. Disabled = Azalia will be unconditionally disabled. Enabled = Azalia will be unconditionally Enabled. The choice: Disabled. Enabled(Default). WEBS-5491 Embedded System User’s Manual...
  • Page 24 Launch Legacy PXE Rom. [Disable] Not Launch Rom, [Enabled] Force Launch Rom. The choice: Disabled(Default). Enabled. Wake on LAN Controller Enable or Disable Intel LAN 0 and Intel LAN 1 WGI210AT wakeup function. The choice: Disabled. Enabled(Default). WEBS-5491 Embedded System User’s Manual...
  • Page 25 Choices: Auto, IGD(Default), PCI, SG. DVMT Pre-Allocated Select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory sized used by the Internal Graphic Device Choices: 64M(Default), 96M, 128M, 160M, 192M, 224M, 256M, 288M, 320M, 352M, 384M,416M, 448M, 480M, 512M. WEBS-5491 Embedded System User’s Manual...
  • Page 26 Choices: PWM Inverted, PWM Normal(Default), GMBus Inverted, GMBus Normal. Active LFP Select the Active LEP Configuration. Mo LVDS: VBIOS does not enable LVDS. eDP Port-A: LFP driven by Int-DisplayPort encoder from Port-A. Choices: No LVDS, eDP Port-A(Default). WEBS-5491 Embedded System User’s Manual...
  • Page 27 BIOS Setup Information PCI/PCIE Configuration PCI , PCI –X and PCI Express Setting. WEBS-5491 Embedded System User’s Manual...
  • Page 28 Enable or Disable the PCI Express Port 1 in the Chipset. Choices: Enable(Default), Disable. Speed Configuration PCIe Speed Choices: Auto(Default), Gen1, Gen2. PCI Express Configuration Port 2 Enable or Disable the PCI Express Port 2 in the Chipset. Choices: Enable(Default), Disable. WEBS-5491 Embedded System User’s Manual 3-10...
  • Page 29 Configuration PCIe Speed Choices: Auto(Default), Gen1, Gen2. PCI Express Configuration Port 3 Enable or Disable the PCI Express Port 3 in the Chipset. Choices: Enable(Default), Disable. Speed Configuration PCIe Speed Choices: Auto(Default), Gen1, Gen2. WEBS-5491 Embedded System User’s Manual 3-11...
  • Page 30 Choices: Disabled, Enabled(Default). SATA Mode Select IDE / AHCI. Choices: Disabled, IDE, AHCI(Default). CF Device Enabled / Disabled CF Device. Choices: Disabled, Enabled(Default). Serial-ATA Port 0 Enable or Disable Serial ATA Port 0. Choices: Disabled, Enabled(Default). WEBS-5491 Embedded System User’s Manual 3-12...
  • Page 31 XHCI driver. Choices: Enabled, Disabled(Default). EHCI Hand-off This is a workaround for OSes without EHCI hand-off support. The EHCI ownership change should be claimed by EHCI driver. Choices: Enabled, Disabled(Default). WEBS-5491 Embedded System User’s Manual 3-13...
  • Page 32 USB 2.0 (EHCI) Support Control the USB EHCI (USB2.0) functions. One EHCI controller must always be enabled. Choices: Enable, Disable(Default). USB Port 0 Enable/Disable USB Port 0: USB 3.0 port on Board. Choices: Enable(Default), Disable. WEBS-5491 Embedded System User’s Manual 3-14...
  • Page 33 Enable/Disable USB Port 2: The USB port turn into a mini PCIE. Choices: Enable(Default), Disable. USB Port 3 Enable/Disable USB Port 3: The USB port as USB HUB have 2 USB Port in external cart. Choices: Enable(Default), Disable. WEBS-5491 Embedded System User’s Manual 3-15...
  • Page 34 Enable / Disable GPIO wake on Ring function. Choices: Disabled(Default), Enabled. Wake System from S5 Enable or Disable System wake on alarm event, Select Enable, system will wake on the hr: mm: sec: specified. Choices: Disabled(Default), Enabled. WEBS-5491 Embedded System User’s Manual 3-16...
  • Page 35 Set Termination Control Disabled/ Enabled. Choices: Disabled, Enabled(Default). Direction Control Set Direction Control set Enabled as Transceiver else; Disabled as Receiver. Choices: Disabled(Default), Enabled. Serial Port Enable or Disable Serial Port (COM) IO=2F8H; IRQ=3. Choices: Disabled, Enabled(Default). WEBS-5491 Embedded System User’s Manual 3-17...
  • Page 36 Enable or Disable Watch Dog Timer. Choices: Disabled(Default), Enabled. Timer Unit (Watch Dog Timer Enabled) Select Timer count unit of WDT. Choices: Seconds(Default), Minutes. Timer value (Watch Dog Timer Enabled) Set WDT Timer value Seconds/minutes. Choices: Default [20]. WEBS-5491 Embedded System User’s Manual 3-18...
  • Page 37 BIOS Setup Information Hardware Monitor Monitor hardware status. WEBS-5491 Embedded System User’s Manual 3-19...

