FCHC
Operating and
Maintenance Manual
FCHU
Horizontal Concealed/
Horizontal Ultra Thin
Units
Fan Coil Unit (FCU)
Precautions and preparations listed are for general knowledge and to define basic guidelines. Local codes and existing practices should be observed and preformed by a professional.
Due to ICE AIRs ongoing product development programs, the information in this document is subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FCHC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ICE AIR FCHC

  • Page 1 FCHC Operating and Maintenance Manual FCHU Horizontal Concealed/ Horizontal Ultra Thin Units Fan Coil Unit (FCU) Precautions and preparations listed are for general knowledge and to define basic guidelines. Local codes and existing practices should be observed and preformed by a professional.
  • Page 2: Table Of Contents

    Components and Parts View ......4 FCHC Nomenclature ........5 ICE AIR Horizontal FCUs are built to a high standard of quality and FCHC Valve Package Nomenclature ..... 6 reliability, employing commercial grade components and heavy FCHU Nomenclature ........
  • Page 3: Consumer Safety Information/Guidelines

    WARNING: Do NOT operate the unit with frayed, burnt or damaged electrical wires! For safe and optimal enjoyment of your ICE AIR unit, please read WARNING: Do NOT operate the equipment when in doubt – the following consumer safety and operating notes carefully before...
  • Page 4: Components And Parts View

    Components and Parts View Horizontal Concealed SHOWN WITH OPTIONAL PLENUM RETURN JUNCTION CONDENSATE DRAIN DRAIN PAN TOP VIEW DUCT COLLAR SUPPLY AND RETURN CONNECTIONS AIR SUPPLY FRONT VIEW RIGHT VIEW Ultra Thin FAN MOTOR SHOWN WITHOUT PLENUM RETURN JUNCTION CONDENSATE DRAIN DRAIN PAN TOP VIEW DUCT COLLAR...
  • Page 5: Fchc Nomenclature

    Nomenclature Model Selection FCHC 08 E M X A G A P M F Item Number 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 Primary Part Secondary Parts Valve Package Parts 5- 115V - 1Ph - 60Hz...
  • Page 6: Fchc Valve Package Nomenclature

    Valve Package Nomenclature Model Selection FCHC 08 E M X A G A P M F Item Number 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 Primary Part Secondary Parts Valve Package Parts...
  • Page 7: Fchu Nomenclature

    Nomenclature Model Selection FCHU 08 E M X 22 A G A A P M F Item Number 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 Primary Part Secondary Parts Valve Package Parts 5- 115V - 1Ph - 60Hz 8- 208V - 1Ph - 60Hz 7- 277V - 1Ph - 60Hz...
  • Page 8: Fchu Valve Package Nomenclature

    Valve Package Nomenclature Model Selection FCHU 08 E M X - 22 A G A A P M F Item Number 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 Primary Part Secondary Parts Valve Package Parts 22- Line Voltage 2 Way Motorized Valve Heat NO, 29- 24V 2 Way Motorized Valve Heat NO, Cool...
  • Page 9: Controls

    Thermostat Location The ICE AIR horizontal units do not come with a standard thermostat selection. There are two options that are specific for each job; Wired Thermostat and Wireless Thermostat.
  • Page 10: Lcd Programmable Operation

    LCD Programmable Operation User Interface Button Press Hold UP/Override mode UP/Permanent Override mode DOWN/Override mode DOWN/Permanent Override mode ON/OFF ON/OFF -------- MODE Set operation mode Internal Setting Set fan speed/Confirm -------- The temperature reading that is on constant display is the ambient room temperature.
  • Page 11 Auto Mode Event Time Heat Cool Days 1. To activate Auto mode, press the MODE button until WAKE 6:00 AM 70º F (21º C) 78º F (26º C) MON-FRI AUTO displays. LEAVE 8:00 AM 62º F (17º C) 85º F (29.5º C) 2.
  • Page 12 Permanent Override Cooling Mode: With the ASC switch in the Summer (Cooling) position, the Heat/Cool thermostat shall cycle the water control valve, 1. Holding UP and DOWN button for two seconds to enter via the thermostat’s cooling signal, to maintain the desired space Permanent Override mode.
  • Page 13: Maintenance

    Only configurations with a plenum on the procedures are followed. This manual return vent for the ICE AIR unit are delivered If there is evidence of dirt or dust build-up in assumes that your unit has been installed with a dispensible filter.
  • Page 14 General Unit Inspection Electrical Connections Visually inspect unit at least once a month. The unit Serial Number name plate has Pay special attention to hose assemblies and the required supply voltage, fan amps and connections. Repair any leaks and replace required circuit amps (optional electrical heat deteriorated hose immediately to avoid amps).
  • Page 15: Troubleshooting

    If unit is not operating, conduct the following checks: IMPORTANT: It is not the intent of this maintenance manual to resolve any problems with the operation of your ICE AIR unit. 1. Check the electrical connections. Please contact a trained servicer or building maintenance 2.
  • Page 16: Warranty/Contact Information

    The Company is not obligated under this warranty for specifi cally agreed to in writing, ICE AIR includes no fi eld default. ICE AIR is not responsible for service to correct fi...
