Summary of Contents for Bluerock Tools S75
- Page 1 Volume OPERATIONAL MANUAL MODEL: S75 SECTIONAL DRAIN CLEANING MACHINE by BLUEROCK ® Tools...
- Page 2 S 7 5 P I P E D R A I N C L E A N E R UNPACKING THE ITEM Caution: This machine is packed together with items that may be sharp, oily and overly heavy objects. Remove the machine from the packaging in a safe manner.
-
Page 3: Table Of Contents
S 7 5 P I P E D R A I N C L E A N E R Table of Contents SAFETY PRE-OPERATIONAL SAFETY CHECKS OPERATIONAL SAFETY CHECKS SPECIFICATIONS INCLUDED ACCESSORIES ADDITIONAL AVAILABLE ACCESSORIES BLUEROCK ® T DDITIONAL ACCESSORIES FOR THIS MACHINE CAN BE FOUND IN OOLS ONLINE SHOP AT BLUEROCKTOOLS COM OR FROM YOUR LOCAL RETAILER... -
Page 4: Safety
Chapter S 7 5 P I P E D R A I N C L E A N E R Safety DO NOT USE THIS MACHINE UNLESS YOU HAVE READ THE OPERATING INSTRUCTIONS! Safety glasses must be worn at all times in Long and loose hair must be work areas. - Page 5 S 7 5 P I P E D R A I N C L E A N E R Ø DO always non-slip rubber soled shoes. Ø DO be extremely careful when cleaning drains where chemical cleaning compounds have been previously used. Ø...
-
Page 6: Specifications
S 7 5 P I P E D R A I N C L E A N E R Chapter Specifications ELECTRICAL DATA Voltage 110V, 60Hz Induction 1/6hp Motor Current 4 Amps Motor Size 400W Power Connection US Standard 3 Prong Grounded Plug GFCI Yes, Inline on power cable MECHANICAL DATA... -
Page 7: Operations
THOROUGHLY READ THROUGH THE ENTIRE MANUAL BEFORE OPERATING THIS MACHINE! PURPOSE Ø The purpose of the S75 is for cleaning the insides of drainpipes from 3/4” to 4” in diameter. This is a heavy-duty professional use machine allowing a single user to easily clean pipes. Ø... -
Page 8: Preperation For Using Machine
S 7 5 P I P E D R A I N C L E A N E R PREPERATION FOR USING MACHINE Ø CAUTION: Before making any adjustments, ensure the main machine switch is in the “O” off position. CAUTION: Before starting your job, it is vital to be aware of the distance from the sewer inlet pipe to the Ø... - Page 9 S 7 5 P I P E D R A I N C L E A N E R Ø Rubber Safety Hose Operations The rubber safety hose is attached to the back of the machine clutch channel. CAUTION: The rubber safety hose must be installed. It protects the user from potential “whipping”...
- Page 10 S 7 5 P I P E D R A I N C L E A N E R There are a variety of drain cutters available for these units (see cutter/accessory table below). When deciding which cutter to use, the user should choose a cutter size that is at least §...
-
Page 11: Running The Machine
S 7 5 P I P E D R A I N C L E A N E R RUNNING THE MACHINE Ø Do all pre-operational and operational safety checks from Chapter 1. Ø Consider your security and stability as well as the orientation of the machine in the work area. Consider the work surface material, condition, strength, density and rigidity. - Page 12 S 7 5 P I P E D R A I N C L E A N E R Ø Turn the main machine switch to the “on” position (“R” for general cutting forward clockwise). NOTE: The machine will turn on, but the cable will not spin yet (until the clutch handle is depressed.
- Page 13 S 7 5 P I P E D R A I N C L E A N E R With gloved hand, pull the cable out or hold cable against the edge of the sewer inlet pipe until a half circle is formed in the cable. §...
-
Page 14: Troubleshooting
S 7 5 P I P E D R A I N C L E A N E R Chapter Troubleshooting Note SERVICING SHOULD ONLY BE DONE BY A QUALIFIED TECHNICIAN. DON’T FORGET TO UNPLUG POWER TO UNIT PRIOR TO SERVICE! PROBLEM CAUSE CORRECTION... -
Page 15: General Maintenance
S 7 5 P I P E D R A I N C L E A N E R Chapter General Maintenance Note SERVICING SHOULD ONLY BE DONE BY A QUALIFIED TECHNICIAN. DON’T FORGET TO UNPLUG POWER TO UNIT PRIOR TO SERVICE! Ø... -
Page 16: Parts List And Breakdown View
S 7 5 P I P E D R A I N C L E A N E R Chapter Parts List and Breakdown View...