  • Page 38: Security

    Password Check Mode [Setup] check password when enter setup screen, [Power On] check password on every time system power on. Choices: Setup(Default), Power On. Administrator Password Set Administrator Password User Password Set User Password. WEBS-5491 Embedded System User’s Manual 3-20...

  • Page 39: Boot

    Choices: Default [5]. Bootup NumLock state Select the keyboard NumLock state. Choices: On(Default), Off. Post Report Post Report Support Enabled/Disabled. Choices: Disabled(Default), Enabled. Summary Screen Summary Screen Support Enabled/Disabled. Choices: Disabled(Default), Enabled. WEBS-5491 Embedded System User’s Manual 3-21...
  • Page 40 Enables or Disables boot with initialization of a minimal set of devices required to launch active boot option. Has no effect for BBS boot options. Choices: Disable(Default), Enabled. Boot Option #1 Sets the system boot order Choices: UEFI: Built-in EFI Shell, Disabled. WEBS-5491 Embedded System User’s Manual 3-22...

  • Page 41: Save And Exit

    BIOS Setup Information 3.6 Save and Exit Save Changes and Reset Reset the system after saving the changes. Pressing <Enter> on this item asks for confirmation: Save configuration and reset. WEBS-5491 Embedded System User’s Manual 3-23...
  • Page 42 Reset system setup without saving any changes. Pressing <Enter> on this item asks for confirmation: Reset without saving. Restore Defaults Restore/Load Default values for all the setup options. Pressing <Enter> on this item asks for confirmation: Load Optimized Default. WEBS-5491 Embedded System User’s Manual 3-24...

  • Page 43: Chapter 4 Important Instructions

    4.2 Exclusion of Accident Liability Obligation Portwell, Inc. shall be exempt from the statutory accident liability obligation if users fail to abide by the safety instructions. 4.3 Liability Limitations / Exemption from the Warranty Obligation In the event of damage to the system unit caused by failure to abide by the hints in this manual and on the unit (especially the safety instructions), Portwell, Inc.

  • Page 44: Chapter 5 Frequent Asked Questions

    You can find OS Selection under BIOS setting. Step1. Power on the computer and the system will start POST (Power on Self Test) process. When the message appears on the screen, press <Del> key and enter BIOS setup screen. WEBS-5491 Embedded System User’s Manual...
  • Page 45 Frequent Asked Questions Step2. In page “Boot”, you can find OS Selection and choose the corresponding OS. Note: For Linux OS, please choose Windows 7. WEBS-5491 Embedded System User’s Manual...
  • Page 46 AT mode. SW2: AT/ATX & BIOS recovery Setup PIN NO. DESCRIPTION ON: AT Mode 1-4(Port1) OFF:ATX Mode ★ Default *Note: Diagram ATX mode setting *Note: Diagram AT mode setting WEBS-5491 Embedded System User’s Manual...
